Delta Breez Integrity ITG80 - 80 CFM Single Speed

Delta Breez Integrity ITG80 - 80 CFM Single Speed

(No reviews yet) Write a Review

Model: ITG80
From the BreezIntegrity Collection
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$58.00
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

The Builder’s Choice for Green Construction.
Delta BreezIntegrity series are ENERGY STAR qualified with DC brushless motor engineered to run continuously for a minimum 70,000 hours. UL and cUL listed for tub/shower enclosure when used with GFCI-protected branch circuit wiring. Available in contractor packs.

Features

  • 80 CFM single speed fan for spaces up to 80 Sq. Ft.
  • Brushless DC Motor outlasts typical AC motors by 2-1/2.
  • Quiet at 1.3 sones.
  • Energy star®-qualified.
  • Compact housing for easy retrofit and replacement of older bath fans.
  • Housing size 7-1/4" x 7-1/2" x 5-3/4".
  • 4" duct.
  • UL and cUL listed for ceiling and wall mount installations.
  • UL and cUL listed for tub/shower enclosure when used with GFCI-protected branch circuit wiring.
  • 3 yr. limited warranty.

Product Specs

Subcategory:
BreezIntegrity
Static Pressure:
0.1 - 0.25
Sones:
1.3 - 1.4
Energy Star:
Yes
Maximum CFM:
80
Duct Diameter:
4"
Warranty:
3 Year Limited
Product Group:
Washroom/Bath
Product Subgroup:
Ventilation Fans
Collection:
BreezIntegrity
Product Voltage:
120/60
Product Height:
5-3/4"
Product Category:
Ventilation Fans
Product Width:
10-3/4"
Department:
Plumbing
Product Depth:
9-3/8"

Delta Breez ITG80 – Frequently Asked Questions

1) Will the Delta Breez Integrity ITG80 fit where my old bath fan was, or do I have to cut the ceiling?
The ITG80's housing is 7-1/4 x 7-1/2 x 5-3/4 inches, which is compact enough that it drops into most existing bath fan openings without enlarging the hole. Overall product dimensions are 10-3/4 inches wide, 9-3/8 inches deep, 5-3/4 inches high, so budget joist bay depth accordingly. Delta calls it out specifically for retrofit and replacement of older bath fans. Measure your existing cutout before you pull the old unit and you will know in a minute.
2) What size bathroom is an 80 CFM fan like the Delta Breez ITG80 good for?
Up to 80 square feet. The ITG80 is a single speed 80 CFM fan, and Delta rates it for spaces to 80 sq ft, which covers a typical full bath with tub or shower. Larger master baths, or rooms with an enclosed toilet compartment or a jetted tub, need more CFM or a second fan on the separate space.
3) Can the Delta Breez ITG80 be mounted on a wall instead of the ceiling?
Wall mount is covered. The ITG80 carries UL and cUL listing for both ceiling and wall mount installations, so it is a legitimate option in a bath with a concrete ceiling, a second floor above, or ductwork you cannot get at from overhead. Same 4 inch duct connection either way.
4) How loud is the Delta Breez Integrity ITG80 in a bathroom next to a bedroom?
1.3 sones at the rated point, and 1.3 to 1.4 sones across its operating range. That is quiet enough for a bath sharing a wall with a bedroom or for a hotel or multi-family corridor unit where guest complaints are the issue. For reference, anything at or under about 1.0 sone is effectively background; 1.3 is soft and audible but not intrusive.
5) Can the Delta Breez ITG80 run continuously for whole-house or code-required ventilation?
It is built for it. The BreezIntegrity series uses a DC brushless motor engineered to run continuously for a minimum of 70,000 hours, which is roughly eight years of nonstop operation. Delta states the brushless DC motor outlasts typical AC motors by 2-1/2 times. That is the reason to pick this over a standard AC bath fan when the fan is on a timer, a humidistat, or running 24/7 for makeup air.
6) What voltage does the Delta Breez ITG80 run on, and does it need a special circuit?
Standard 120V, 60 Hz power. The ITG80 wires to an ordinary residential branch circuit, no transformer or dedicated supply. The one wiring requirement to watch is that installations over a tub or in a shower enclosure must be on a GFCI-protected circuit for the UL and cUL listing to hold.
7) Is the Delta Breez ITG80 ENERGY STAR qualified for a green build or rebate program?
Yes. The ITG80 is ENERGY STAR qualified, which is what gets it accepted on green construction specs and utility rebate paperwork. The efficiency comes from the DC brushless motor rather than a conventional AC motor. If you are speccing across a whole project, the BreezIntegrity series is available in contractor packs.
8) Does the Delta Breez ITG80 have a light or humidity sensor, or is it fan only?
Fan only, single speed. The ITG80 moves 80 CFM whenever it is energized, with no light, no night light, no humidity sensor, and no speed selection. Control it from a wall switch, a timer, or an external humidistat. If you need the light in the same can, or a fan that ramps on humidity, you want a different model in the range, not this one.
9) How do I order the Delta Breez Integrity ITG80, and are there finish or size options?
One configuration only. The BreezIntegrity ITG80 is ordered as a single model with no finish, size, or speed choices to specify, so the model number is the whole order. Contractor packs are offered for the series if you are buying for a multi-unit job.
10) Will the Delta Breez ITG80 still pull 80 CFM through a long duct run?
Its rated performance is stated across 0.1 to 0.25 inches of static pressure, so it is characterized for real duct runs rather than a bare outlet. Keep the run in 4 inch duct, minimize elbows, and use rigid or smooth flex where you can. Long runs of corrugated flex and multiple 90s push you past that pressure band and airflow drops off.
