Callan Bentley Grade 2 Passage Leverset
Passage Function: Passage lever sets have no locking function and are free turning on both sides. These are perfect for a hallway or closet where no locking is necessary.
Features:
- Combination screws that suit both wood or metal door mounting
- Heavy duty all metal construction
- Protective sleeve for added latch security
- Interlocking chassis provides additional strength
- Patented GR2 adjustable latch
- Reinforced spring assembly for improved performance
- Reversible handing (either left or right)
- ADA compliant
Specifications:
- Backset: 2-3/4", 2-3/8", Adjustable 2-3/8" or 2-3/4"
- BHMA Certification: Grade 2
- Cross Bore: 2-1/8"
- Cylinder: 5 Pin Schlage C
- Door Thickness: 1-3/4", 1-3/8"
- Edge Bore: 1"
- Function: Keyed Entry
- Handing: Left, Reversible, Right
- Handle Material: Metal
- Handle Style: Lever
- Latch Faceplate: Round Corner, Squared Corner
- Panic Proof: No
- Product Class: Residential
- Product Weight: 2.3 lbs
Manufacturer Resources
Product Specs
- Subcategory:
- Leversets
- Series:
- Bentley
- Product Group:
- Mechanical Locks
- Product Subgroup:
- Bored Locksets
- Commercial/Residential:
- Residential
- Lock Function:
- Passage
- Product Type:
- Leversets
- Grade:
- Grade 2
- Product Attribute:
- Cylindrical Locks
- Product Function:
- Passage/Hall/Closet
- Product Category:
- Mechanical Locks
- Department:
- Door Hardware
Callan G2BN5011R – Frequently Asked Questions
1) Will the Callan Bentley passage leverset fit a 1-3/8 inch door, or only a 1-3/4 inch door?
Both. The Bentley passage lever is built for 1-3/4 inch and 1-3/8 inch doors, which covers standard commercial slabs and the thinner older interior doors you find in apartments and hallways. The prep is the usual bored prep: 2-1/8 inch cross bore, 1 inch edge bore. If your doors run thicker than 1-3/4 inches, look at something like the Hager 2510 passage lever, which covers 1-3/8 to 2 inches.
2) Does the Bentley passage lever work with a 2-3/8 inch backset, or do I need to know my backset before ordering?
Either backset works. The Bentley passage set is offered in 2-3/4 inch, 2-3/8 inch, and an adjustable latch that covers 2-3/8 or 2-3/4 inch. The adjustable version is the one to grab for a retrofit where you haven't measured every door, since those two are the standard bored backsets. Latch faceplate comes round corner or squared corner, so match whatever mortise is already cut in the door edge.
3) Do I have to specify handing for a Callan Bentley passage lever?
No. The Bentley lever is reversible, so one set handles a left or right hand door and you flip it on site. For a property manager buying a carton of these for hallway and closet doors, that means one part number covers the whole building regardless of swing.
4) What is a passage lever and do I need one for a hall or closet door?
A passage function lever has no lock at all. Both sides turn freely at all times, there is no key, no pushbutton, no thumbturn. It is latching hardware only, to hold the door closed. That is what you want on a hallway, a closet, a laundry, or a utility door. If someone needs to lock the door from inside, that is a privacy set instead, and if it needs a key, that is an entry or storeroom function.
5) The Bentley is rated for residential use - what passage lever should be used on a high traffic commercial corridor instead?
The Callan Bentley is a Grade 2 residential class passage leverset. For a corridor or stairwell door that cycles constantly, a Grade 1 passage lever is the step up: the Falcon K101 is a Grade 1 heavy duty passage cylindrical lock with non-handed levers, fire rated, for doors 1-3/8 inch to 2-1/4 inch thick; the Falcon T101 is a Grade 1 heavy duty passage lever with pressure release technology; the Corbin Russwin CL3110 is a Grade 1 vandal resistant passage/closet lever, fire rated, for 1-3/4 inch to 2 inch doors; and the Design Hardware X75 is a Grade 1 passage lever lockset with a flat lever for 1-3/4 inch doors.
