Detex 1002D Advantex 10 Series Super-Heavy-Duty Wide Stile Rim Exit Device with Dummy Lever Trim

Detex 1002D Advantex 10 Series Super-Heavy-Duty Wide Stile Rim Exit Device with Dummy Lever Trim

(No reviews yet) Write a Review

Model: 1002D-628-36
$2,359.00
$2,338.33
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$2,359.00
$2,338.33
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Detex Advantex 10 Series Super-Heavy-Duty Wide Stile Rim Exit Device with Dummy Lever Trim

Professional Grade Panic Hardware for High-Traffic Commercial Applications

The Detex Advantex 10 Series rim exit device delivers super-heavy-duty panic and fire exit hardware engineered for demanding commercial environments. This Grade 1 wide stile rim exit device features patented mounting plate and strike locator system technology, tested beyond 1,000,000 cycles for exceptional durability. Built with stainless steel deadlocking Pullman-type latch bolt and PVD-finished surfaces over stainless steel construction for years of reliable service in high-use, high-abuse applications.

Professional Features & Benefits

  • Super-Heavy-Duty Durability: Tested beyond 1,000,000 cycles - twice the cycling required for Grade 1 UL testing for exceptional longevity in high-traffic environments.
  • Patented Installation System: Mounting plate and strike locator system replaces paper templates for the easiest and most accurate installation of panic hardware available.
  • Wide Stile Compatibility: Designed specifically for wide stile door applications with field sizeable capability for versatile installation options.
  • Premium Construction: Stainless steel deadlocking Pullman-type latch bolt with all exposed surfaces finished over stainless steel using environmentally-friendly PVD process.
  • Service-Friendly Design: Outside trims are easily changed or re-keyed without removing device from door, reducing maintenance time and costs.
  • Damage Protection: Heavy duty angled end cap deflects damage away from device for enhanced durability in high-abuse environments.
  • Versatile Operation: Non-handed design with 1/8 turn hex or cylinder dogging options for flexible operational requirements.
  • Manufacturer Warranty: 10 Year Mechanical/3 year Electrical Limited Manufacturer's Warranty for added confidence and protection.

Technical Specifications

  • Commercial/Residential: Commercial
  • Grade: Grade 1
  • Product Category: Exit Devices and Trim
  • Product Function: Dummy Lever Trim
  • Product Group: Exit Devices and Trim
  • Product Model: 1002D
  • Product Subgroup: Exit Devices - Rim
  • Product Type: Exit Devices - Rim
  • Series: 10 Series
  • Stile: Wide
  • Stile Type: Wide Stile
  • Subcategory: Advantex Series
  • Warranty: 10 Year Mechanical/3 year Electrical Limited Manufacturer's Warranty
  • Wood Door Compatible: No

Installation & Operation

  1. Review manufacturer specifications and verify door preparation requirements including door thickness, stile width, and handing as applicable to this product.
  2. Use manufacturer-provided templates to mark mounting hole locations accurately on door and/or frame surfaces.
  3. Prepare door and frame by drilling required holes and routing as specified in manufacturer instructions.
  4. Install all mounting hardware and secure the device to door and frame per manufacturer torque specifications.
  5. Adjust operational components for proper alignment, latching, and smooth operation throughout the full range of motion.
  6. Test device operation to verify proper function and make final adjustments as needed. Refer to manufacturer documentation for complete installation details and troubleshooting.

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Choose Detex Quality?

Detex Advantex 10 Series exit devices deliver professional-grade reliability with stainless steel construction and patented mounting technology tested beyond 1,000,000 cycles. The 10 Year Mechanical/3 year Electrical Limited Manufacturer's Warranty provides comprehensive coverage for demanding commercial applications. Engineered for high-use, high-abuse environments where dependable panic hardware performance is essential for life safety compliance.



