Klein Tools CL800 Digital Clamp Meter 600A AC/DC Auto-Range TRMS with Low Impedance Mode

Klein Tools CL800 Digital Clamp Meter 600A AC/DC Auto-Range TRMS with Low Impedance Mode

Professional Auto-Range TRMS Technology with Low Impedance Detection

The Klein Tools CL800 Digital Clamp Meter delivers professional-grade electrical measurement capabilities with automatically ranging true RMS technology for increased accuracy. This versatile clamp meter features CAT IV 600V and CAT III 1000V safety ratings with Class 2 double insulation, making it suitable for residential, office, and light-industrial applications. The integrated Low Impedance (LoZ) mode identifies and eliminates ghost or stray voltages, while the included thermocouple probe extends temperature measurement capabilities from -14� to 1000�F.

Professional Features & Benefits

• 600A AC/DC Current Measurement: Handles high-current applications with precision for comprehensive electrical diagnostics and troubleshooting.
• Auto-Range TRMS Technology: Automatically selects optimal measurement range while providing true RMS accuracy for reliable readings on non-linear loads.
• Low Impedance (LoZ) Mode: Eliminates ghost voltages and stray readings for confident voltage measurements in complex electrical environments.
• CAT IV 600V Safety Rating: Meets stringent safety standards for use in primary distribution and utility applications with enhanced protection.
• 6000 Count LCD Display: Provides clear, high-resolution readings with excellent visibility for precise measurement interpretation.
• 6.6-Foot Drop Protection: Built to withstand demanding jobsite conditions with rugged construction for long-term reliability.
• Complete Measurement Kit: Includes carrying pouch, test leads, thermocouple with adapter, and batteries for immediate professional use.

Technical Specifications

• Batteries: 2 x AAA
• Capacitance: 6000�F
• Current: 600A AC; 600A DC
• Department: Electrical
• Depth: 9.0900 in
• Display: 6000 Count LCD
• Drop Protection: 6.6' (2 m)
• Frequency: 1Hz - 500 KHz
• Height: 1.5400 in
• Ingress Protection: IP40
• Jaw Size: 1.38" (3.5 cm)
• Ohms Resistance : 60MO
• Overall Height: 1.55" (3.9 cm)
• Overall Length: 9.09" (23.1 cm)
• Overall Width: 3.81" (9.7 cm)
• Product Function: Test leads measure AC/DC voltage, resistance, continuity, frequency and capacitance and tests diodes. Thermocouple probe measures temperature.
• Product Group: Tool Sets
• Product Subgroup: Tool Kits
• Product Voltage: 1000V AC; 1000V DC
• Standard: CAT IV 600V; CE Certified
• Temperature Range: -14� - 1000�F (-26� - 538�C)
• Weight: 0.7810 lbs
• Width: 3.8200 in

Installation & Operation

1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

• Electrical Troubleshooting and Diagnostics
• HVAC System Maintenance and Repair
• Industrial Equipment Testing
• Commercial Facility Maintenance
• Residential Electrical Service
• Motor and Drive System Analysis
• Power Quality Assessment

Why Choose Klein Tools Quality?

Klein Tools delivers professional-grade reliability with CAT IV 600V and CE certification standards, backed by rugged 6.6-foot drop protection and IP40 ingress protection. The comprehensive measurement capabilities, combined with true RMS accuracy and Low Impedance mode, provide the precision and durability that electrical professionals demand for critical diagnostic work.
