Don-Jo PL-13515 Pull Plate, 3-...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$68.90
$61.87
Don-Jo PL-13515 Pull Plate, 3-1/2" Width x 15" Length with 1-3/4" Projection

Don-Jo PL-13515 Pull Plate, 3-1/2" Width x 15" Length with 1-3/4" Projection

(No reviews yet) Write a Review

Model: PL-13515-630
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$68.90
$61.87
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Don-Jo PL-13515 Pull Plate, 3-1/2" Width x 15" Length with 1-3/4" Projection

The Don-Jo PL-13515 is a commercial-grade display packaged pull plate measuring 3-1/2" in width and 15" in length, with a 1-3/4" projection for a comfortable, ergonomic grip. Designed for commercial door applications, this pull plate is available in multiple finishes — 605, 613, and 630 — to complement a wide range of door hardware and architectural styles. Built to Don-Jo's professional standards, the PL-13515 delivers reliable performance and a clean, finished appearance for high-traffic commercial environments.

Key Features

  • Precise Dimensions: Measures 3-1/2" in width and 15" in length, providing a proportional, professional appearance suited for commercial door applications.
  • Comfortable Projection: Features a 1-3/4" projection that ensures a secure, ergonomic grip for ease of use in high-traffic settings.
  • Multiple Finish Options: Available in finishes 605, 613, and 630 to coordinate with existing door hardware and architectural design requirements.
  • Commercial-Grade Construction: Engineered for commercial use, delivering the durability and reliability demanded by professional door hardware applications.
  • Display Packaged: Shelf pack of 1, making it convenient for display and retail or distributor stocking.
  • Versatile Door Trim Accessory: Classified under Door Pulls, Push and Pull Plates, making it a straightforward solution for completing door hardware installations.

Technical Specifications

  • Product Group: Door Trim and Accessories
  • Product Subgroup: Door Pulls, Push and Pull Plates
  • Product Type: Push and Pull Plates
  • Subcategory: Pulls and Push Plates
  • Commercial/Residential: Commercial
  • Package: No
  • Product Category: Door Trim and Accessories
  • Department: Door Hardware

Typical Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Don-Jo PL-13515?

Don-Jo pull plates are engineered to meet the demands of commercial door hardware applications, combining precise dimensional specifications — 3-1/2" width, 15" length, and 1-3/4" projection — with a choice of professional finishes including 605, 613, and 630. The PL-13515 reflects Don-Jo's commitment to delivering dependable, professionally finished door trim accessories that perform reliably in demanding, high-traffic commercial environments.

Product Specs

Product Group:
Door Trim and Accessories
Product Subgroup:
Door Pulls, Push and Pull Plates
Product Type:
Push and Pull Plates
Subcategory:
Pulls and Push Plates
Commercial/Residential:
Commercial
Package:
No
Product Model:
PL 13515
Product Category:
Door Trim and Accessories
Department:
Door Hardware

