Callan Model 200S - Grade 3 Single Cylinder Square Trim Deadbolt

Callan Model 200S - Grade 3 Single Cylinder Square Trim Deadbolt

(No reviews yet) Write a Review

Model: 372001
$69.00
$58.29
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$69.00
$58.29
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Callan Model 200S - Grade 3 Single Cylinder Square Trim Deadbolt

The single cylinder deadbolt with an enlarged back plate is a perfect match to all designer series Italian collection entry knobs or levers where additional security is required. The design of the deadbolt includes all the important features of a high quality deadbolt while offering matching style and beauty. Each deadbolt comes with long 3 in. strike plate security screws. Thumb turn on the inside unlocks the deadbolt without a key to provide a quick and easy exit in an emergency.

Single Cylinder Function: Single cylinder deadbolts are keyed on the exterior with an associated thumb turn on the inside that can quickly and easily lock or unlock the latch mechanism. Single cylinder locks are most commonly used to secure entrances to a residence or place of business.

Features:

  • Protective collar
  • High Security Strike Plate
  • Interlocking installation guides
  • Reinforced spring assembly

Technical Specification Download

Manufacturer Resources

Product Specs

Subcategory:
Deadbolts
Product Group:
Mechanical Locks
Product Subgroup:
Bored Locksets
Commercial/Residential:
Residential
Lock Function:
Single Cylinder
Product Type:
Deadbolts
Grade:
Grade 3
Product Attribute:
Deadbolts
Product Model:
200S
Product Function:
Cylinder x Thumbturn
Product Category:
Mechanical Locks
Department:
Door Hardware

