Design Hardware Pull Trim with Cylinder Hole, Night Latch Function, Trim for the 1000R, 2000R Exit Devices

Design Hardware Pull Trim with Cylinder Hole, Night Latch Function, Trim for the 1000R, 2000R Exit Devices

(No reviews yet) Write a Review

Model: DH-2P-03NL-32D
Selected Keying is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$139.48
$103.35
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Specification


Construction: Stainless steel construction
Pull Plate: 3” Wide x 13 7/8” Height x 1/16” thick
Pull: 3/4” diameter hollow x 6 1/4” etc x 2 7/16” projection
Application: Pull trim option for 1000R & 2000R. Will cover 161 door prep (Not recommended for SVR devices as rods can be hard to Iift with rim cylinder tailpiece)
Mounting: Thru bolted design thru bolts to head of exit device and to door with finish washer. Will cover 161 door prep
Handing: Non-handed
Door Thickness: 1 3/4”
Functions: 02DT Dummy, 03-NL Night latch (key retracts latch)
Accessories: 03-NL includes cylinder sleeve for installation into 161 door prep
Fasteners: Includes thru bolt posts, 1/4”-2 machine screws & finish washer for installation
Cylinders: Rim Cylinder required for 03NL (not included)
Rim cylinder housing for 6 or 7 pin Small format IC core (less core) also available
Finishes: US3, US4, US10B, US26, US32D

Manufacturer Resources

Product Specs

Application:
1000R and 2000R Lever Trim
Device Type:
Rim or SVR
Grade:
Grade 1
Keyed Function:
No
Product Group:
Exit Devices and Trim
Product Subgroup:
Exit Device Trim
Product Type:
Exit Device Trims
Keyed:
No
Commercial/Residential:
Commercial
Handle Type:
Lever
Lock Function:
Entry
Product Function:
Entry
Cylinder Classification:
Conventional Cylinder
Product Category:
Mechanical Locks
Department:
Door Hardware

