Eaton Crouse-Hinds 2" Form 5 Integral Gasket Cover, Sheet Steel

Eaton Crouse-Hinds 2" Form 5 Integral Gasket Cover, Sheet Steel

NEMA 4 Rated Weather Protection for Condulet Bodies

The Eaton Crouse-Hinds 2" Form 5 Integral Gasket Cover is a professional-grade replacement cover engineered for reliable weather protection in condulet body installations. This sheet steel cover delivers NEMA 4 rated protection with integral gasket sealing for commercial and industrial electrical systems requiring dependable moisture resistance.

Key Features & Benefits

Weather Protection Excellence

• NEMA 4 Rating - Provides protection against windblown dust, rain, sleet, and snow for reliable outdoor performance
• Integral Gasket Design - Built-in sealing eliminates the need for separate gaskets and ensures consistent weather protection
• Sheet Steel Construction - Durable material provides excellent impact resistance and long-term reliability
• Precision Manufacturing - Engineered to exact specifications for proper fit and optimal sealing performance

Installation Efficiency

• Direct Replacement Design - Compatible with standard 2" condulet bodies for quick maintenance and upgrades
• Secure Mounting - Reliable attachment system ensures covers stay properly positioned in all weather conditions
• Professional Grade Quality - Trusted by electrical contractors for over 100 years of proven performance

Code Compliance & Safety

• NEC/CEC Compliant - Meets National Electrical Code and Canadian Electrical Code requirements
• Ordinary Location Rated - Suitable for standard commercial and industrial electrical installations
• Consistent Performance - Maintains electrical system integrity in challenging environmental conditions

Technical Specifications

This Form 5 integral gasket cover features a 2" trade size with sheet steel construction and NEMA 4 environmental rating. The cover measures 9.56" in length, 3.25" in width, and 0.63" in height, with a total weight of 0.7 pounds. The integral gasket design eliminates the need for separate sealing components while providing reliable weather protection. The cover is designed for ordinary/non-hazardous locations and complies with NEC/CEC standards for professional electrical installations.

Installation Process

1. Ensure power is disconnected and verify the condulet body is properly supported
2. Remove the existing cover by loosening the mounting hardware
3. Clean the condulet body sealing surface to remove any debris or old gasket material
4. Position the new Form 5 cover ensuring the integral gasket aligns properly with the sealing surface
5. Install and tighten mounting hardware to manufacturer specifications for proper gasket compression
6. Verify the cover is securely mounted and the gasket provides complete sealing around the perimeter

Applications

Perfect for:

• Commercial Buildings - Office complexes, retail centers, and healthcare facilities requiring reliable condulet protection
• Industrial Facilities - Manufacturing plants, processing facilities, and warehouses with outdoor electrical connections
• Municipal Infrastructure - Schools, government buildings, and public facilities with weather-exposed electrical systems
• Outdoor Installations - Parking lot lighting, building perimeter systems, and exterior equipment connections
• Maintenance Applications - Replacement covers for existing condulet bodies requiring upgraded weather protection
• Wet Location Systems - Areas subject to moisture, rain, or washing where NEMA 4 protection is essential
• Agricultural Facilities - Barns, processing buildings, and outdoor equipment requiring durable electrical protection
• Transportation Infrastructure - Transit facilities, airports, and transportation hubs with demanding environmental conditions

Condulet Cover System Benefits

Form 5 integral gasket covers provide superior weather protection compared to standard covers by incorporating the sealing gasket directly into the cover design. This eliminates the potential for gasket displacement or deterioration that can occur with separate gasket systems. The integral design ensures consistent sealing performance throughout the cover's service life while simplifying installation and maintenance procedures.

Why Choose Integral Gasket Design?

The integral gasket construction of this Eaton Crouse-Hinds cover delivers superior long-term reliability by eliminating the most common failure point in condulet weather protection systems. Unlike covers requiring separate gaskets that can shift, deteriorate, or be lost during maintenance, the integral design ensures the sealing element is always properly positioned and ready for service. This professional-grade approach reduces maintenance requirements while providing consistent NEMA 4 protection for critical electrical connections.