Callan 372001 – Frequently Asked Questions

1) Will the Callan 200S deadbolt match my existing Callan entry knobs and levers?
The 200S is built as the square-trim companion to the Callan designer series Italian collection entry knobs and levers, so the trim styling and finish line up with those sets on the same door. It comes in three finishes: US15 Satin Nickel, US19 Black, and US10BE Edged Bronze. If your knobs or levers are one of those three finishes, the deadbolt matches above them.
2) Can I key the Callan 200S deadbolt to match my existing house or building keys?
Yes, within two keyways. The 200S is ordered with either an SC1 5-pin (Schlage) or KW1 5-pin (Kwikset) keyway, and you pick Keyed Different or Keyed Alike at the same time. If the doors you are matching already run SC1 or KW1 keys, order that keyway keyed alike and one key runs the group. Both keyway and keying are required selections, so neither is a default you can skip.
3) Is a single cylinder deadbolt or a double cylinder deadbolt right for my entry door?
Single cylinder, like the Callan 200S, is keyed outside with a thumbturn inside, so anyone can get out without hunting for a key. That is the usual choice for a residence or a place of business entry. Double cylinder needs a key on both sides and is used where glass sits close enough to the lock that someone could reach through and turn a thumbturn, but it slows egress and many jurisdictions restrict it on dwelling exits. If you need the keyed-both-sides version, ZenSupply carries the Delaney LU Series double cylinder deadbolt and the Baldwin Reserve Contemporary Square double cylinder deadbolt.
4) Is the Callan 200S deadbolt strong enough for an apartment building or a commercial entrance?
The 200S is a Grade 3 residential deadbolt. Grade 3 is the entry-level ANSI/BHMA tier, sized for single-family and light residential use, not for a commercial opening or a high-traffic multi-family entry. For those doors, step up: ZenSupply carries the Cal-Royal CB160 in Grade 2 and the Cal-Royal CRB800 in Grade 1 heavy duty, plus the Dexter DB1000 Series Grade 1 single cylinder. Use the 200S on unit doors and houses where the finish match to the Callan trim is what matters.
5) What deadbolt should replace the Callan 200S on a fire rated opening?
The Callan 200S is a Grade 3 residential deadbolt. Where the opening is fire rated, the Hager 3215 is a single cylinder deadbolt with a 1 inch throw carrying a fire rating and fitting doors 1-3/8 inch to 1-3/4 inch, and the Hager 3115 is a cylinder x thumbturn deadbolt with a Schlage C keyway, also fire rated across the same door thickness range. The Cal-Royal CRB800 is a heavy duty single cylinder deadbolt with a UL 3-hour fire rated latch and cylinder x thumbturn function.
6) What is the closest Grade 3 single cylinder deadbolt to the Callan 200S if a different brand is needed?
The Cal-Royal ED500 and the Cal-Royal LSD are both Grade 3 single cylinder deadbolts with cylinder x thumbturn function, the same grade and function as the Callan 200S. The ED500 is from the Chelsie ED Series with an adjustable backset and fits doors 1-3/8 inch to 1-3/4 inch; the LSD is from the Chelsie LSD Series with an ADA ergonomic thumbturn and covers the same 1-3/8 inch to 1-3/4 inch door thickness. Either keeps the keyed-outside, thumbturn-inside operation a residential entry door needs.
7) What single cylinder deadbolt should be used instead of the Callan 200S on a commercial opening that requires a higher ANSI grade?
The Callan 200S is a Grade 3 residential deadbolt. Where a project calls for a higher grade with the same cylinder x thumbturn operation, the Accentra D111 is Grade 1 with a 2-3/8 inch backset and fits doors 1-3/8 inch to 1-3/4 inch, the Dexter DB1000 single cylinder is Grade 1 covering 1-3/8 inch to 1-7/8 inch doors, and the Deltana CL200LM is a Grade 1 single cylinder deadbolt. For Grade 2, the Dexter DB2000 single cylinder covers 1-3/8 inch to 1-3/4 inch doors and the Cal-Royal CB160 adds a tamper-resistant cylinder guard.
8) Which deadbolt replaces the Callan 200S when the opening needs a key on both sides instead of a thumbturn?
The Callan 200S is single cylinder, keyed outside with a thumbturn inside. Where a double cylinder is required, the Dexter DB1000 double cylinder is Grade 1 for doors 1-3/8 inch to 1-7/8 inch, the Dexter DB2000 double cylinder is Grade 2 for 1-3/8 inch to 1-3/4 inch, the Delaney LU Series 320601 is Grade 2 in a stainless steel US32D finish, and the Deltana 7312KA2 is Grade 3 covering 1-3/8 inch to 2 inch doors. Note that a double cylinder requires a key to exit, so confirm the local egress code for the occupancy before specifying one.
9) Is a mortise deadlock like the Corbin Russwin DL3011 a substitute for the Callan 200S?
No. The Callan 200S is a bored deadbolt with a cylinder outside and a thumbturn inside, prepped into a standard bored door. The Corbin Russwin DL3011 is a Grade 1 cylindrical deadlock in cylinder x blank configuration for doors 1-3/4 inch to 2-1/4 inch, and the DL3211 is the same cylinder x blank arrangement for 1-3/4 inch doors. Cylinder x blank means there is no inside thumbturn, so the door cannot be unlocked from the secure side without a key. Emtek's 2050 and 2051 are European mortise deadbolts with an integrated roller latch, which need a mortise pocket rather than a bored prep.
10) The Callan 200S takes SC1 or KW1 keyways - what is the option if the building is keyed to an interchangeable core system?
The Callan 200S is ordered with an SC1 5-pin or KW1 5-pin keyway. For an interchangeable core system, the Deltana CL200LAIC is a Grade 2 single cylinder deadbolt prepped for an interchangeable core, less cylinder, with a 2-3/4 inch backset. The Arrow E61 is a Grade 2 single cylinder deadlock with SFIC prep less core for doors 1-3/8 inch to 1-3/4 inch, and the Delaney LM Series 301702 is a Grade 1 single cylinder less core deadbolt in dull chrome US26D. These accept the facility's existing core rather than a factory keyway.
11) Which deadbolt has an easier thumbturn to operate than the Callan 200S for accessibility requirements?
The Callan 200S has a standard thumbturn on the inside. Where an accessible turn is called for, the Cal-Royal LSD is a Grade 3 single cylinder deadbolt with an ADA ergonomic thumbturn, cylinder x thumbturn function, and a 1-3/8 inch to 1-3/4 inch door thickness range, which puts it at the same grade and function as the 200S with a turn shaped for limited grip.
12) Does the Callan 200S deadbolt come with a strike plate and screws, or do I need to buy those separately?
