Corbin Russwin 148F22-8 Grade 1 ED7000 Pin

Corbin Russwin 148F22-8 Replacement Pin for ED7000 Crossbar and ED6400 Series Exit Devices

Commercial-Grade Replacement Pin for Exit Device Compatibility

The Corbin Russwin 148F22-8 is a commercial-grade replacement pin designed for use with Corbin Russwin ED7000 Crossbar Exit Devices, ED6400 Panic Exit Devices-Vertical Rod, and ED6400A Fire Exit Devices-Vertical Rod. This precision-manufactured pin component ensures proper function and reliable performance when servicing or maintaining compatible exit device assemblies. Corbin Russwin has been a recognized name in high-quality commercial-grade hardware for commercial and institutional facilities, offering products that meet ANSI/BHMA Grade 1 standards across their hardware lines.

Professional Features & Benefits

• Heavy-duty cold-forged steel chassis with electroplated corrosion resistance
• Latchbolt: stainless steel pullman-type, 3/4" (19mm) throw with deadlocking auxiliary latch
• Non-handed device (except double cylinder and lever trim which are handed)
• Standard bar length 36" (fits 30"–36" doors); easily field cut; optional 24" or 48"
• Standard single-point 1/4-turn hex key dogging on panic devices
• Free Wheeling levers for vandal resistance on trim
• SecureBolt® option (ED5200S): deadbolt-style latchbolt resists unauthorized entry
• Electrified options including delayed egress, electric latch retraction, and electric dogging
• UL-listed panic and 3-hour fire exit hardware; NFPA 101 and NFPA 80 compliant
• Full range of trim with Muséo® and Vineyard™ collections
• ADA compliant — lever trims and pulls comply with Americans with Disabilities Act
• PathLite™ photoluminescent touchpad cover option available
• Five-year limited warranty; ED5800 CVR certified to 3.25 million cycles

Technical Specifications

• Grade: ANSI/BHMA A156.3 Grade 1
• Handing: Non-handed standard (lever trim and double cylinder devices are handed)
• Bar Length: 36" standard (fits 30"–36" doors); optional 24" or 48"
• Door Thickness: 1-3/4" (44mm) standard; optional 2" (D200) or 2-1/4" (D214)
• Minimum Stile Width: 4-1/2" (114mm)
• Latchbolt — Rim (ED5200): Stainless steel pullman-type, 3/4" (19mm) throw with deadlocking auxiliary latch
• Latchbolt — SecureBolt® (ED5200S): Deadbolt-style, 3/4" (19mm) projection x 1" wide, positive deadlocking by auxiliary bolt
• Latchbolt — SVR (ED5400): Top: 3/4" throw pullman-type deadlocking; Bottom: 5/8" throw deadbolt
• Projection: 3-1/4" (83mm) active; 2-3/4" (70mm) dogged
• Dogging: Single-point 1/4-turn hex key; optional cylinder or electric dogging
• Strike: Surface-mounted 3/8" roller strike with positive locking plate and shims
• Certifications: ANSI A156.3 Grade 1; UL/cUL panic and 3-hour fire exit hardware; NFPA 101; NFPA 80; ADA; California State Fire Marshal approved
• Warranty: Five-year limited

Professional Applications

• Commercial Office Buildings
• Educational Facilities
• Healthcare Institutions
• Retail Establishments
• Industrial and Warehouse Facilities
• Multi-Tenant Residential Properties
• Government and Municipal Buildings

Why Choose Corbin Russwin Quality?

Corbin Russwin door hardware products are engineered to meet ANSI/BHMA Grade 1 standards, delivering professional-grade reliability for commercial and institutional applications. This replacement pin is manufactured to the same exacting standards as the exit device lines it supports, ensuring consistent performance when servicing ED7000, ED6400, and ED6400A series devices. For demanding commercial environments where exit device dependability is critical, Corbin Russwin replacement components provide the trusted quality needed to maintain safe and compliant door hardware systems.