6) What is the closest equivalent to the Callan Bentley passage leverset from another brand?
The Bentley passage leverset is a Grade 2 cylindrical lever with passage function, so the nearest matches are other Grade 2 cylindrical passage levers. The Accentra 5301LN Augusta is a Grade 2 cylindrical lever lock in passage/closet function from the 5300 Series, and the Accentra 4601LN carries the same Grade 2 passage function with Augusta trim in the 4600 Series. The Hager 2510 is a Grade 2 passage cylindrical lever with the Withnell lever design, and the Falcon B101 is a Grade 2 medium duty cylindrical passage lever with a non-handed design. All four are non-keyed and free turning on both sides, the same as the Bentley.
7) The opening needs to lock - what takes the place of the Callan Bentley passage leverset?
Passage function has no locking at all and turns freely on both sides, so a door that needs to secure takes a different function in the same cylindrical lever family. For a bath or bedroom, the Hager 2540 is a Grade 2 privacy cylindrical lock with the Withnell lever, and the Arrow MK02-TA is a privacy cylindrical lock with a Tudor knob and a fire rating. For an office or entry door, the Hager 2525 is a Grade 2 commercial cylindrical entry lock with a lever handle, the Falcon B511CP6D is a Grade 2 medium duty cylindrical lever in entry/office function, and the Cal-Royal AG00 entrance lever is Grade 2 with a 6-pin Schlage C keyway keyed different and a 2-3/8 inch backset. For a door that must stay locked outside and always exit free, the Cal-Royal AG05 is a Grade 2 storeroom lever lockset with a deadlocking latchbolt and the Hager 2580 is a Grade 2 storeroom cylindrical lock with the Withnell lever.
8) The doors are thicker than what the Callan Bentley covers - which passage lever fits?
The Bentley is built for 1-3/4 inch and 1-3/8 inch doors. On a thicker slab, the Falcon K101 Grade 1 passage lock covers 1-3/8 inch to 2-1/4 inch, the Corbin Russwin CL3110 passage/closet lever covers 1-3/4 inch to 2 inch, the Arrow GL01 Grade 2 Sierra lever passage lock covers 1-3/4 inch to 2 inch, and the Hager 2510 Grade 2 passage lever covers 1-3/8 inch to 2 inch. All four keep the same non-keyed passage function.
9) Is the Callan Bentley lever ADA compliant for a commercial hallway?
The Bentley lever is ADA compliant, and lever hardware is what ADA asks for in the first place, since it opens without grasping, pinching, or twisting the wrist. Note that Callan classes the Bentley as a residential product carrying BHMA Grade 2, so it suits multi-family corridors and light commercial traffic rather than a high-cycle institutional opening.
10) Can I mount a Callan Bentley leverset on a hollow metal door, or is it wood only?
Both. The Bentley ships with combination screws that suit wood or metal door mounting, so the same carton covers a wood apartment door and a hollow metal utility door. Standard bored prep applies either way, 2-1/8 inch cross bore and 1 inch edge bore.
11) I need matching privacy and keyed levers to go with these passage sets. Does the Bentley line cover that?
The Bentley passage set itself is non-keyed and non-locking, so it will not lock a bathroom or an entry door. Callan builds the Bentley in other functions to match, and the passage set's own spec sheet references a 5 pin Schlage C cylinder and a keyed entry function within the series, so ask for the Bentley keyed entry or privacy in the same finish rather than mixing in another brand's trim. If you need a matched family from a single commercial line instead, the Bravura Miramar, Atlanta, Orlando, and Tampa passage leversets are all Grade 2 with different trim shapes.
12) Is there a lighter duty passage lever than the Callan Bentley for interior bedroom and hall doors?
The Bentley is Grade 2. Below that, the Kwikset 200BRNL RDT Breton passage lever set is Grade 3 with passage/hall/closet function for doors 1-3/8 inch to 1-3/4 inch thick, and the Kwikset 200DL Delta passage lever is an interior hall and closet lock, reversible, with an adjustable 6AL latch and RCS strike. The Kwikset 200DL-RCALFD is the same Delta passage lever supplied with a round corner adjustable 20 minute UL latch and round corner strike. Grade 3 levers are built for interior residential traffic rather than the cycle counts a Grade 2 chassis is tested to.
