Corbin Russwin 586L19M020 T-Curved Lip Strike for CLX3300, 1-1/4in Lip Length

Corbin Russwin 586L19M020 Grade 1 T-Curved Lip Strike for CLX3300, 1-1/4in Lip Length

(No reviews yet) Write a Review

Model: 586L19M020-626
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$39.68
$19.09
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Corbin Russwin 586L19M020 T-Curved Lip Strike for CLX3300 Series Cylindrical Lever Locksets, 1-1/4" Lip Length, Brass

Commercial-Grade Replacement Curved Lip Strike for CLX3300 Series Locksets

The Corbin Russwin 586L19M020 is a T-Curved Lip Strike engineered as a precision replacement part for CLX3300 Series Cylindrical Lever Locksets. Constructed from brass, this strike features overall dimensions of 2-3/4" (70mm) x 1-1/8" (29mm) with a 1-1/4" (32mm) lip to center measurement, ensuring accurate fitment and reliable door latch engagement in commercial applications. Designed as a direct replacement component, it is available in a wide range of optional lip lengths to accommodate varied door frame conditions.

Professional Features & Benefits

  • ANSI/BHMA Grade 1 cylindrical lock per A156.2 (2022) Series 4000
  • UL Cycle above and beyond: 20 Million Cycles (Verification ID: V875753)
  • Exceeds 3,100 in-lb abusive locked lever torque — 2.6× ANSI requirements
  • Exceeds 1,600 lbs offset lever pull — 8× ANSI requirements
  • Innovative Lever Release™ freewheeling design for vandal resistance
  • Lock chassis design supports all cylinder formats (fixed core to interchangeable core)
  • Patented adjustable push/turn button for easy door thickness adjustment
  • Available with BHSS behavioral health trim and VSL visual status indicators
  • EcoFlex® technology on CLX33900: up to 92% energy reduction (GreenCircle certified)
  • Available with 27 mechanical and 2 electrified functions
  • CLX3352 Classroom Intruder: locking from either side, always-free egress
  • ElectroLynx® 8-pin molex connector on electrified units
  • Ten-year limited mechanical warranty (two-year limited electrical)

Technical Specifications

  • Grade: ANSI/BHMA A156.2 (2022) Series 4000, Grade 1
  • Door Prep: ANSI/SDI A250.14
  • Handing: Non-handed
  • Door Thickness: 1-3/4" 2" (44–51mm) standard; optional 1-3/8" (D138) or over 2" up to 2-1/4" (D214)
  • Backset: 2-3/4" (70mm) standard; optional 2-3/8", 3-3/4", 5"
  • Minimum Stile: 4-1/2" (114mm)
  • Latchbolt: Stainless steel, 1/2" (13mm) throw; optional 3/4" (19mm) deadlocking fire latch
  • Front: Wrought brass, bronze, or stainless steel, 2-1/4" x 1-1/8" standard
  • Strike: Wrought brass or stainless steel, ANSI curved lip, 4-7/8" x 1-1/4" x 1-1/4" lip to center
  • Cylinder: Brass, 6-pin L4 keyway, 0-bitted standard
  • Electrified Voltage: 12VDC or 24VDC; range 10.2–26.4VDC (CLX33900)
  • Electrified Current: 10mA continuous; 500mA peak @ 12VDC or 24VDC
  • Operating Temperature: -13°F (-25°C) to 151°F (66°C) (electrified)
  • Certifications: ANSI/BHMA A156.2 Grade 1; UL/cUL 3-hour; UL294 (electrified); NFPA 80; ADA A117.1; Windstorm/Hurricane certified
  • Warranty: Ten-year limited mechanical; two-year limited electrical

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Choose Corbin Russwin Quality?

Corbin Russwin door hardware components deliver professional-grade reliability through precision brass construction and exact dimensional tolerances, ensuring proper fitment and long-term performance in commercial applications. The 586L19M020 T-Curved Lip Strike is engineered specifically for CLX3300 Series Cylindrical Lever Locksets, providing a dependable replacement solution with a broad selection of lip lengths to suit varied installation requirements. Engineered for demanding commercial environments where consistent, reliable door hardware performance is essential.

