Digital Clamp Meter, True RMS, AC Auto-Ranging, 600 Amps
CL600 - spec sheet
Features
- Operating altitude to 6,562-Foot (2,000 m)
- Low battery indicator and easily accessible battery compartment
- Meets requirements for use in basic and controlled electromagnetic environments like residential, office and light-industrial locations
- Includes carrying pouch, test leads and batteries
- CAT IV 600V, CAT III 1000V, Class 2, Double insulation safety rating
- Amp Clamp measures AC current
- Built to withstand a 6.6-foot (2 m) drop
- Features Low Battery Indicator
- Clamp Meter with automatically ranging true mean squared (TRMS) technology for increased accuracy
- Test leads measure AC/DC voltage, resistance, continuity and tests diodes
Warnings
- Do not use the meter during electrical storms or in wet weather, and do not use the meter or test leads if they appear to be damaged.
- Before each use verify meter operation by measuring a known voltage or current.
- Do not attempt to measure resistance or continuity on live circuits.
- Read, understand and follow all instructions, cautions and warnings attached to and /or packed with all test and measurement devices before each use.
CL600 - spec sheet
Manufacturer Resources
Product Specs
- Batteries:
- 2 x AAA
- Current:
- 600A
- Depth:
- 9.0900 in
- Display:
- 6000 Count LCD
- Drop Protection:
- 6.6' (2 m)
- Functions:
- Clamp measures AC current; Test leads measure AC/DC voltage, resistance, continuity and tests diodes
- Height:
- 1.5400 in
- Ingress Protection:
- IP40
- Jaw Size:
- 1.38" (3.5 cm)
- Ohms Resistance :
- 60MO
- Overall Height:
- 1.55" (3.9 cm)
- Overall Length:
- 9.09" (23.1 cm)
- Overall Width:
- 3.81" (9.7 cm)
- Standard:
- CAT IV 600V; CE Certified
- Voltage:
- 1000V AC; 1000V DC
- Weight:
- 0.7380 lbs
- Width:
- 3.8200 in
