Eaton Crouse-Hinds 1/2" Form 5 Condulet Cover with Integral Gasket
Professional-Grade NEMA 4 Rated Replacement Cover for Reliable Conduit System Protection
The Eaton Crouse-Hinds 1/2" Form 5 Condulet Cover with Integral Gasket is a precision-engineered replacement cover designed for maximum weather protection in conduit systems. This sheet steel cover delivers NEMA 4 rated performance with an integral gasket design that ensures reliable sealing for ordinary and non-hazardous electrical installations.
Key Features & Benefits
Weather Protection Excellence
- NEMA 4 Rating - Provides protection against windblown dust, rain, sleet, and snow for outdoor installations
- Integral Gasket Design - Built-in sealing eliminates the need for separate gaskets and ensures consistent weather protection
- Precision Fit - Engineered dimensions guarantee proper sealing and long-term performance
- Corrosion Resistance - Sheet steel construction with protective finish withstands harsh environmental conditions
Professional Installation Features
- Form 5 Configuration - Standard industry form factor ensures compatibility with existing condulet bodies
- Secure Mounting - Reliable attachment system maintains proper seal under thermal cycling
- Compact Profile - Low-profile design minimizes space requirements in tight installations
- NEC/CEC Compliance - Meets all applicable electrical code requirements for conduit system components
Technical Specifications
This Form 5 integral gasket cover is designed for 1/2" trade size condulet bodies and features sheet steel construction with NEMA 4 environmental protection rating. The cover measures 1.38" x 1.38" x 0.38" and weighs 0.14 pounds, providing a compact yet durable solution. The integral gasket design eliminates installation steps while ensuring consistent sealing performance. Suitable for ordinary and non-hazardous locations per NEC/CEC standards, this cover maintains electrical system integrity in demanding environments.
Installation Process
- Ensure condulet body is clean and free of debris around the sealing surface
- Inspect the integral gasket for any damage or contamination
- Position the cover squarely on the condulet body, aligning all mounting points
- Install mounting hardware using appropriate torque specifications
- Verify proper gasket compression and sealing around the entire perimeter
- Test the installation for proper environmental protection rating
Applications
Perfect for:
- Outdoor Electrical Systems - Weather-exposed conduit runs, exterior lighting circuits, and outdoor equipment connections
- Industrial Facilities - Manufacturing plants, processing facilities, and heavy-duty electrical distribution systems
- Commercial Buildings - Office complexes, retail centers, and institutional facilities requiring reliable conduit protection
- Municipal Infrastructure - Street lighting systems, traffic control installations, and public facility electrical systems
- Agricultural Applications - Farm buildings, irrigation control systems, and outdoor equipment installations
- Maintenance Operations - Replacement covers for existing condulet installations requiring upgraded weather protection
- Marine Environments - Coastal installations where enhanced corrosion resistance is essential
- HVAC Systems - Rooftop equipment connections and outdoor mechanical system electrical feeds
Condulet System Benefits
Condulet covers are essential components that transform basic conduit bodies into weather-resistant junction points. Unlike standard covers, this Form 5 design with integral gasket provides superior environmental protection without requiring separate sealing components. The NEMA 4 rating ensures reliable performance in wet locations, making it ideal for outdoor installations where moisture protection is critical. This eliminates the risk of water infiltration that can cause system failures and safety hazards.
Why Choose Integral Gasket Design?
The integral gasket design represents a significant advancement over traditional separate gasket systems. By incorporating the sealing element directly into the cover, this design eliminates gasket displacement, reduces installation time, and ensures consistent sealing performance throughout the system's service life. The precision-molded gasket maintains its sealing properties across a wide temperature range, while the sheet steel construction provides the structural integrity needed for long-term reliability in demanding electrical applications.
Manufacturer Resources
Product Specs
- Area Classification:
- Ordinary/Non-Hazardous Locations
- Nema Rating:
- 4
- Product Height:
- .38 in
- Product Length Depth:
- 1.38 in
- Product Weight:
- .14 lb
- Product Width:
- 1.38 in
- Standards Type:
- NEC/CEC
- Trade Size:
- 1/2"
- Product Type:
- Form 5 Integral Gasket Cover
- Product Group:
- Electrical Covers
- Department:
- Electrical
- Product Subgroup:
- Form 5 Integral Gasket Cover
- Product Material:
- Sheet steel
