Corbin Russwin ED7000 Grade 1 Trim Stud

Corbin Russwin ED7000 Grade 1 Trim Stud

(No reviews yet) Write a Review

Model: 416F81-8

In Stock (leaves warehouse same day if ordered before 3pm ET)

$21.57
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Corbin Russwin 416F81-8 ED7000 Trim Stud for Crossbar Exit Devices

Commercial-Grade Exit Device Replacement Part for ED7000 Series

The Corbin Russwin 416F81-8 ED7000 Trim Stud is a purpose-built replacement component designed specifically for use with ED7000 Crossbar Exit Devices. This commercial-grade trim stud ensures proper trim attachment and secure operation within the ED7000 series exit device assembly. Sourced directly from Corbin Russwin, this part maintains the integrity and performance of your existing ED7000 hardware installation.

Professional Features & Benefits

  • Heavy-duty cold-forged steel chassis with electroplated corrosion resistance
  • Latchbolt: stainless steel pullman-type, 3/4" (19mm) throw with deadlocking auxiliary latch
  • Non-handed device (except double cylinder and lever trim which are handed)
  • Standard bar length 36" (fits 30"–36" doors); easily field cut; optional 24" or 48"
  • Standard single-point 1/4-turn hex key dogging on panic devices
  • Free Wheeling levers for vandal resistance on trim
  • SecureBolt® option (ED5200S): deadbolt-style latchbolt resists unauthorized entry
  • Electrified options including delayed egress, electric latch retraction, and electric dogging
  • UL-listed panic and 3-hour fire exit hardware; NFPA 101 and NFPA 80 compliant
  • Full range of trim with Muséo® and Vineyard™ collections
  • ADA compliant — lever trims and pulls comply with Americans with Disabilities Act
  • PathLite™ photoluminescent touchpad cover option available
  • Five-year limited warranty; ED5800 CVR certified to 3.25 million cycles

Technical Specifications

  • Grade: ANSI/BHMA A156.3 Grade 1
  • Handing: Non-handed standard (lever trim and double cylinder devices are handed)
  • Bar Length: 36" standard (fits 30"–36" doors); optional 24" or 48"
  • Door Thickness: 1-3/4" (44mm) standard; optional 2" (D200) or 2-1/4" (D214)
  • Minimum Stile Width: 4-1/2" (114mm)
  • Latchbolt — Rim (ED5200): Stainless steel pullman-type, 3/4" (19mm) throw with deadlocking auxiliary latch
  • Latchbolt — SecureBolt® (ED5200S): Deadbolt-style, 3/4" (19mm) projection x 1" wide, positive deadlocking by auxiliary bolt
  • Latchbolt — SVR (ED5400): Top: 3/4" throw pullman-type deadlocking; Bottom: 5/8" throw deadbolt
  • Projection: 3-1/4" (83mm) active; 2-3/4" (70mm) dogged
  • Dogging: Single-point 1/4-turn hex key; optional cylinder or electric dogging
  • Strike: Surface-mounted 3/8" roller strike with positive locking plate and shims
  • Certifications: ANSI A156.3 Grade 1; UL/cUL panic and 3-hour fire exit hardware; NFPA 101; NFPA 80; ADA; California State Fire Marshal approved
  • Warranty: Five-year limited

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Choose Corbin Russwin Quality?

Corbin Russwin exit device parts and accessories are engineered to deliver professional-grade reliability in demanding commercial environments. The ED7000 Trim Stud is a genuine OEM component, ensuring full compatibility and consistent performance with your existing ED7000 Crossbar Exit Device hardware. Trust Corbin Russwin for dependable door hardware solutions where precision fit and lasting durability are essential.

Product Specs

Product Group:
Exit Device Parts and Accessories
Product Subgroup:
Parts and Accessories
Product Type:
Trim Stud
Commercial/Residential:
Commercial
Subcategory:
Parts and Accessories
For Use With:
ED7000 Crossbar Exit Devices
Product Function:
Trim Stud
Department:
Door Hardware

Corbin Russwin 416F81-8 – Frequently Asked Questions

1) What is the Corbin Russwin 416F81-8 trim stud and what does it do?
It is the small threaded stud that carries the outside trim attachment on Corbin Russwin ED7000 crossbar exit devices. It is a genuine Corbin Russwin replacement piece, not a complete device or a trim set, so you order it when the stud is stripped, bent, or missing and the trim will no longer pull up tight to the device.
2) My door is thicker than standard. Does that change which trim stud I need?
Yes, door thickness drives stud length on a through-bolted trim. The standard build is 1-3/4 inch doors, with 2 inch (D200) and 2-1/4 inch (D214) thickness options offered on the device. Measure the leaf before ordering, because a stud cut for a 1-3/4 inch door will not pick up the trim on a 2-1/4 inch door.
3) Does the trim stud come with the lever trim or the exit device, or do I order it separately?
It is sold on its own as a replacement component. If you are rebuilding an ED7000 crossbar device, plan on ordering the trim itself, any cylinder, and the mounting screws separately; the stud only handles the trim-to-device connection.
4) Is a crossbar exit device the right choice, or should I be looking at a touchpad device?
Crossbar devices like the ED7000 are the traditional horizontal-bar style and are common on older commercial openings, which is why replacement parts such as this stud are still needed. If you are specifying new hardware instead of repairing, Corbin Russwin's touchpad devices cover rim (ED5200), SecureBolt (ED5200S) and surface vertical rod (ED5400) applications, with a 3/4 inch throw pullman latch on the rim device and a 5/8 inch bottom deadbolt on the SVR version for a pair of doors without a mullion.
5) Is this part suitable for a fire-rated opening?
Using genuine Corbin Russwin components is what keeps a listed assembly intact. The exit device families covered here are UL listed panic and 3-hour fire exit hardware, NFPA 101 and NFPA 80 compliant, ANSI/BHMA A156.3 Grade 1, and California State Fire Marshal approved. Substituting a non-OEM stud on a fire exit device is what puts that listing at risk.
6) What is the minimum stile width for these Corbin Russwin exit devices?
4-1/2 inches (114mm). On an aluminum storefront with a narrower stile than that, this device family is not the one to use; you need a narrow stile device instead.
7) Is the trim stud handed?
The crossbar and touchpad devices in this family are non-handed as standard, with lever trim and double cylinder devices being the handed exceptions. The stud itself is a trim attachment point and is ordered by part number, 416F81-8, not by hand.
8) How much does the exit device project off the door face when it is dogged down?
2-3/4 inches (70mm) dogged, versus 3-1/4 inches (83mm) active. That matters where the door swings into a corridor or against a wall and you are checking clear width.
How fast can I get the Corbin Russwin 416F81-8 delivered?
Most orders ship the same day from our distribution partners, with quick delivery throughout the continental U.S. Need it urgently? Contact Us for expedited shipping options.
