Klein Tools 50122 Conduit Measuring Pull Tape, 1250-Pound x 2000-Foot

Klein Tools 50122 Conduit Measuring Pull Tape, 1250-Pound x 2000-Foot

(No reviews yet) Write a Review

Model: 50122
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$208.57
$158.57
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Conduit Measuring Pull Tape, 1250-Pound x 2000-Foot

  • Warnings

    • Not for overhead lifting.
    • For wire and cable installation only.
    • Knots in line can significantly reduce tensile strength.
    • Do not use on live circuits. Tape can wick moisture and become conductive.

  • Features

    • Hole in bucket lid for controlled, tangle-free dispensing
    • Additional pull tape tensile strengths and lengths available
    • Tangle-Free Dispensing with Hole in Bucket Lid
    • Pre-lubricated to reduce friction
    • Bucket provides easy storage and transport
    • 1250-Pound (567 kg) tensile strength
    • Tape is marked with easy-to-read, descending 1-Foot increments to measure conduit runs and determine the amount of tape left to pay out
    • Pull Tape is a woven, flat polyester strapping that disperses pull load and minimizes stretching when pulling


50122 - spec sheet

Manufacturer Resources

Spec Sheet

Product Specs

Container:
Orange Bucket with Lid and Handle
Item Depth:
11.0000 in
Item Height:
11.0000 in
Item Weight:
16.6000 lbs
Item Width:
11.0000 in
Overall Length:
2000' (609.6 m)
Overall Width:
0.49" (1.2 cm)
Tensile Strength:
1250 lb (567 kg)
Department:
Electrical
Product Group:
Electrical Installation Tools
Product Subgroup:
Cable Pullers
Product Type:
Pre-Lubricated, Flat Pull Tape with 1' Markings
Product Details:
Pre-Lubricated, Flat Pull Tape with 1' Markings
Product Color:
White Tape with Black Markings
Product Weight:
16.6 lb (7.5 kg)
Product Depth:
11 in
Product Height:
11 in
Product Width:
11 in

Klein Tools 50122 – Frequently Asked Questions

1) Can I use Klein 50122 pull tape to measure a conduit run while I pull it?
That's what the markings are for. The 50122 tape is printed with descending 1-foot increments, so as you blow or fish it through the run you can read the footage off the tape and know both how long the run is and how much tape is still in the bucket. The full reel is 2000 feet (609.6 m), and because the numbers descend you are reading remaining tape, not elapsed tape.
2) Can I pull this tape in a panel or raceway that still has power on it?
No. Do not use this tape on live circuits. Polyester tape can wick moisture and become conductive, so it is not a safe barrier. De-energize and lock out before you pull.
3) Is flat pull tape better than rope or fish tape for a long conduit run?
Flat woven polyester tape like the Klein 50122 spreads the pull load across its width instead of concentrating it like a round rope, and it stretches less under tension. At 0.49 inch (1.2 cm) wide it also lies against the conduit wall rather than cutting into the cable jacket. For long runs you blow or vacuum the tape through, then use it to pull your line. A steel or fiberglass fish tape is still the better tool for short runs where you need to push the leader through by hand.
4) Do I need to add cable-pulling lube with this tape?
The 50122 tape comes pre-lubricated to cut friction in the conduit, so for a straightforward run you are not adding lube to the tape itself. Pulling compound on the cable is still a separate decision based on the cable, the number of bends, and the run length.
5) How does 2000 feet of pull tape ship, and will it tangle on the job?
It comes in an orange bucket with a lid and handle, and the lid has a dispensing hole so the tape pays out controlled and tangle-free without you opening the pail. The bucket measures 11 inches in height, width, and depth and the whole package weighs 16.6 lb (7.5 kg), so one hand carries it to the pull box.
6) What is the Klein part number for the 1250-pound, 2000-foot pull tape?
Klein Tools 50122 is the 1250 lb x 2000 ft pre-lubricated flat measuring pull tape in the bucket. Klein offers the same style of tape in other tensile strengths and lengths, so if 1250 lb or 2000 ft is not the combination you need, the part number changes.
7) Are the footage markings easy to read in a dark pull box?
The tape is white with black markings, which is the highest-contrast combination Klein offers on this line and readable under a work light in a vault or pull box. Markings run in 1-foot increments down the full 2000-foot length.