Don-Jo PL-13515-630 – Frequently Asked Questions

1) What size door will a Don-Jo PL-13515 pull plate fit, and how much does it stick out from the face?
The PL-13515 plate measures 3-1/2 inches wide by 15 inches long, with the pull standing 1-3/4 inches off the plate. That 15 inch length runs vertically on the door face, so you need a stile at least 3-1/2 inches wide to land the plate flat. On a narrow stile aluminum door with less than 3-1/2 inches of flat face, it will overhang the glass stop, and a narrower pull plate is the better call.
2) Is the Don-Jo PL-13515 a pull plate or a push plate? Do I need both sides?
It is a pull plate, meaning it has a grip handle mounted on the plate. On a swinging door with no latch hardware you normally pair it with a flat push plate on the opposite face, so the pull side is the pull face and the push side gets the plain plate. The PL-13515 covers the pull face only. Delaney's 3-1/2 x 15 push plate is the matching flat plate in the same footprint if you want the pair to line up dimensionally.
3) Is the Don-Jo PL-13515 heavy enough for a high traffic entrance, or should I spec something else?
The PL-13515 is rated by Don-Jo as a commercial product and is built for commercial door use, which covers offices, schools, healthcare, retail, and multi-tenant buildings. For an abused main entrance where the pull takes body weight every cycle, a heavy duty cast plate is the stronger spec: Ives lists the 8302 as a heavy duty pull plate with through bolt mounting, and Trimco's 1010, 1012, and 1013 are heavy duty cast plates. Through bolting is what keeps a pull from working loose on a high cycle door.
4) I'm replacing a pull plate on an existing door. Will the Don-Jo PL-13515 cover the old screw holes?
It depends on what came off. The PL-13515 is a 3-1/2 by 15 inch plate, so it covers anything with a smaller footprint and hides the old fastener holes underneath. If you are pulling off a 4 by 16 plate, it will not cover the perimeter marks left behind, and you would want a same-size replacement like the Delaney 4 x 16 pull plate instead. Measure the existing plate before you order.
5) What cast pull plates can I use instead of the Don-Jo PL-13515 if the architect specified a particular pull center-to-center?
Trimco's cast plates are specified by pull center-to-center: the 1010 Series cast pull plate has a 5 inch CTC pull, the 1012 is a cast tapered heavy duty plate with a 5.5 inch CTC pull, the 1013 is a round heavy duty plate with a 5.5 inch CTC pull, and the 1014 Series is a half-round plate with a 6 inch CTC pull. The Don-Jo PL-13515 is specified instead by plate size and grip clearance - 3-1/2 inches by 15 inches with a 1-3/4 inch projection - so match to the drawing on whichever dimension the spec calls out.
6) What is a direct equivalent to the Don-Jo PL-13515 pull plate in the same 3-1/2 inch by 15 inch size?
The Delaney 3-1/2" x 15" Door Pull Plate is the closest size-for-size match, built in the same 3-1/2 inch by 15 inch pull plate series as the Don-Jo PL-13515. Both are pull plates, meaning the plate carries a pull handle rather than a flat pushing surface, so either one serves the same pull side of a commercial door opening.
7) I need a push plate rather than a pull plate for the opposite side of the door. What matches the Don-Jo PL-13515?
The Delaney 3-1/2" x 15" Push Plate is the push-side counterpart in the same 3-1/2 inch by 15 inch footprint. The Don-Jo PL-13515 has a pull handle with a 1-3/4 inch projection for gripping, while a push plate is a flat plate with no handle, intended for the swing side where the door is pushed open. Pairing the two gives a matched push/pull set on one opening.
8) For a heavy traffic entrance, is there a more robust pull plate than the Don-Jo PL-13515?
Yes. The Ives 8302 is a heavy duty pull plate with through bolt mounting, which carries the pull load through the door rather than relying on face screws alone - a common choice on entrances that are pulled hundreds of times a day. The Ives 8303 is also heavy duty and is offered with 8 inch or 10 inch center-to-center pull mounting. The Don-Jo PL-13515 is a commercial-grade plate at 3-1/2 inches by 15 inches with a 1-3/4 inch projection and is a lighter-profile trim piece by comparison.
9) What finishes does the Don-Jo PL-13515 pull plate come in?
Three: polished brass (605), oil rubbed bronze (613), and satin stainless steel (630). For most commercial office, school, and healthcare work, 630 satin stainless is the one that matches existing levers, hinges, and push plates, since it is the standard commercial finish. Pick 605 or 613 when you are matching decorative brass or dark bronze trim already on the openings.
10) Can I use the Don-Jo PL-13515 with an exit device on a storefront door?
Not as a device trim. The PL-13515 is a standalone pull plate for the pull face of a door, with no prep for connecting to an exit device chassis. When you need a pull plate that works with a panic, you want the manufacturer's matched trim, such as the Detex P/PN Series pull plate made for their Value Series exit devices.
11) What's the difference between the Don-Jo PL-13515 and a decorative pull plate like Emtek's?
The PL-13515 is a plain commercial rectangular plate, 3-1/2 by 15 inches, meant to blend with standard institutional hardware. Emtek's push and pull plate lines (Knoxville, Modern, and the lost wax cast bronze Petal) are decorative styled plates for residential and high-end interior openings. If the door is in an office corridor or a school, the Don-Jo is the right type; if it's a designer entry, the decorative lines are what get specified.
12) Does the Don-Jo PL-13515 pull plate have a handing?
No handing to specify. It is a symmetrical rectangular plate with the pull centered, so the same part works on a left hand or right hand door, and on either an in-swing or out-swing leaf. You only decide which face of the door it goes on, which is the pull side.
13) My existing plate is larger than 3-1/2 by 15 and I want to cover the old screw holes. What is a bigger alternative to the PL-13515?
The Delaney 4" x 16" Door Pull Plate is the larger option, in a 4 inch by 16 inch pull plate series versus the Don-Jo PL-13515's 3-1/2 inch by 15 inch plate. The extra half inch of width and inch of length gives more coverage over previous fastener holes or worn finish on the door face. Its push-side mate is the Delaney 4" x 16" Push Plate.
14) Will the Detex P/PN pull plate work as a substitute for the Don-Jo PL-13515?
Not as a general substitute. The Detex P/PN Series pull plate is made for Detex Value Series exit devices, so it belongs on an opening equipped with that exit hardware. The Don-Jo PL-13515 is standalone door trim - a 3-1/2 inch by 15 inch pull plate with a 1-3/4 inch projection for commercial doors - with no tie to a specific exit device. Choose the Detex only if you are trimming a Value Series device.
15) Is there a decorative pull plate option if the Don-Jo PL-13515 looks too plain for the space?
Emtek offers styled push and pull plate sets: the Modern series for a contemporary look, the Knoxville series, and the Petal series in lost wax cast bronze. Those are design-driven trim aimed at architectural appearance. The Don-Jo PL-13515 is a commercial-grade plate offered in finishes 605 polished brass, 613 oil rubbed bronze, and 630 satin stainless steel, which is the palette that typically coordinates with standard commercial lock and exit hardware.
16) How is the Don-Jo PL-13515 packaged if I'm stocking it on a shelf?
It ships display packaged, one plate per shelf pack. That suits retail pegboard and counter display for a distributor or a supply house, and it means each finish is ordered as an individual piece rather than a bulk carton.
17) For a facility standardizing pull plates across many doors, how do the Ives and Trimco plates differ from the Don-Jo PL-13515?
The Ives 8302 and 8303 are heavy duty plates, the 8302 using through bolt mounting and the 8303 offered in 8 inch or 10 inch center-to-center pull spacing. Trimco's 1010, 1012 and 1013 are cast heavy duty plates with 5 inch to 5.5 inch CTC pulls in tapered and round profiles. The Don-Jo PL-13515 is a commercial-grade plate defined by a single 3-1/2 inch by 15 inch size and 1-3/4 inch projection in three finishes, which keeps the ordering simple when one size repeats across an entire building.
