Panduit BT4LH-L0 Dome-Top® BT4LH-L0 Barb Tie, Black, UV PA6.6, 14.9"L, 120lb, PK50

Panduit BT4LH-L0 Dome-Top Barb Cable Tie, 14.9" 120lb UV-Resistant Nylon 6.6, Black 100-Pack

(No reviews yet) Write a Review

Model: BT4LH-L0

In Stock (leaves warehouse same day if ordered before 3pm ET)

$122.50
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Panduit BT4LH-L0 Dome-Top® Barb Cable Tie, 14.9" 120lb UV-Resistant Nylon 6.6, Black 100-Pack

The Panduit BT4LH-L0 Dome-Top® Barb Cable Tie is a 14.9" (378mm) nylon cable tie engineered for heavy-duty bundling in commercial, industrial, and telecommunications installations. Built from UV-resistant, weather-resistant Nylon 6.6 with a 120lb (534N) minimum loop tensile strength, it accommodates bundle diameters from 0.188" to 4" and performs reliably across a -76°F to 185°F operating range. This UL Listed, CSA-recognized tie ships in a convenient 100-Pack for high-volume cable management projects.

Key Features

  • Trade Size: 14.9" overall length (378mm) accommodates bundle diameters from 0.188" up to 4" for versatile cable organization.
  • Durable Construction: UV-resistant, weather-resistant Nylon 6.6 body measuring 0.275" wide by 0.065" thick withstands outdoor exposure and temperature extremes.
  • Dome-Top® Barb Design: Professional barb-style closure configuration ensures a secure hold and resists accidental release in critical applications.
  • Minimum Loop Tensile Strength: 120lb (534N) rating delivers heavy-duty holding power for large, demanding cable bundles.
  • Operating Temperature Range: Rated from -76°F to 185°F (-60°C to 85°C), with a -4°F minimum installation temperature, for consistent performance in extreme environments.
  • Indoor/Outdoor Rated: Weather-resistant construction supports installation in diverse interior and exterior conditions.
  • RoHS Compliant: Environmentally responsible construction meets international regulatory requirements for professional installations.

Certifications & Compliance

  • UL Listed (UL 62275)
  • CSA Recognized
  • RoHS Compliant

Technical Specifications

  • Overall Length Mm: 378
  • Body Thickness Mm: 1.7
  • Body Width Mm: 7
  • Maximum Bundle Diameter In: 4
  • Minimum Bundle Diameter Mm: 4.8
  • Minimum Loop Tensile Strength Lb: 120
  • Maximum Operating Temperature F: 185
  • Minimum Operating Temperature F: -76
  • Minimum Installation Temperature F: -4
  • Sub Brand: Dome-Top®

Typical Applications

  • Telecommunications Infrastructure
  • Data Center Cable Management
  • Industrial Control Panels
  • Electrical Distribution Systems
  • HVAC System Installations
  • Outdoor Utility Applications

Why Panduit?

Panduit's Dome-Top® cable ties deliver professional-grade cable management backed by UL Listed and CSA-recognized certifications for demanding electrical and telecommunications environments. The UV-resistant Nylon 6.6 construction and wide -76°F to 185°F operating range provide long-term durability, while RoHS-compliant materials support environmentally responsible installations for reliable, code-compliant performance.