Resources

Installation Instructions
Parts List
Door Templates
Maintenance Manual
Installation Video
Specifications

Product Specs

Series:
10 Series
Product Group:
Exit Devices and Trim
Product Subgroup:
Exit Devices - Rim
Product Type:
Exit Devices - Rim
Subcategory:
Advantex Series
Commercial/Residential:
Commercial
Warranty:
10 Year Mechanical/3 year Electrical Limited Manufacturer's Warranty
Grade:
Grade 1
Stile:
Wide
Stile Type:
Wide Stile
Wood Door Compatible:
No
Product Model:
1002D
Product Function:
Dummy Lever Trim
Product Category:
Exit Devices and Trim
Department:
Door Hardware

Detex 1002D-628-36 – Frequently Asked Questions

1) What does the dummy lever trim on the Detex 1002D actually do, and can you get in from outside with it?
The 1002D is configured with dummy lever trim, so the outside lever is fixed. It gives you something to pull on and a finished look on the outside face, but it does not retract the latch. Entry from outside means either dogging the device down (hex or cylinder dogging are both offered) or ordering a keyed trim function instead. If you need key entry from the pull side, this is the wrong trim for the opening.
2) What size Detex 1002D do I order for a 36 inch door versus a 42 inch door?
Two device lengths are offered, 36 inch and 48 inch. The 48 inch covers wider leaves, and the device is field sizeable, so an in-between leaf width is handled by cutting the larger device down rather than hunting a third length.
3) Do I have to specify handing on the Detex 1002D if the device itself is non-handed?
Yes, handing is part of the order even though the device body is non-handed. Right Hand Reverse and Left Hand Reverse are the two choices, and that drives the trim and end cap orientation. Exit devices are always handed by the reverse bevel convention, so an out-swinging door with the hinges on your right as you face the pull side is Right Hand Reverse.
4) I need this door to stay push-pull during business hours. What dogging option should I order?
Order hex dogging for the standard 1/8 turn allen-key hold-down, or cylinder dogging if you want staff to dog and undog it with a key instead of a tool. Less/No dogging is the third choice and is what you take on a fire rated opening, since fire exit hardware cannot be mechanically dogged. There is also an electric dogging option if you want the door released on a time clock or access control schedule.
5) Is the Detex 1002D available fire rated, and is there a hurricane rated version?
Four rating configurations are offered: Fire Rated, Hurricane Rated, Hurricane and Fire Rated, and Non-Rated. That combined hurricane-and-fire option is the one to specify for a coastal exterior egress door that also sits in a rated wall.
6) Can I get a Detex Advantex 10 Series rim device with delayed egress or a request-to-exit switch built in?
Yes. Electrified choices on the 1002D are Delayed Egress, Electric Dogging, Hardwired Electric Alarm, Request To Exit (Signal) Switch, or None. Delayed egress and the local alarm are the ones facilities use to stop unauthorized exits through a side or stock door; the RX switch is what an integrator wires back to the access control panel to signal a valid exit. Delayed egress installations are governed by local code and fire marshal approval, so confirm it is permitted for your occupancy before specifying it.
7) My door has a narrow stile - what rim exit device should I use instead of the Detex 1002D?
The Detex 1002D is built for wide stile doors, so a narrow stile opening needs a different device. Grade 1 narrow stile rim options include the Corbin Russwin ED4200 in 36 inch, the TownSteel ED3700 and ED8900 in 36 inch, the Falcon 19-R in 36 inch exit only, and the Adams Rite 8800 Series 30 inch, which lists a door thickness range of 1-3/4 inch to 2-1/4 inch. All of these are rim devices, so the strike prep stays on the frame stop rather than moving to the header or sill.
8) What is the closest equivalent to the Detex 1002D from another manufacturer for a wide stile rim exit device with dummy lever trim?
The Sargent 12-8810-LTRIM is the nearest match in function and configuration: it is a Grade 1 fire rated wide stile rim exit device with a dummy lever trim function, in the Sargent 8800 Series. The Detex 1002D is also a Grade 1 wide stile rim device with dummy lever trim, in the Advantex 10 Series, and it is offered in fire rated, hurricane rated, hurricane and fire rated, and non-rated configurations. The Sargent unit also carries RX and motorized electric latch retraction, while the Detex 1002D handles electrification through delayed egress, electric dogging, hardwired electric alarm, or a request to exit signal switch option.
