Eaton B-Line series panels and panel accessories, NEMA 12, White powder coated, Used in installation of all JIC enclosures, Stainless steel, JIC and small panels, Panels and panel accessories, Stainless panel
Manufacturer Resources
Product Specs
- Application:
- Used in installation of all JIC enclosures
- Certifications:
- UL Listed
- Degree Of Protection:
- NEMA 12
- Product Category:
- Panels & panel accessories
- Product Height:
- 14.87 in
- Product Length Depth:
- 14.87 in
- Product Weight:
- 4.069 lb
- Product Width:
- 14 in
- Department:
- Electrical
- Product Group:
- Panels & Plates
- Product Subgroup:
- Panel Accessories
- Product Type:
- JIC & small panels
- Product Details:
- JIC & small panels
- Product Material:
- Stainless steel
B-LINE AW1614SP – Frequently Asked Questions
1) What size panel is the B-Line AW1614SP and what enclosure does it fit?
The Eaton B-Line AW1614SP is a JIC-style back panel measuring 14.87 x 14.87 x 14 inches as listed, and it is made for installation in JIC enclosures. Match those panel dimensions against the mounting studs in your enclosure before ordering, since a JIC panel sits on welded studs rather than bolting to the enclosure walls.
2) Is the AW1614SP panel stainless steel or painted steel?
It is stainless steel with a white powder coated finish. The white coat gives you a light background for tracing wiring and component layout, while the stainless base is the reason this panel holds up in washdown and corrosive areas where a plain cold rolled steel panel would rust at the drill points.
3) Will a stainless JIC panel work in a NEMA 12 control enclosure?
Yes. The AW1614SP is rated to NEMA 12, the dust-tight and drip-tight indoor class used for most industrial control cabinets, and it is UL Listed. A back panel does not create the enclosure rating on its own, but this one is specified to the same NEMA 12 class so it will not undercut a NEMA 12 cabinet.
4) Does the AW1614SP come with mounting hardware or studs?
The AW1614SP is the stainless back panel by itself. JIC enclosures carry their own welded mounting studs and supply the nuts, so order the panel to suit the enclosure you already have rather than expecting fasteners in the box.
5) Can I drill and tap this B-Line panel for DIN rail and contactors?
Yes, that is what a back panel is for. The AW1614SP is a flat stainless plate you lay out and drill for DIN rail, wire duct, contactors and terminal blocks. With stainless, use a sharp bit at lower speed and steady feed pressure so you cut rather than work-harden the material, and touch up the powder coat at any exposed edge you want to keep uniform.
