Don-Jo 20 Cast Door Pull — 10" CTC, 11" Overall, 3" Projection, 2" Clearance

Don-Jo 20 Cast Door Pull — 10" CTC, 11" Overall, 3" Projection, 2" Clearance

(No reviews yet) Write a Review

Model: 20-630
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$85.70
$73.80
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Don-Jo 20 Cast Door Pull — 10" CTC, 11" Overall, 3" Projection, 2" Clearance

The Don-Jo 20 is a cast door pull engineered for commercial applications, offering a 10" center-to-center (CTC) spacing, 11" overall length, 3" projection, and 2" clearance with a 1" diameter grip. Conforming to ANSI J401 standards, this pull is built to deliver reliable, professional-grade performance across a wide range of commercial door installations. Available in multiple finishes — 313, 315, 605, 606, 613, 628, 629, and 630 — it provides the flexibility to match virtually any architectural hardware scheme.

Key Features

  • Precise Dimensions: 10" center-to-center (CTC) spacing and 11" overall length provide a comfortable, ergonomic grip suited for commercial door applications.
  • Generous Projection & Clearance: 3" projection and 2" clearance ensure easy hand access and comfortable operation for a wide range of users.
  • 1" Diameter Grip: Uniform 1" diameter throughout the pull bar delivers a solid, confident feel and consistent aesthetics.
  • Cast Construction: Manufactured using a cast process for dimensional consistency, strength, and a refined appearance appropriate for commercial environments.
  • ANSI J401 Compliant: Meets ANSI J401 standards, confirming suitability for commercial door hardware applications.
  • Wide Finish Selection: Available in finishes 313, 315, 605, 606, 613, 628, 629, and 630 to coordinate with existing architectural hardware and design requirements.
  • Commercial Grade: Designed and rated for commercial use, making it appropriate for high-traffic doors in offices, retail, healthcare, and institutional settings.

Certifications & Compliance

  • ANSI J401 Compliant
  • Commercial Grade

Technical Specifications

  • Product Group: Door Trim and Accessories
  • Product Subgroup: Door Pulls, Push and Pull Plates
  • Product Type: Door Pulls
  • Subcategory: Pulls and Push Plates
  • Commercial/Residential: Commercial
  • Clearance: 2"
  • Product Model: 20
  • (CTC) Center-to-Center: 10"
  • Product Size: 11"
  • Product Diameter: 1"
  • Product Projection: 3"
  • Product Category: Door Trim and Accessories
  • Department: Door Hardware

Typical Applications

  • Commercial Office Buildings
  • Retail Establishments
  • Healthcare Institutions
  • Educational Facilities
  • Government and Municipal Buildings
  • Multi-Tenant Residential Properties
  • Industrial and Warehouse Facilities

Why Don-Jo 20?

Don-Jo door pulls are crafted using a cast construction process that ensures consistent dimensions, structural integrity, and a polished appearance suited for demanding commercial environments. The Model 20 meets ANSI J401 standards and is available in eight distinct finishes, making it a versatile and dependable choice for architects, contractors, and facility managers seeking professional-grade door trim hardware.

Product Specs

Product Group:
Door Trim and Accessories
Product Subgroup:
Door Pulls, Push and Pull Plates
Product Type:
Door Pulls
Subcategory:
Pulls and Push Plates
Commercial/Residential:
Commercial
Clearance:
2"
ANSI/BHMA:
J401
Product Model:
20
(CTC) Center-to-Center:
10"
Product Size:
11"
Product Diameter:
1"
Product Projection:
3"
Product Category:
Door Trim and Accessories
Department:
Door Hardware

