Catamount TV14-6LF-XV Vinyl Locking Fork Terminal, 16-14 AWG, Blue, Pack of 100

Catamount TV14-6LF-XV Vinyl Locking Fork Terminal, 16-14 AWG, Blue, Pack of 100

(No reviews yet) Write a Review

Model: TV14-6LF-XV

In Stock (leaves warehouse same day if ordered before 3pm ET)

$49.36
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Catamount TV14-6LF-XV Vinyl Locking Fork Terminal, 16-14 AWG, Blue

The Catamount TV14-6LF-XV is an insulated vinyl locking fork terminal engineered for wire range 16-14 AWG with a #6 stud size, sold under the Sta-Kon brand and finished in blue vinyl insulation for easy wire-gauge identification. Constructed with a copper barrel for reliable conductivity, this locking fork terminal features a molded funnel entry insulator, a brazed seam, and internal barrel serrations to secure the conductor and resist pull-out. Rated up to 600V, it is well suited for control panels, machine wiring, and general electrical connector applications where a vibration-resistant, positive-locking termination is required. Each unit is sold individually and packaged in a canister of 900 pieces for high-volume assembly and maintenance use.

Key Features

  • Wire Range: Accommodates 16-14 AWG conductors for a secure, code-appropriate crimp connection.
  • Stud Size: #6 stud size fork terminal for compatibility with standard terminal blocks and studs.
  • Durable Construction: Copper barrel construction delivers reliable conductivity and long-term connection integrity.
  • Locking Fork Design: Locking fork tongue helps retain the connection on the stud and resists loosening from vibration.
  • Molded Funnel Entry Insulator: Guides wire strands into the barrel for a clean, consistent crimp every time.
  • Brazed Seam: Brazed barrel seam adds strength and resists separation under stress.
  • Internal Barrel Serrations: Internal serrations grip the conductor strands for a secure mechanical and electrical connection.
  • Voltage Rating: Rated 600V for demanding electrical connector applications.
  • Color-Coded Insulation: Blue vinyl insulation provides quick visual identification of wire gauge range.

Technical Specifications

  • Product Name: ELECTRICAL CONNECTOR,<1000V
  • Product Type: Vinyl Insulated Locking Fork Terminal
  • Material: Copper
  • Wire Size: 16-14 AWG
  • Stud Size: #6
  • Voltage Rating: 600V
  • Color: Blue
  • Selling Unit of Measure: Each
  • Packaging: 900 piece canister
  • Country of Origin: Taiwan, Province Of China (TW)
  • Brand / Label: Sta-Kon
  • Sub Brand / Label: Catamount

Typical Applications

  • Control Panel and Machine Wiring
  • Terminal Block Connections
  • Industrial Electrical Assemblies
  • Panelboard and Equipment Grounding Hookups
  • General Purpose Electrical Connector Applications

Why Catamount?

Catamount vinyl locking fork terminals combine a copper barrel, brazed seam, and internal serrations with a molded funnel entry insulator to deliver a dependable, vibration-resistant termination for demanding electrical work. Backed by the Sta-Kon connector line and rated to 600V, these terminals are built for professionals who need consistent, code-compliant connections across control panels and industrial assemblies.

Manufacturer Resources

Product Specs

Idea Granular Category Code Igcc:
4603 >> Electrical terminals
Wire Size:
16-14 AWG
Effective Date:
20090414
Selling Unit Of Measure:
each
Product Name:
ELECTRICAL CONNECTOR,<1000V
Weee Category:
Product Not in WEEE Scope
Product Type:
Fork Terminal
Voltage Rating:
600V
Sub Brand Label:
Catamount
Brand Label:
Sta-Kon
list_batch:
CTM-20260924
Department:
Electrical
Product Subgroup:
Lugs & Terminals
Product Material:
Copper
Product Color:
Blue
Pack size (unit):
100
Product Group:
Wire Connectors & Terminals

Catamount TV14-6LF-XV – Frequently Asked Questions

1) Will the Catamount TV14-6LF-XV fork terminal work on 16 and 14 gauge wire?
Yes. The TV14-6LF-XV is rated for 16-14 AWG stranded copper conductors, and the blue vinyl insulation is the standard color code for that gauge band, so an inspector or the next tech can read the range off the terminal without a chart. Internal barrel serrations grip the strands once crimped. For 22-16 AWG you need a red-insulated terminal instead, and for 12-10 AWG a yellow one.
2) What stud size does this blue locking fork terminal fit?
It is built for a #6 stud. The fork slips over a #6 screw or stud on a terminal block without removing the screw completely, and the locking tongue then captures it so the terminal cannot back off the stud under vibration. A larger stud, #8 or #10, needs the matching larger fork or a ring terminal.
3) Locking fork vs. standard fork vs. ring terminal, which should I use in a control panel?
A standard fork (spade) is the fastest to service because it slides on and off under a loosened screw, but it can walk off a vibrating stud. The locking fork used here keeps that slide-on advantage and adds a tongue that grips the stud, so it holds on machine wiring and panels that see vibration. A ring terminal is the most secure of the three but the screw has to come all the way out to change a wire. For control panels and machine wiring where you want serviceability plus vibration resistance, the locking fork is the middle ground.
4) Is this terminal rated for 600 volt control wiring?
Yes, the TV14-6LF-XV carries a 600V rating, which covers standard 120/208, 277 and 480 volt control and power circuits in panels and industrial assemblies.
5) Is the barrel on this fork terminal copper or steel?
Copper, with a brazed seam rather than a butted one. Copper keeps the connection conductive and matches the copper conductor it is crimped onto, avoiding the dissimilar-metal issue you get with plated steel barrels. The brazed seam is what keeps the barrel from splitting open under crimp pressure or a pull on the wire.
6) Do I need a special crimper for these insulated Sta-Kon fork terminals?
These are insulated vinyl barrel terminals, so they take an insulated-terminal crimper sized for the blue 16-14 AWG nest, not an open-barrel or non-insulated die. The molded funnel entry insulator feeds the strands into the barrel so nothing strays outside the crimp, but the crimp itself still has to be made with the correct color-coded nest to get full pull-out strength.
7) How many terminals come in a pack of the Catamount TV14-6LF-XV?
Pack size is 100 pieces of the blue #6 locking fork terminal. Selling unit of measure is each, so a quantity of 1 is one terminal and the 100 count is how they are bagged for panel build-out or MRO stock.
8) Is this a Catamount terminal or a Sta-Kon terminal?
Both names apply to the same part. TV14-6LF-XV is sold under the Sta-Kon connector line with Catamount as the sub brand, so a spec calling out either name is pointing at this terminal. Order by the part number TV14-6LF-XV to avoid confusion.
9) Can I use these fork terminals for equipment grounding connections in a panelboard?
Yes, panelboard and equipment grounding hookups are among the intended uses, provided the ground conductor is 16-14 AWG and the grounding screw or stud is a #6. On larger ground conductors you need a bigger lug, not this terminal.
