B-Line Eaton series fastener hardware and accessories, Suitable for solid and hollow core materials, Zinc plated, 3/8" x 3",50-300HN SLEEVE ANCHR HEX

The B-Line ASA-50-300HN sleeve anchor is rated for both solid and hollow core base materials, so it works in poured concrete and in hollow block or brick where a wedge anchor would spin out. The expansion sleeve spreads load over a longer section of the hole rather than gripping at one point, which is why it tolerates hollow substrates.

Yes. The ASA-50-300HN carries a UL Listed marking, which is what inspectors look for when anchors are supporting conduit, strut, cable tray or fixture hangers. That plus the electrical department classification makes it a normal spec item for raceway and support attachment to masonry.

On hollow block, use the sleeve anchor. Wedge anchors need solid concrete to develop their grip and are the better choice for heavy structural attachment in poured slabs and walls. This B-Line anchor is a sleeve type expansion anchor rated for solid and hollow core materials, which is the case strut on CMU usually falls into. In poured concrete either type works; in block the sleeve is what holds.

Zinc plating is the finish on this B-Line sleeve anchor, which is a mild corrosion barrier intended for dry interior and protected use. For a wet vault, coastal exposure, or anything continuously damp, specify a hot-dip galvanized or stainless anchor instead rather than relying on zinc plate.

It's the hex nut version: a hex nut and washer on a threaded stud. You drill, drop the anchor through the fixture into the hole, and tighten the nut with a wrench or socket to expand the sleeve. No separate setting tool is needed, and because the nut is removable the fixture can be taken off later without destroying the anchor.

The anchor ships as a complete assembly with its expansion sleeve, nut and washer, so nothing else is required to make the attachment. What you do need is a masonry bit matched to the anchor diameter and a hole drilled deeper than the anchor embedment so debris has somewhere to go. Blow or vacuum the hole out before setting.