Product Specs

Product Group:
Parts and Accessories
Product Subgroup:
Parts and Accessories
Product Type:
Strikes
Commercial/Residential:
Commercial
Subcategory:
Parts and Accessories
Parts and Accessories Type:
Replacement Parts
Product Attribute:
Parts and Accessories
Product Model:
586L19M020
Product Length:
1-1/4"
Strike Classification:
Curved Lip Strike
Product Category:
Mechanical Locks
Department:
Door Hardware

Corbin Russwin 586L19M020-626 – Frequently Asked Questions

1) What lock does the Corbin Russwin 586L19M020 strike fit?
It's the curved lip strike for Corbin Russwin CLX3300 Series cylindrical lever locksets. It's sold as a replacement part, so if you're rebuilding or repairing a CLX3300 lever lock and the strike is bent, worn, or the wrong lip length for the frame, this is the piece that goes back in the jamb.
2) What does the 1-1/4 inch lip length on this Corbin Russwin strike mean, and how do I know it's the right one?
The 1-1/4 inch figure is the lip to center measurement, meaning the distance from the mounting centerline of the strike out to the end of the curved lip. You measure it on the jamb: from the center of the strike screw line to the face of the door stop or trim the latch has to clear. Corbin Russwin offers this strike in a range of optional lip lengths, so if your frame has deeper trim or the door sits proud, you order a longer lip rather than bending this one.
3) Is the 586L19M020 curved lip strike handed?
You do pick a hand when ordering. The curved lip wraps toward the stop on one side, so the strike has to match the swing of the door. Confirm which way your door swings before you order, because a left hand strike on a right hand opening puts the lip on the wrong side of the latch.
4) Can an Adams Rite 4901 strike be used in place of the Corbin Russwin 586L19M020 curved lip strike?
No. The Corbin Russwin 586L19M020 is a curved lip strike made as a replacement part for CLX3300 Series cylindrical lever locksets, with a 1-1/4 inch lip to center. The Adams Rite 4901 is a flush mount deadlatch strike with a dust box and steel mounting plate, designed for use with Adams Rite 4300, 4500, 4700, and 4900 Series deadlatches. The two serve different latch families and different frame preps, so they are not interchangeable.
5) What strike should I use on an aluminum storefront deadlatch instead of the Corbin Russwin 586L19M020?
The 586L19M020 is built for CLX3300 Series cylindrical lever locksets, not for narrow stile deadlatches. For an Adams Rite deadlatch opening, look at the Adams Rite 4901 flush mount deadlatch strike or the Adams Rite 4902 radius short strike, both of which come with a dust box and are intended for 4300, 4500, 4700, and 4900 Series deadlatches. Choose between them based on whether the jamb takes a flush face or a radius short strike.
6) I need a strike for a sliding door deadlock, not a lever lock. Is this it?
Not this one. The 586L19M020 is a curved lip jamb strike for a swinging door with a CLX3300 cylindrical lever lock. For sliding door deadlocks you want a reinforcing strike built for that hardware, the Adams Rite 4800 Series is the option of that type.
7) Will this strike work with a 3/4 inch fire latch on a CLX3300?
The CLX3300 latchbolt is 1/2 inch throw as standard, with an optional 3/4 inch deadlocking fire latch. The curved lip strike is the ANSI curved lip type used with the series either way, but on a rated opening the whole assembly, latch and strike, has to match what the door and frame were listed with. Order the strike in the finish and lip length that matches the existing lock rather than mixing types.
8) Is there a reinforcing strike comparable to the Corbin Russwin 586L19M020 for a sliding door deadlock?
Not a direct one. The Corbin Russwin 586L19M020 is a T-curved lip strike for CLX3300 Series cylindrical lever locksets and is offered in 612 satin bronze, 613E dark oxidized satin bronze equivalent, 626 satin chrome, and BSP black suede powder coat. For sliding door deadlocks, the Adams Rite 4800 Series reinforcing strikes are the applicable part; they address a sliding door deadlock jamb rather than a cylindrical lockset latch.
9) What material is the 586L19M020 strike made of?
Brass. Brass strikes hold up in commercial traffic and take the plated finishes cleanly, which is why the same part shows up in satin bronze and satin chrome as well as the powder coated black.
10) Is this strike suitable for a school or hospital corridor door?
Yes, it's a commercial part, used with the CLX3300 Series lock line that's rated ANSI/BHMA A156.2 (2022) Series 4000 Grade 1 and applied in educational, healthcare, office, retail, industrial, multi-tenant residential and government buildings. Brass construction and a curved lip that guides the latch home are what you want on a high traffic corridor opening.
