CWRS
CWRS - spec sheet
Features
- Provided with water-proof test switch and AC-On indicator
- Wet Location Listed(0°C to 50°C)
- Dual-voltage 120/277 AC input
- LED life-cycle of more than 10 years
- Remote capacity or extended runtime option
- Fully adjustable lamp-heads
- Quick installation
- Includes long-life 9.6VDC Nickel Cadmium battery for UL recognized 90 minute operation
CWRS - spec sheet
Manufacturer Resources
Product Specs
- Department:
- Electrical
Compass COM-CWRS – Frequently Asked Questions
1) Can the Compass CWRS emergency light be installed outdoors or in a damp parking garage?
The CWRS is Wet Location Listed for ambient temperatures from 0 to 50 degrees C, so it holds up in covered outdoor entries, parking garages, loading docks, and wash-down areas. The test switch is water-proof as well, so the monthly push-to-test can be done without opening anything up. Below freezing it is outside the listed range.
2) Do I need to order a separate 120V or 277V version of the Compass CWRS?
No. The CWRS unit takes a dual-voltage 120/277 VAC input, so one part number covers both common commercial branch circuits. That makes it easier to standardize across a building where some areas are fed at 120 and others at 277.
3) How long will the Compass CWRS stay lit in a power outage?
The CWRS carries a long-life 9.6VDC nickel cadmium battery supporting UL recognized 90 minute emergency operation, which is the standard egress duration inspectors look for. Where you need longer, the unit offers an extended runtime option.
4) Can the Compass CWRS also power remote emergency heads down a corridor?
Yes, remote capacity is an available option on the CWRS, letting the unit feed additional remote heads where you need illumination away from the unit itself, such as a stairwell landing or a long egress path. Remote capacity and extended runtime are the two capacity options to call out when ordering.
5) How do I verify the Compass CWRS is on line and working during an inspection?
There is an AC-On indicator plus a push-to-test switch on the CWRS, both rated for wet locations. The indicator confirms utility power and charging; the switch drops the unit to battery so you can watch the heads come on. That covers the routine monthly function test a facility maintains records for.
6) Are the lamps on the Compass CWRS replaceable incandescent or LED?
LED, with a stated life-cycle of more than 10 years. For an MRO crew that means the recurring maintenance item on this unit is the nickel cadmium battery rather than lamp changes.
7) Can the light output be aimed after the Compass CWRS is mounted?
The lamp heads on the CWRS are fully adjustable, so you can aim coverage along the egress path after mounting rather than being locked into a fixed throw. Useful when one unit has to cover a door and a turn in a corridor.
8) What is the exact part number to order the Compass wet location emergency light?
Order it as Compass Products CWRS. That single model number is the whole unit; voltage does not split the part number because the input is dual 120/277.