Everything for the strike side ships with it. The 200S includes a high security strike plate and 3 inch strike plate security screws, which are the long screws that reach past the jamb into the framing stud, where a kick-in actually gets stopped. You do not need to source a reinforced strike separately. It also includes a protective collar over the cylinder and interlocking installation guides that hold the two halves in alignment while you set the screws.
13) Can someone get out fast in a fire with the Callan 200S deadbolt locked?
Yes. The inside face of the 200S is a thumbturn, so it unlocks by hand with no key, which is what you want on an egress door in an emergency. That is the practical argument for single cylinder over a keyed-both-sides bolt on any door people exit through. If you need a keyless bolt with no exterior cylinder at all, the Arrow E60 is a blank plate by thumbturn exit deadlock.
14) I need a deadbolt with an adjustable backset because I do not know the bore spacing on the door. Is the Callan 200S the one?
Pick a stated-adjustable model instead. ZenSupply carries the Cal-Royal ED500, a Grade 3 single cylinder deadbolt with an adjustable backset for 1-3/8 to 1-3/4 inch doors, and the Brinks Mendocino Series square single cylinder with a 4-way adjustable backset. Adjustable backset covers both 2-3/8 and 2-3/4 inch bore-to-edge spacing, which is what saves you a return when you are ordering blind for an existing door.
15) I am standardizing deadbolts across a portfolio of rental units. Does the Callan 200S work for that?
For unit entry doors it does, and the keying is the part that makes it work at scale: order every one in the same keyway, SC1 or KW1 5-pin, and use Keyed Alike where you want a shared key across a building or Keyed Different where each tenant gets their own. Finish is fixed to three choices, US15 Satin Nickel, US19 Black, and US10BE Edged Bronze, so pick one and hold it across the portfolio. It is a Grade 3 residential bolt, so for shared building entrances and back-of-house doors move to a Grade 2 or Grade 1 model such as the Cal-Royal CB160 or the Dexter DB1000 Series.
16) What matches the square trim of the Callan 200S if a square deadbolt from another line is wanted?
The Callan 200S carries square trim with an enlarged back plate. Squared alternatives include the Bravura 310SC Elite, a Grade 2 contemporary square deadbolt with cylinder x thumbturn, the Brinks Mendocino Series E2402, a contemporary square single cylinder deadbolt with a 4-way adjustable backset, and the Baldwin Reserve DC.CSD, a contemporary square deadbolt in double cylinder function. Of those, the 310SC and the Mendocino keep the same keyed-outside, thumbturn-inside operation as the 200S.
17) Is the Arrow E60 exit deadlock an alternative to the Callan 200S?
They serve different openings. The Callan 200S is keyed on the exterior with a thumbturn inside. The Arrow E60 is a Grade 2 exit deadlock that is non-keyed, with a blank plate outside and a thumbturn inside, for doors 1-3/8 inch to 1-3/4 inch. It secures a door that is never operated by key from the outside, so it is not a swap for an entry door that has to be unlocked with a key.
18) What is an alternative to the Callan 200S if the deadbolt needs to be keyless or electronic?
The Callan 200S is a mechanical key-operated deadbolt. For code or credential entry instead, the Delaney KP400 is a Grade 2 electronic deadbolt with a programmable remote, the Codelocks CL2200 is an electronic surface deadbolt in a brushed steel finish rated medium duty, and the Codelocks CL2210 is an electronic mortise deadbolt. The Dormakaba Saffire LX-D is an RFID electronic deadbolt with BLE and electronic lock override.
19) What round trim deadbolts are comparable to the Callan 200S for doors where a square plate does not suit the existing hardware?
The Callan 200S carries square trim. Where round trim matches the rest of the door hardware, the Bravura 310B Elite is a Grade 2 traditional round deadbolt with cylinder x thumbturn, the Bravura 310RC Elite is a Grade 2 contemporary round deadbolt with the same function, and the Brinks Raleigh Series E2401 is a transitional round single cylinder deadbolt with a 4-way adjustable backset. The Bravura Rectangle Deadbolt BV910005 is a Grade 2 single cylinder in a rectangular trim if neither round nor square fits the look.
20) Is a classroom function deadbolt the same as the Callan 200S single cylinder function?
No. The Callan 200S is single cylinder with a thumbturn inside that unlocks without a key for quick exit. The Falcon D111 is a Grade 1 classroom deadbolt with adjustable backset, rated heavy duty, and the Falcon D211 is the Grade 2 classroom function version with single cylinder operation, rated medium duty; the Hager 3118 is a Grade 1 classroom deadbolt with a Schlage C keyway and 6-pin cylinder for doors 1-3/8 inch to 1-3/4 inch. Classroom function is a keyed control arrangement for institutional openings, not the residential key-outside, turn-inside pattern of the 200S.
21) Which deadbolts fit thicker doors than the Callan 200S range typically covers?
For doors thicker than a standard residential leaf, the Corbin Russwin DL3011 is a Grade 1 cylindrical deadlock covering 1-3/4 inch to 2-1/4 inch, and the Deltana 7312KA2 is a Grade 3 double cylinder covering 1-3/8 inch to 2 inch. The Dexter DB1000 single cylinder reaches 1-7/8 inch while keeping the same cylinder x thumbturn operation as the Callan 200S, which makes it the closest option when the door is only slightly over standard.
22) Is the Arrow 460 strike a replacement part for the Callan 200S?
No. The Callan 200S ships with its own high security strike plate and 3 inch security screws. The Arrow 460 is a mortise lock strike for latchbolt and deadbolt functions with a straight lip, sized for 1-3/4 inch doors, and it serves a mortise lock body rather than a bored deadbolt. Similarly, the Baldwin Reserve 8BR0618001 is a deadbolt spacer for double cylinder applications and the BEST 8T is a T Series tubular deadbolt tube component, both parts of another assembly rather than a complete deadbolt.
23) Does the Callan 200S deadbolt need a specific handing when I order it?
No handing to specify. The 200S is a bored deadbolt, cylinder outside and thumbturn inside, so it drops into the cross bore either way the door swings. The two things you do have to specify are keyway (SC1 or KW1 5-pin) and keying (Keyed Different or Keyed Alike), and both are required on the order.
24) Can a deadbolt be added to a door that already has an entry knob instead of using the Callan 200S separately?
The Callan 200S is a standalone deadbolt intended to pair with matching entry knobs or levers on a second bore. If a single unit is preferred, the Falcon H2101 is a Grade 2 entrance interconnected lock that combines a single cylinder deadbolt with the entry trim in one device. The Baldwin Estates 8011 is a 1-5/8 inch contemporary double cylinder deadbolt in entrance function for doors where a separate deadbolt is still wanted.