Manufacturer Resources

Product Specs

Any Reason Not To Sell:
N
Arra Compliant:
Y
Body Thickness In :
0.065
Body Thickness Mm :
1.7
Body Width In :
0.275
Body Width Mm :
7
California Pro65 Cancer:
No
Country Of Origin:
Costa Rica
Ean:
74983412686
Environment:
Indoor/Outdoor
For Use With:
GTH-E, GS4H-E, GS4EH-E, PTH, STH2, ST3EH
Gtin Carton:
5.0075E+13
Gtin Package:
74983412686
Hazardous Material Flag:
N
Lead Content Indicator:
N
Material Description:
Nylon 6.6 (UV-Resistant, Weather-Resistant)
Maximum Bundle Diameter In :
4
Maximum Bundle Diameter Mm :
102
Maximum Operating Temperature C :
85
Maximum Operating Temperature F :
185
Mercury Content Indicator:
N
Min Order Qty:
500
Min Order Uom:
Piece
Minimum Bundle Diameter In :
0.188
Minimum Bundle Diameter Mm :
4.8
Minimum Installation Temperature C :
-20
Minimum Installation Temperature F :
-4
Minimum Loop Tensile Strength Lb :
120
Minimum Loop Tensile Strength N :
534
Minimum Operating Temperature C :
-60
Minimum Operating Temperature F :
-76
Overall Length In :
14.9
Overall Length Mm :
378
Pallet Quantity:
48,000
Pallet Volume:
51.255
Pallet Weight:
628.3152
Product Color:
Black
Product Material:
Nylon 6.6
Product Segment:
IEI
Product Type:
Cable Tie
Reach Status:
N
Resistance Properties:
UV-Resistant, Weather-Resistant
Restricted Use Of Hazardous Substances:
N
Rohs Compliant:
Compliant
Standard Carton Volume Ft3:
0.5339
Standard Carton Weight Pounds:
6.545
Standard Package Volume Ft3:
0.0534
Standard Package Weight Pounds:
0.6545
Std Carton Height In:
6.1
Std Carton Height Mm:
154.94
Std Carton Length In:
16.95
Std Carton Length Mm:
430.53
Std Carton Width In:
9.05
Std Carton Width Mm:
229.87
Std Ctn Qty:
500
Std Package Height In:
1.75
Std Package Height Mm:
44.45
Std Package Length In:
17.15
Std Package Length Mm:
435.61
Std Package Width In:
4.3
Std Package Width Mm:
109.22
Std Pkg Qty :
50
Std Pkg Uom:
Piece
Sub Brand:
Dome-Top®
Uom Ea Pk:
PK
Department:
Electrical
Product Group:
Wiring Devices

Panduit BT4LH-L0 – Frequently Asked Questions

1) Can this Panduit barb tie be used outdoors in direct sun?
Yes. The BT4LH-L0 is molded from UV-resistant, weather-resistant Nylon 6.6 in black, and it is rated indoor/outdoor. Black UV-stabilized nylon is the grade you want for exterior utility, rooftop and outdoor HVAC runs; a natural (undyed) nylon tie in the same size is indoor-only.
2) Can I install these ties in freezing weather?
Minimum installation temperature is -4 F (-20 C). Below that, nylon gets brittle and the tie can crack as the barb engages, so bring the ties indoors to warm before a cold-weather pull. Once installed, the service range is much wider: -76 F to 185 F (-60 C to 85 C).
3) Which Panduit tools work with the BT4LH-L0 heavy duty tie?
Panduit lists the GTH-E, GS4H-E, GS4EH-E, PTH, STH2 and ST3EH installation tools for this tie. A heavy-duty tie at 0.275 in body width needs a tool sized for it; a light-duty tensioning tool for miniature ties will not feed or cut this body cleanly.
4) How much load will a 120 lb cable tie actually hold?
120 lb (534 N) is the minimum loop tensile strength, meaning the closed loop is rated to that before failure. Cable ties are not rated for overhead support or lifting, so size the bundle weight and any strain relief accordingly. The 0.275 in wide by 0.065 in thick body is what carries that load.
5) Is a Dome-Top barb tie different from a standard pawl cable tie?
The difference is the locking mechanism. Dome-Top barb ties use a one-piece molded barb head rather than a separate pawl, so there is no metal insert and nothing to corrode, and the smooth dome head reduces the chance of snagging or abrading cable jackets as you pull the bundle through a tray. That matters on telecom and data center runs where jacket damage is the failure mode.
6) Is the Panduit BT4LH-L0 UL Listed and RoHS compliant?
It is UL Listed to UL 62275, CSA Recognized, and RoHS compliant. It also carries no lead or mercury content and is ARRA compliant, which matters on federally funded work.
7) How do these Panduit ties come packaged for a large job?
Standard package is 50 pieces, and the standard carton holds 500. Minimum order is 500 pieces. A pallet runs 48,000 pieces if you are buying at project volume.
