Callan Sawyer Passage Door Knobset
Passage Function: Passage lever sets have no locking function and are free turning on both sides. These are perfect for a hallway or closet where no locking is necessary.
Features:
- Meets BHMA security grade 2 requirements
- Made of durable zinc
- Fully reversible handing for left or right handed applications
- Designed for an easy one person installation
- Comes standard with a round corner latch faceplate and 1/2" throw
- Includes a limited lifetime warranty on mechanical parts and a five year warranty on finish
Specifications:
- Backset: Adjustable 2-3/8" or 2-3/4"
- Cross Bore: 2-1/8"
- Edge Bore: 1"
- Door Thickness: 1-3/8" to 1-3/4"
- Handing: Reversible Left or Right
- Projection: 2-5/8"
- Latch Faceplate: Round Corner
- Cylinder: 5 Pin KW1
- Concealed Screws: No
- Material: Zinc
Manufacturer Resources
Product Specs
- Subcategory:
- Bored Locksets
- Series:
- Sawyer
- Product Group:
- Mechanical Locks
- Product Subgroup:
- Bored Locksets
- Commercial/Residential:
- Residential
- Lock Function:
- Passage
- Product Type:
- Knobsets
- Grade:
- Grade 2
- Product Attribute:
- Cylindrical Locks
- Product Function:
- Passage/Hall/Closet
- Product Category:
- Mechanical Locks
- Department:
- Door Hardware
Callan G2KS1011 – Frequently Asked Questions
1) Will the Callan Sawyer passage knob fit a 1-3/8 inch interior door, or is it only for 1-3/4?
Both. The Sawyer passage knobset covers 1-3/8 inch to 1-3/4 inch doors, which spans the older interior slab doors in most houses and standard 1-3/4 inch doors. The backset is adjustable between 2-3/8 and 2-3/4 inches, so it drops onto either of the two common bore locations without ordering a specific latch.
2) Can I put a Callan Sawyer knobset into the existing holes in my door?
If the door is already bored for a standard cylindrical lock, yes. The Sawyer needs a 2-1/8 inch cross bore and a 1 inch edge bore, which is the standard prep on virtually every bored lockset door in North America. Measure the hole in the face of the door and the hole drilled in the edge; if they match those two numbers and the door is 1-3/8 to 1-3/4 inches thick, it goes straight in.
3) Do I have to order a Callan Sawyer passage knob left hand or right hand?
No handing to specify. The Sawyer passage set is fully reversible and works on a left or right hand door as it comes out of the box, so one part number covers every opening in a building. Pick the finish and that is the whole order decision.
4) Does a passage knob lock, or do I need a privacy set for a bathroom?
A passage set does not lock. The Sawyer turns freely from both sides and has no button, no key, and no cylinder, which is what you want on a hallway, closet, or pantry door. For a bathroom or bedroom you need a privacy function with a push button inside and an emergency release outside. If the door needs a key, that is an entrance function instead.
5) Will the Callan Sawyer latch catch in the strike plate that is already in my door frame?
The Sawyer uses a 1/2 inch throw latch with a round corner faceplate, which is the standard residential bored-lock latch. It lines up with the ordinary round-corner strike already mortised into most frames. If your existing latch faceplate has square corners, the new faceplate will not sit in the same mortise cleanly and you will want to swap the strike or file the mortise.
6) What is the commercial equivalent of a Callan Sawyer passage knob for a school or office?
For an institutional opening, the Corbin Russwin CK4410 is a Grade 2 passage cylindrical knob covering the same 1-3/8 to 1-3/4 inch doors, and the Falcon W101 is a Grade 2 passage knob that carries a fire rating. If the spec calls for Grade 1, the Corbin Russwin CK4310 handles doors up to 2 inches thick and the Falcon X101 goes to 2-1/4 inches with an interchangeable core. The Sawyer is a residential-grade set and is the wrong choice where a commercial spec is written.
7) My door is 2 inches thick - which passage knob covers it if the Callan Sawyer does not?
The Sawyer is built for 1-3/8 inch to 1-3/4 inch doors. For a 2 inch door, the Corbin Russwin CK4310 Grade 1 passage/closet knob covers 1-3/8 inch to 2 inch, and the Falcon X101 Grade 1 passage knobset covers 1-3/8 inch to 2-1/4 inch. The Lockey 3830 keyless combination knob lock with auto-locking passage function covers 1 3/16 inch to 2 inch.
8) What is the closest Grade 2 passage knob equivalent to the Callan Sawyer passage knobset?
The Dexter C2000 Series Grade 2 passage cylindrical ball knob lock is the nearest match: same Grade 2 rating, same passage/hall/closet function, non-keyed, and the same 1-3/8 inch to 1-3/4 inch door thickness range the Sawyer covers. The Corbin Russwin CK4410 is a second Grade 2 passage knob with that same 1-3/8 inch to 1-3/4 inch range. Both drop into the same non-locking hallway or closet opening the Sawyer is built for.
9) I need a fire rated passage knob for a rated corridor door - can I use the Callan Sawyer?
For a fire rated opening, specify a knob that carries the rating. The Falcon W101 is a Grade 2 medium duty cylindrical passage/closet knob lock with a fire rating and a 2-3/4 inch backset, and the Falcon X101 is a Grade 1 heavy duty fire rated passage knobset. The Sawyer is a Grade 2 residential passage set with an adjustable 2-3/8 inch or 2-3/4 inch backset.
10) The door needs to lock - what is the keyed or privacy version to order instead of the Callan Sawyer?
