Crouse-Hinds C200M Malleable I...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$19.77
Crouse-Hinds C200M Malleable Iron Type C Conduit Outlet Body 2-Inch Condulet

Crouse-Hinds C200M Malleable Iron Type C Conduit Outlet Body 2-Inch Condulet

(No reviews yet) Write a Review

Model: C100M

In Stock (leaves warehouse same day if ordered before 3pm ET)

$19.77
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Crouse-Hinds 1" Form 5 C-Shape Condulet Outlet Body - Malleable Iron Construction

Professional electrical conduit fitting for reliable connections

The Crouse-Hinds 1" Form 5 C-Shape Condulet Outlet Body delivers professional-grade electrical conduit connections with durable malleable iron construction. Designed for ordinary/non-hazardous locations, this condulet body provides secure conduit routing and access points while meeting NEC/CEC standards for reliable electrical installations.

Professional Features & Benefits

  • 1" Trade Size: Accommodates standard 1-inch conduit systems for versatile electrical applications
  • Form 5 C-Shape Design: Provides 90-degree conduit routing with convenient access for wire pulling and connections
  • Malleable Iron Construction: Delivers exceptional durability and corrosion resistance for long-lasting performance
  • Compact Profile: 1.9" height and 1.8" width design minimizes installation space requirements
  • NEC/CEC Compliance: Meets electrical code standards for safe and compliant installations
  • Lightweight Design: 1.7 lb weight facilitates easy handling and installation

Technical Specifications

  • Area Classification: Ordinary/Non-Hazardous Locations
  • Product Height: 1.9 in
  • Product Length Depth: 7.05 in
  • Product Material: Malleable iron
  • Product Shape: C
  • Product Size: 1"
  • Product Weight: 1.7 lb
  • Product Width: 1.8 in
  • Standards Type: NEC/CEC

Professional Applications

  • Commercial electrical installations requiring conduit routing changes
  • Industrial facilities with standard conduit systems
  • Residential electrical projects needing access points
  • Maintenance and retrofit applications
  • Professional electrical contractor installations
  • Building electrical distribution systems

Why Choose Crouse-Hinds Quality?

Crouse-Hinds condulet bodies provide trusted reliability with malleable iron construction and NEC/CEC compliance. The professional-grade materials and proven design ensure dependable performance in demanding electrical applications, backed by the quality standards electrical professionals rely on.

Manufacturer Resources

Product Specs

Product Type:
Conduit Body
Department:
Electrical
Product Subgroup:
Electrical

Crouse-Hinds C100M – Frequently Asked Questions

1) What conduit trade sizes does the Crouse-Hinds C-series malleable iron Condulet outlet body come in?
Two trade sizes: 1 inch (part number C100M) and 2 inch (part number C200M). Order by the trade size of the rigid or IMC conduit run it is landing on, since the hubs are threaded to that size and there is no adapter built in.
2) Can I use this Crouse-Hinds Condulet body in a hazardous or classified area?
No. The C-shape malleable iron Condulet body is rated for ordinary, non-hazardous locations only. For Class I or Class II classified areas you need an explosionproof body built and marked for that division, not this one.
3) I have a 2-inch rigid run and need a pull point. Which part number do I order?
C200M, the 2-inch malleable iron C-shape body. The 1-inch version is C100M, so check the trade size stamped on your conduit before ordering; the two are not interchangeable.
4) What is a C-shape conduit body actually used for on a conduit run?
A C body is a straight-through pull and access point: conduit enters one end and leaves the other in line, with a removable cover in between so you can pull and splice wire. If you need to turn the run instead, that is an L body (LB for back outlet, LL or LR for side), and for a three-way junction you want a T body. The C shape is the one you put mid-run where you just need access.
5) Does this Condulet body meet electrical code for a commercial job?
The C-series malleable iron Condulet outlet body is built to NEC/CEC standards, which is what an inspector looks for on a commercial or industrial conduit run in an unclassified area.
6) Does the C200M come with a cover and gasket, or do I order those separately?
The C200M is the 2-inch body itself. Covers and gaskets are separate line items on Condulet bodies, so add the cover style you need (blank, gasketed, or wedge-nut) to finish the assembly.
7) Will a malleable iron Condulet thread onto EMT?
No. Threaded Condulet hubs take threaded rigid metal conduit or IMC. For EMT you need a set-screw or compression connector into a box, or an EMT-to-threaded adapter ahead of the body.
8) Is the Crouse-Hinds C100M body suitable for outdoor or damp commercial installs?
It is built of malleable iron, which holds up to knocks and corrosion better than die-cast, and it is intended for ordinary non-hazardous locations. Whether the installation is weatherproof depends on the cover and gasket you pair with it, so specify a gasketed cover for wet locations.