9) I only need a push-to-exit device with no outside trim - is there a simpler option than the Detex 1002D?
Yes. The 1002D is supplied with dummy lever trim on the outside, so if the outside pull is not wanted, an exit-only wide stile rim device is the simpler buy. Wide stile exit-only options include the Corbin Russwin ED2200 in 36 inch Grade 1, the Sargent 2828 and 3828 Grade 1 reversible devices for 48 inch doors, the Imperial USA ED-501 Grade 1 36 inch, and the TownSteel ED1100 36 inch Grade 1 heavy duty. Von Duprin's 22 Series 36 inch wide stile pushpad device is also non-handed and Grade 1, which removes the handing decision the 1002D requires.
10) Is a Cal-Royal 5000 or 5500 a direct substitute for the Detex Advantex 1002D?
They are not equivalents on rating. The Detex 1002D is Grade 1 and tested beyond 1,000,000 cycles, twice the cycling required for Grade 1 UL testing. The Cal-Royal 5000 is a 36 inch wide rim exit device with a touch bar and a Grade 2 chassis, and the Cal-Royal 5500 is a 48 inch wide rim device with a push bar, also Grade 2; both are heavy duty and neither is fire rated. If the spec on the drawing calls for Grade 1 panic hardware, the Cal-Royal 5000 and 5500 will not satisfy it.
11) Is an SDC pressure sense bar or switch bar the same thing as a Detex 1002D exit device?
No. The Detex 1002D is mechanical panic hardware with a stainless steel deadlocking Pullman-type latch bolt that latches the door itself. The SDC PSB560 Series 36 inch pressure sense bar and the SDC MSB550 Series 36 inch mechanical switch bar are exit bars that release a separate electromagnetic lock rather than carrying their own latch, and both are listed for narrow or wide stile doors and are not fire rated. If you need the door latched by the device, the 1002D is the one; if the door is held by a maglock, the SDC bars are the release.
12) Which fire rated rim exit devices compare to the fire rated Detex 1002D?
The Detex 1002D is available in a fire rated configuration, as well as hurricane rated and hurricane-and-fire-rated. Other fire rated rim devices include the Dexter ED1000 Series Grade 1 fire rated rim device, the Marks USA M9900F in 36 inch and 48 inch exit only with a panic protector end cap, the Orca Hardware OED85 Series 36 inch, the Arrow FS1250 32 inch, and the Adams Rite 3700 Series 30 inch narrow stile, which is also wood door compatible. Of that group, only the Detex 1002D lists a hurricane rated option.
13) What is the difference between the Detex 1002D dummy lever trim and a nightlatch function rim device?
The dummy lever trim on the Detex 1002D is a fixed outside pull with no latch retraction, so the door is exit-only from inside and the outside lever does not operate the latch. A nightlatch device such as the Sargent 8504 gives keyed outside entry through a cylinder instead; that one is a Grade 1 narrow stile rim device in the 8500 Series. Choose the 1002D dummy trim where the outside must stay locked, and a nightlatch where staff need to key back in. On the Detex, outside trims can be changed or re-keyed without taking the device off the door.
14) Which strike do I pick, the 99 surface or the 98 semi-mortise, for the 1002D?
Strike is a required selection. The 99 surface strike mounts on the face of the stop and is the simpler retrofit when you do not want to cut the frame. The 98 semi-mortise sets into the stop for a flatter, less snag-prone profile and a cleaner look on a new frame or one you are already prepping. Match it to whatever the existing frame prep will accept if you are replacing an older device.
15) What finishes can I get to match the other exit devices in my building?
Ten finishes are offered on the Advantex 1002D: 605 polished brass, 606 brushed brass, 611 polished bronze, 612 brushed bronze, 613 oil rubbed bronze, 628 brushed aluminum, 629 polished stainless, 630 brushed stainless, 693 black painted and 695 dark bronze painted. Exposed surfaces are finished over stainless steel with a PVD process, which holds up better than plated brass on a high-traffic or exterior door. 630 and 628 are the usual matches for existing commercial openings.