Don-Jo 20-630 – Frequently Asked Questions

1) Will a Don-Jo 20 door pull line up with my existing pull holes at 10 inch centers?
The Don-Jo 20 is drilled on 10 inch centers, so it drops onto an opening already prepped for 10 inch CTC pull holes. Overall length is 11 inches, meaning the grip runs only a half inch past each mounting point, so check you have that much clear rail or stile face beyond the existing holes. If your prep is on any other center spacing, the mounting holes will not line up and the door has to be re-drilled.
2) Is there enough hand clearance on the Don-Jo 20 pull for a gloved hand?
Two inches of clearance between the grip and the door face, with a 3 inch total projection off the door and a 1 inch diameter bar. That 2 inch gap takes a gloved hand or a full fist wrap, which is what you want on a service entrance or a back-of-house door. On a door with a narrow reveal or an adjacent wall return, remember the pull stands 3 inches proud of the face when you check swing clearance.
3) Does the Don-Jo 20 pull meet ANSI J401 for a commercial spec?
J401 is the ANSI/BHMA designation the Don-Jo 20 carries, and it is classed for commercial rather than residential use. If your drawing calls out a J401 pull, this satisfies that line item. J401 is the door pull category under the A156.6 architectural door trim standard, so submit it against that section.
4) Is the Don-Jo 20 a back-to-back set or a single side pull?
Model 20 is one pull, mounted on one face of the door, at 10 inch centers. If you need a matched grip on both faces of a glass or wood door, that is a back-to-back set instead, and the Deltana OHP620 off-set handle pull ships as a back-to-back set, as do the Deltana SSPOBB24 and SSPORBB24 24 inch offset pulls. Note the OHP620 back-to-back set is listed for 1-1/8 to 1-3/8 inch doors, so it will not suit a 1-3/4 inch commercial door.
5) Is a push plate a substitute for the Don-Jo 20 pull?
No. The Don-Jo 20 is a grip bar with 10 inch center-to-center mounting, 3 inch projection and 2 inch clearance, meant for the pull side of the door. A push plate such as the Trimco 1001-1 heavy duty push plate at 3 inches by 12 inches or the Trimco 1041 half-round push plate at 8 inches by 16 inches is a flat protective plate for the push side, with nothing to grip. The two are typically ordered together for the same opening, one per side. If you want a single item covering both faces, the Trimco 1070 series classic push/pull plates at 3-1/2 by 15 inches pair a pull plate with a push plate.
6) What is the closest equivalent to the Don-Jo 20 door pull if I need a 1 inch round grip?
The Don-Jo 20 is a cast pull with a 1 inch diameter grip, 10 inch center-to-center spacing, 11 inch overall length, 3 inch projection and 2 inch clearance. The nearest match on grip diameter is the Ives 8103HD heavy duty straight door pull, a 1 inch round pull with through bolt mounting, and the ABH AB3300 straight flat end pull handle, also 1.00 inch diameter. The Ives 8169 is a 1 inch diameter pull as well but in a C style offset shape rather than a straight bar, so the hand position off the door face differs.
7) I need an ADA compliant pull instead of the Don-Jo 20. What should I use?
The Ives 8145EZHD is the option to specify when ADA compliance is the requirement. It is a 45 degree offset door pull in the EZ series, described as ADA compliant, and ships with heavy duty mounting hardware. The Don-Jo 20 is a straight cast pull conforming to ANSI J401 with 2 inch clearance and 3 inch projection, so if the ADA callout is what governs the opening, the 8145EZHD is the one that carries that designation.
8) What finishes does the Don-Jo 20 cast pull come in, and which ones match stainless or aluminum storefront?
Four finishes are stocked on the Don-Jo 20: 605 polished brass, 613 oil rubbed bronze, 628 satin aluminum, and 630 satin stainless steel. For aluminum storefront and clear anodized frames, 628 is the match. For stainless push and pull plates or a 32D hardware scheme, take 630. 613 pairs with dark bronze anodized entrances, and 605 with a brass trim package.
9) Should I use a straight pull like the Don-Jo 20 or an offset pull on my entrance door?