Design Hardware DH-2P-03NL-32D – Frequently Asked Questions

1) Does the night latch pull trim come with a cylinder?
No cylinder is included. The 03-NL night latch function needs a rim cylinder, bought separately, and the trim ships with a cylinder sleeve so it installs into a 161 door prep. If you run small format interchangeable core, a rim cylinder housing for 6 or 7 pin SFIC (less core) is also available.
2) Will this trim cover an existing 161 door prep?
Yes. Both the pull plate and the mounting are made to cover a 161 (cylindrical lock) door prep, and the 03-NL version includes a cylinder sleeve so a rim cylinder mounts correctly in that prep. That makes it a straightforward swap on a door that previously had a cylindrical lockset.
3) Can I use this pull trim on a surface vertical rod exit device?
Not recommended. On an SVR device the key has to lift the rods, and the rim cylinder tailpiece makes that hard, so the retraction feels heavy or fails. Keep this trim on rim devices, the 1000R and 2000R. For a keyed SVR application, a trim built for vertical rod devices, such as the Sargent 744 freewheeling night latch trim for 8700/8900 surface vertical rod and mortise devices, is the right direction.
4) What should I use instead of the Design Hardware 03NL pull trim on a surface vertical rod exit device?
The Design Hardware pull trim is not recommended for SVR devices, since the rods can be hard to lift with a rim cylinder tailpiece. For an SVR opening, the Sargent 744 is a Grade 1 night latch trim listed for surface vertical rod and mortise 8700 and 8900 Series devices with a freewheeling lever that retracts the latch by key. The Dormakaba PowerPlex P201U is listed for rim, mortise and SVR devices.
5) What is the closest equivalent to the Design Hardware 03NL pull trim if the door needs a pull-style night latch trim rather than a lever?
The Tell EDPT exit device pull trim is also a pull trim with a cylinder hole supplied less cylinder, and it is listed for doors 1-3/8 inch to 1-3/4 inch thick. The Design Hardware 03-NL pull trim is built for 1-3/4 inch doors, is non-handed, and its 03-NL night latch function retracts the latch by key, with a rim cylinder required and not included. The Dexter ED1500 nightlatch trim with raised lip pull plate is another pull-plate nightlatch option, in Grade 1.
6) Do I need to order this pull trim left or right hand?
No handing to specify. The pull trim is non-handed, so one part works on either swing. Keying is the only choice on the order: keyed different as standard, or keyed alike if you're matching multiple openings.
7) What is the difference between the 03-NL and 02DT versions of this trim?
02DT is a dummy: the pull is fixed, there is no key control, and it's purely a grab handle for exit-only doors. 03-NL is night latch, where a key retracts the latch so you can get back in through the device. If nobody ever needs keyed re-entry, the dummy is the simpler order.
8) How far does this pull stick out from the door, and how much plate does it cover?
The pull plate measures 3 inches wide by 13-7/8 inches high and 1/16 inch thick. The pull itself is 3/4 inch diameter hollow tube with a 2-7/16 inch projection off the face. Worth checking that projection against anything swinging past the door, like an adjacent door or a wall return.
9) What fasteners come with this exit device pull trim, and do I need anything else?
The kit includes thru bolt posts, 1/4-20 machine screws and a finish washer, so the mounting hardware is covered. What you still have to buy is a rim cylinder for the 03-NL night latch function, plus the 1000R or 2000R exit device itself if it isn't already on the door.
10) Is this pull trim heavy enough for a high traffic commercial entrance?
It's stainless steel construction, Grade 1, and thru bolted through the door into the head of the exit device rather than screwed to the face, which is what holds up under pulling traffic. It's a commercial trim, not residential.
11) I need a night latch trim but with a lever instead of a pull. What are my options?
This Design Hardware trim is a pull, not a lever, so on a door where code or preference calls for a lever you want a lever night latch escutcheon instead. Comparable night latch lever trims include the Sargent 704ET (Grade 1, field reversible), the Sargent 704-ETL for PE Series devices, the Dorma YR03R wide stile escutcheon with R lever, and the Corbin Russwin VT957ET stamped stainless nightlatch escutcheon for ED5000 devices. Each of those is tied to its own device family, so match the trim to the device you have.
12) I need the outside lever to stay latched and always require a key - is the Design Hardware 03NL the right trim, or should I look at a storeroom trim?
The Design Hardware 03-NL is a night latch function where the key retracts the latch, and it is a pull rather than a lever. If a storeroom lever is what the spec calls for, the Pamex E9000 is a Grade 1 storeroom trim with an L3 lever listed for 1-3/8 inch to 2 inch doors, the Marks USA M195F is a storeroom lever and rose trim with spring loaded roses, and the Tell EDELT80 is a storeroom escutcheon lever trim for 1-3/8 inch to 1-3/4 inch doors.
13) Is a thumbpiece trim an alternative to the Design Hardware 03NL pull trim?
It is a different mode of operation. The Design Hardware 03-NL uses a fixed pull with a rim cylinder, so the key retracts the latch and there is no outside handle motion. A thumbpiece trim such as the Tell EDTHP53, an entry function trim for 1-3/8 inch to 1-3/4 inch doors, or the Dexter ED1000T-CLRM-TP-NC, a Grade 1 classroom thumbpiece with pull plate and cylinder less cylinder, gives a depressible thumbpiece to retract the latch.
14) What finishes does the Design Hardware 1000R/2000R pull trim come in?
Five: US3 bright brass, US4 satin brass, US10B oil rubbed bronze, US26 bright chrome and US32D satin stainless. US32D is the usual pick for commercial back-of-house and matches most existing exit device hardware in a building.
15) The opening is fire rated - does the Design Hardware 03NL pull trim or one of the alternatives suit it better?
The Design Hardware 03-NL is a Grade 1 commercial exit device trim that thru bolts to the head of the 1000R or 2000R device. Among comparable trims, the Accentra 121NL nightlatch trim, 426F Augusta lever escutcheon trim, 441F night latch keyed lever trim and 446F classroom trim are each listed with a fire rating of No, which matters when the drawing calls for a labeled assembly.
