B-Line Eaton series strut fitt...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$6,752.94
B-Line Eaton series strut fittings and accessories, 3.93" Height, 3.75" Length, 1.62" Width, .76lbs, Aluminium, Pre-assembled fitting, Four hole adjus

B-Line Eaton series strut fittings and accessories, 3.93" Height, 3.75" Length, 1.62" Width, .76lbs, Aluminium, Pre-assembled fitting, Four hole adjus

(No reviews yet) Write a Review

Model: B115AL
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$6,752.94
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Eaton B-Line series strut fittings and accessories, 3.93" Height, 3.75" Length, 1.62" Width, .76lbs, Aluminium, Pre-assembled fitting, Four hole adjustable corner angle, 90 deg, Thickness 1/4 in, Aluminum

Manufacturer Resources

Product Specs

Certifications:
Not Applicable
Material Gauge:
1/4"
Product Height:
3.93 in
Product Length Depth:
3.75 in
Product Weight:
.76 lb
Product Width:
1.62 in
Special Features:
Pre-assembled fitting
Department:
Electrical
Product Type:
Four hole adjustable corner angle, 90 deg
Product Finish:
Aluminum
Product Details:
Four hole adjustable corner angle, 90 deg
Product Material:
Aluminum
Product Length:
3.75 in

B-LINE B115AL – Frequently Asked Questions

1) What does the B-Line B115AL corner angle actually do on a strut run?
The B115AL is a four hole adjustable corner angle that joins two pieces of strut at a 90 degree corner. Two holes land in each leg of the connection, so it carries the joint rather than just locating it. It ships as a pre-assembled fitting, so the angle arrives put together and you are only adding the strut nuts and bolts at the channel.
2) Do bolts and strut nuts come with the B115AL?
Order the channel hardware separately. The B115AL ships as a pre-assembled fitting, meaning the angle itself is assembled, but the strut nuts and bolts that fasten it into the channel are a separate line item. Size them to the strut series you are attaching to, typically 1/2-13 or 3/8-16 spring nuts.
3) How thick is the B-Line B115AL angle bracket?
The material gauge is 1/4 inch. That is a solid-plate fitting rather than a formed light-gauge bracket, which is what you want at a load-bearing corner in a trapeze or rack frame instead of a simple alignment tie.
4) What are the dimensions of the B115AL corner angle so I can check clearance behind my strut?
It measures 3.93 x 3.75 x 1.62 inches (height, length/depth, width as B-Line lists them). Use the 1.62 inch figure for the face width against the channel and the 3.93 and 3.75 figures for how far each leg reaches past the corner, which is the number that decides whether the fitting clears a wall, a conduit run, or an adjacent strut.
5) Does the B115AL only work at exactly 90 degrees, or can I set another angle?
It is an adjustable corner angle rated at 90 degrees, so the slotted adjustment lets you shift the joint off square to pick up a corner that is not dead true. If your design calls for a fixed non-square angle, a dedicated angle fitting for that degree is the cleaner choice than forcing this one.
6) What part number do I order for the B-Line aluminum four hole 90 degree corner angle?
Order Eaton B-Line part number B115AL. The AL suffix is the aluminum version, which is the distinction to watch when someone hands you a B-Line number off a drawing, since the plain and plated steel variants of the same angle carry different suffixes.