13) Is a keypad lever an alternative to the Callan Bentley passage leverset?
Only if the opening needs code entry, which passage function does not provide - the Bentley turns freely on both sides with no locking. If the door does need a code, the Lockey 2835 is a mechanical pushbutton keyless lever lock with passage function and ADA compliance for doors 1-3/16 inch to 2 inch, the Lockey 2835DC adds a double combination in the same thickness range, and the Lockey 1150 is a heavy duty mechanical keypad lever set with double combination in passage function for 1-1/8 inch to 2 inch doors. The Delaney LP250 is a Grade 2 electronic keypad leverlock. These carry battery or mechanical code hardware the Bentley does not, and they change the trim footprint on the door.
14) What Grade 2 passage levers offer a different trim shape than the Callan Bentley?
Several Grade 2 passage levers differ mainly in trim styling. Bravura offers round trim passage leversets in the Atlanta and Orlando series and the Miramar in US4 satin brass, plus the Tampa with square trim - all Grade 2 passage function. The Arrow GL01 uses the Sierra lever, the Hager 2510 uses the Withnell lever, and the Design Hardware J75 is a Grade 2 passage lever lockset with a flat lever for 1-3/4 inch doors. The Callan Bentley itself comes in US15 satin nickel, US19 black, and US10BE edged bronze.
15) Which passage lever is non-handed, so handing does not have to be called out on the order?
The Callan Bentley is reversible for either left or right hand doors, so one set covers both. If a strictly non-handed chassis is preferred, the Falcon B101 is a Grade 2 medium duty cylindrical passage lever with a non-handed design and the Falcon K101 is a Grade 1 passage cylindrical lock with non-handed levers. The Kwikset 200DL Delta passage lever is also reversible. On a fleet order this removes the handing line item from every door in the takeoff.
16) What lever should be used on a utility, mechanical, or patient room door instead of a passage set?
Passage function leaves the door free on both sides, which is wrong for a room that must be controlled. Asylum and institutional function is the alternative: the Dexter C1000 Series asylum lock is Grade 1 in asylum/institution/utility function for doors 1-3/8 inch to 2 inch, and the Arrow MK33-BD-CS is a Grade 2 heavy duty asylum cylindrical lock with a ball knob and a conventional cylinder in the Schlage C keyway. For a classroom, the Dexter C1000 classroom lever is Grade 1 clutching and keyed for 1-3/8 inch to 1-3/4 inch doors, with a classroom security version in the same range, and the Cal-Royal AG03 classroom lever is Grade 2 with a 6-pin Schlage C keyway keyed different on a 2-3/4 inch backset.
17) Which passage lever matches a Baldwin Estate lever already on the other doors?
If the rest of the openings carry Baldwin Estate trim, the Baldwin Estate 5103 passage lever with the 5048 rose is the matching passage device, with the 5103 privacy lever and the 5103 half dummy in left and right hand covering the other functions in the same trim family. The Callan Bentley is a separate design and will not visually match a Baldwin Estate rose, so mixing the two on adjacent doors in one corridor is a decision to make deliberately.
18) Which passage lever should be used on a door that needs access control wiring?
The Callan Bentley is a mechanical passage set with no electrical provision. For an electrified opening, the Corbin Russwin CL33903 is a Grade 1 fail safe electrified cylindrical lever lock at 12VAC/DC for doors 1-3/4 inch to 2 inch, available with the NZ lever and D rose. That device is controlled by the access system rather than turning free on both sides the way a passage lever does, so the door also needs power transfer and a controller the passage set never required.
19) What finishes does the Callan Bentley passage lever come in?
Three: US15 satin nickel, US19 black, and US10BE edged bronze. Satin nickel is the one that blends with most existing multi-family trim, black suits newer matte-black packages, and edged bronze is the darker traditional look. All three are the same passage set underneath, so you can mix finishes floor to floor without changing the prep.