A straight pull, which is what the Don-Jo 20 is, runs parallel to the door edge on 10 inch centers and is the standard choice where the door has a plain flat face and you just need a grip. An offset pull angles the grip away from the face at one or both ends, which buys knuckle room where a push bar, a lock, or a narrow stile crowds the pull. If that is your situation, the Ives 8145 45 degree offset pull or the Ives 8169 C style offset are the offset equivalents in the same heavy duty class.
10) What is the closest alternative to the Don-Jo 20 if I need a different grip diameter?
Grip diameter on the Don-Jo 20 is 1 inch. If you want the same 1 inch feel from another brand, the Ives 8103HD is a 1 inch round straight pull and the ABH AB3300 is a 1 inch diameter straight flat end pull. Going thinner, the Ives 8102HD uses a 3/4 inch round bar with 1-1/2 inch clearance, and the ABH AB7200 is a 7/8 inch solid stainless bar. Thinner bar means less hand fill on a high traffic entrance, which matters more than it sounds on a door people pull hundreds of times a day.
11) Is the Don-Jo 20 pull heavy enough for a high traffic school or hospital door?
Cast construction and a 1 inch solid grip put the Don-Jo 20 in commercial service rather than residential, and it carries the ANSI J401 pull designation. It is the right weight of hardware for corridor, stairwell, and entrance doors in schools, healthcare, offices, and municipal buildings. Where a facility standardizes on one pull across every opening, the 10 inch CTC and 11 inch length are the common sizes to hold to so future replacements drop into the same prep.
12) Will the Don-Jo 20 pull fit on a narrow stile aluminum door?
Mounting the Don-Jo 20 needs 10 inches of vertical run and enough stile face to take the two posts, and the pull stands 3 inches off the door. On a narrow stile aluminum entrance the constraint is usually stile width, not length, since the posts have to land in the stile and clear the glass stop. Measure your stile face before ordering. On a wide stile or a flush wood or hollow metal door it is a straightforward mount.
13) The Don-Jo 20 grip feels too thick for our doors. Is there a slimmer pull?
The ABH AB7200 is a solid stainless steel flat end pull handle with a 7/8 inch diameter bar and through-bolt mounting, a smaller grip than the 1 inch diameter of the Don-Jo 20. The Ives 8102HD is a heavy duty straight pull built on a 3/4 inch round bar with 1-1/2 inch clearance, thinner again and with less hand space behind the bar than the Don-Jo 20's 2 inch clearance.
14) Which pull should I order for a restroom door where staff open with a forearm or elbow?
The Trimco 1035 Ultimate Restroom Pull is the heavy duty pull built specifically for restroom doors, where the intent is to open without gripping with the hand. The Don-Jo 20 is a general commercial cast pull with a 1 inch round grip and 2 inch clearance, suited to a conventional hand grip on offices, retail and institutional doors rather than to a hands-free restroom exit.
15) The Don-Jo 20 only comes in an 11 inch length. What pull do I use if I need a custom length?
The ABH AB3330 series is an offset round end pull offered with custom length options, so it is the one to specify when the opening calls for a length the fixed-size pulls do not cover. The Don-Jo 20 is built to a set 11 inch overall length with 10 inch center-to-center spacing. The ABH AB3310 offset flat end pull is a commercial grade surface mount option in the same offset family if a flat end profile suits the design.
16) Is there a longer single-side pull than the Don-Jo 20 for a full-height glass door?
The Deltana SSP1210 is a 12 inch contemporary pull supplied for single side mounting, a longer single-face option than the Don-Jo 20's 11 inch overall length. For a considerably longer reach on a tall glass leaf, the Deltana SSPORBB24 is a 24 inch round offset pull, though it comes as a back-to-back pair rather than a single side.
17) Which pull has more knuckle clearance than the Don-Jo 20 for gloved hands?
The Don-Jo 20 carries 2 inch clearance and 3 inch projection with a 1 inch round grip. Among comparable straight pulls, the Ives 8102HD lists 1-1/2 inch clearance on a 3/4 inch round bar, which is less hand space behind the bar than the Don-Jo 20 provides. If gloved or gripped-with-a-load use is the concern, the Don-Jo 20's 2 inch clearance is the larger of the two figures stated in the set.