The Sawyer has no locking function, so pick by what the room needs. For a bed or bath thumbturn, the Dexter C2000 Grade 2 privacy knob and the Pamex FTF Grade 3 Baron privacy knob both cover 1-3/8 inch to 1-3/4 inch doors. For a keyed opening, the Dexter C2000 Grade 2 entry/office keyed ball knob takes the same thickness range, and the Sargent 6G04 is a Grade 2 storeroom/closet knob with a single cylinder.
11) What finishes does the Callan Sawyer passage knob come in, and can I match the rest of my hardware?
Five finishes: US15 satin nickel, US3 bright brass, US5 antique brass, US10BE edged bronze, and US19 black. Those are the standard BHMA finish codes, so if the knobs already on your other doors are marked US15 or US3 you can order to match without guessing at a marketing name.
12) Is a Grade 2 zinc passage knob good enough for an apartment building corridor or rental turnover?
The Sawyer meets BHMA Grade 2 and is built from zinc, which puts it above the Grade 3 hardware sold for light residential use and makes it reasonable for apartment interiors, closets, and rental turnovers. It is catalogued as residential, so for a high-traffic commercial corridor look at a Grade 1 passage set like the Schlage D10S or the Falcon X101 instead.
13) What else do I need to buy to install a Callan Sawyer passage knob?
Nothing beyond the set itself for a door already bored. The Sawyer ships with its adjustable latch and round corner faceplate and is put together for one person to install, so a screwdriver does the job. On an unbored door you will need a 2-1/8 inch hole saw and a 1 inch spade bit to cut the standard prep.
14) Can I get the Callan Sawyer knob keyed to my Kwikset keys?
Not in passage function, because a passage set has no cylinder at all. The Sawyer family does use a 5 pin KW1 cylinder in its keyed functions, so if you are standardizing a building on Kwikset KW1 keys the keyed Sawyer sets will follow that keyway while the passage doors take this non-keyed version.
15) I need matching passage knobs for a whole floor of closet and hall doors. Is the Callan Sawyer a good fleet choice?
It works well for that. One reversible part number covers every door regardless of swing, the backset adjusts to 2-3/8 or 2-3/4 so you are not sorting doors by bore location, and the five finishes let you standardize the building on one code. Straight substitutes at the same Grade 2 passage function include the Dexter C2000 passage ball knob and the Bravura Albany, both covering the same kind of interior opening.
16) What is the difference between a passage knob like the Callan Sawyer and a dummy knob?
A passage knob has a working latch and turns freely on both sides with no locking function - the Sawyer is that type, with a round corner latch faceplate and 1/2 inch throw. A dummy knob has no latch at all and mounts as surface trim on an inactive leaf or a closet door pulled shut by a catch. Dummy examples include the Schlage A170 single dummy trim, the BEST 6K single dummy trim, and the Bravura Biloxi dummy knobset. Order a dummy only where nothing needs to latch.
17) Is there a lighter duty passage knob than the Callan Sawyer for low traffic interior doors?
The Pamex FTF Baron passage knob lockset is a Grade 3 passage knob covering 1-3/8 inch to 1-3/4 inch doors, one grade below the Sawyer's Grade 2. Kwikset also offers the 200P Polo passage knob for interior hall and closet doors, supplied with a 6AL latch and RCS round corner strike, and the 200P-CP with a round corner adjustable latch and round corner strike. Grade 3 sets are specified for lighter residential traffic.
18) What decorative passage knobs can I use in place of the Callan Sawyer on a traditional interior door?
For a traditional look with the same passage function, the Baldwin Estate 5011 Colonial passage knob with 5058 rose and the Baldwin Estate 5000 Baltimore knob with 5048 rose passage lock, supplied with a 2-3/8 inch backset and full lip strike, are both passage sets. The Omnia 434/PA is a traditional egg-shaped knob latchset with solid brass construction and a 3 inch projection. The Sawyer is zinc with a 2-5/8 inch projection and an adjustable 2-3/8 inch or 2-3/4 inch backset.
19) Can the Arrow MK01 or RK01 replace a Callan Sawyer passage knob on the same door prep?
Both are Grade 2 non-keyed passage/hall/closet cylindrical knob locks rated for 1-3/8 inch to 1-3/4 inch doors, the same thickness range the Sawyer covers, so they suit the same interior openings. The RK01 uses a ball knob; the MK01 is the MK Series knob. Confirm the backset your prep uses - the Sawyer ships adjustable for 2-3/8 inch or 2-3/4 inch.
20) How far does the Callan Sawyer knob stick out from the door face?
Projection is 2-5/8 inches off the face of the door. That matters where the door swings back against a wall, next to a cabinet, or into a tight corridor, and it matters if you are matching the reveal of knobs already installed elsewhere in the unit.
21) Are the screws visible on the Callan Sawyer knob rose?
Yes, the mounting screws show on the rose. There are no concealed screws on the Sawyer. If the look matters on a front-of-house door, a decorative line such as the Baldwin Estate 5011 Colonial passage knob is the direction to go; for closets and back hallways the exposed screws also mean the set comes apart with a screwdriver when a tenant changes.
22) Which other Grade 2 passage knobsets come in a range of decorative trims like the Callan Sawyer?
Bravura offers several Grade 2 passage knobsets by trim shape: the Albany with round trim, the Lynchburg with round trim, and the Dallas with rectangle trim in a US4 satin brass finish. All three are passage/hall/closet function like the Sawyer, which is offered in US15 satin nickel, US3 bright brass, US19 black, US5 antique brass, and US10BE edged bronze.