16) Is the Detex 1002D heavy duty enough for a school or hospital main egress door?
It is a Grade 1 commercial device tested beyond 1,000,000 cycles, which Detex states is twice the cycling required for Grade 1 UL testing. The latch is a stainless steel deadlocking Pullman type, and the angled end cap is there to take cart and crowd impact instead of the device. That cycle count is the reason facilities put it on the highest-traffic leaves.
17) Can I re-key or change the outside trim on the Advantex 10 Series without pulling the device off the door?
Yes. Detex builds the 10 Series so outside trims are changed or re-keyed with the device still mounted. For a locksmith rekeying a campus that matters more than the initial install cost, and it is a real difference from devices that require dismounting the chassis to reach the trim mounting screws.
18) What should I use instead of the Detex 1002D if the door needs concealed vertical rods rather than a rim strike?
The 1002D is a rim device, latching into a surface or semi-mortise strike on the frame stop. For a concealed vertical rod opening, the Hager 4501 Series 36 inch Grade 1 concealed vertical rod device with a wide stile pushpad is the wide stile counterpart, and the Hager 4601 Series 36 inch Grade 1 concealed vertical rod device covers narrow stile. Both latch top and bottom into the frame and sill instead of the strike prep a rim device uses.
19) How does the Detex 1002D differ from a crossbar rim device like the Corbin Russwin ED3200 or CRL Jackson 1095?
The Detex 1002D is a wide stile push-pad style rim device with a heavy duty angled end cap and 1/8 turn hex or cylinder dogging. The Corbin Russwin ED3200 is a Grade 1 48 inch crossbar rim exit device supplied as a panic device only, with a 1-3/4 inch door thickness, and the CRL Jackson 1095 Series 48 inch is a crossbar rim panic device in exit-only function. Crossbar devices project a horizontal bar across the door face rather than a pushpad, which changes the look and the clearance in front of the door, and both of those are exit-only rather than carrying outside trim.
20) I want one exit device model I can stock for both handings - is the Detex 1002D or a non-handed device better for standardizing?
The Detex 1002D device itself is non-handed, but it is ordered as right hand reverse or left hand reverse to suit the opening. If you would rather carry a single non-handed part number, the BEST Precision 5101 Series is a non-handed universal design rim device, the BEST 2401 Series is non-handed narrow stile exit only, the CRL Jackson 1295 Series is a non-handed push pad rim panic device for 1-3/4 inch doors, and the Von Duprin 22 Series 36 inch wide stile pushpad device is non-handed and Grade 1. Those are exit-only or trimless, so they will not give you the outside dummy lever the 1002D includes.
21) My door needs a 48 inch rim device - what wide stile alternatives match the 48 inch Detex 1002D?
The Detex 1002D is offered in 36 inch and 48 inch sizes. Other 48 inch wide stile rim devices include the DORMA 9300 Series Grade 1 heavy duty exit-only device, which lists a door thickness range of 1-3/4 inch to 2-1/4 inch, the Corbin Russwin ED3200 Grade 1 crossbar device at 1-3/4 inch thickness, the CRL Jackson 1095 Series crossbar device, and the Marks USA M9900F 48 inch fire rated exit only. The Sargent 2828 and 3828 Grade 1 reversible devices are specified for 48 inch minimum door width.
22) Is there a cheaper wide stile rim device if the door is not high traffic?
If the opening is a low-use rear or stock door, a Grade 2 device will do the job: the Cal-Royal 5000 36 inch touch bar and the Cal-Royal 5500 48 inch push bar are both heavy duty Grade 2 rim devices. Design Hardware's 2000R is a standard duty wide stile rim device. Step up to the Grade 1 Detex when the leaf sees constant cycling or abuse.
23) Do I still need paper templates to install the Advantex 10 Series, or is the door prep in the box?
Detex ships a mounting plate and strike locator system on the 10 Series in place of paper templates, which is what keeps the pushpad and the strike in line on the first try. Door prep templates, the installation instructions, the parts list and a maintenance manual are all published for the series, so a crew can pull the prep dimensions before the hardware lands on site.
