Eaton B-Line series wireway hanger, Wireway hangers(drop), NEMA 12, Steel, 6" X 6"
Manufacturer Resources
Product Specs
- Certifications:
- UL Listed
- Product Height:
- 16 in
- Product Length Depth:
- .067 in
- Product Weight:
- .697 lb
- Product Width:
- 8.25 in
- Special Features:
- NEMA12
- Department:
- Electrical
- Product Group:
- Mounting Hardware
- Product Subgroup:
- Hangers
- Product Type:
- Wireway hangers(drop)
- Product Details:
- Wireway hangers(drop)
- Product Material:
- Steel
B-LINE 66-12DH – Frequently Asked Questions
1) What size wireway does the B-Line 66-12DH hanger fit?
The Eaton B-Line 66-12DH drop hanger is sized for 6 x 6 inch wireway. If your run is 4 x 4, 8 x 8 or 12 x 12, this is the wrong hanger, you need the drop hanger matched to that cross section.
2) Can I use a NEMA 1 wireway hanger on NEMA 12 wireway?
No, and that mismatch is the common ordering error. NEMA 12 wireway bodies differ dimensionally from NEMA 1 screw-cover trough, so the hanger is specific to the type. The 66-12DH is the NEMA 12, 6 x 6 hanger.
3) What is a drop hanger used for on a wireway run?
A drop hanger suspends the wireway below the structure, typically off threaded rod or from a trapeze, rather than bolting it flat to a wall. The 66-12DH cradles a 6 x 6 wireway in that hung configuration; if you are surface mounting against a wall or column, you want a wall bracket instead of a drop hanger.
4) How much clearance do I need for the B-Line 66-12DH hanger?
Plan the layout around 16 inches of height and 8.25 inches of width for the hanger itself. On a 6 x 6 wireway that leaves drop length above the trough, so check your ceiling-to-wireway dimension before you cut rod.
5) Does the B-Line 66-12DH come with threaded rod or anchors?
The 66-12DH is the hanger only, one piece of formed steel. Threaded rod, nuts, washers and the overhead anchor or beam clamp are separate items and need to be ordered with it to complete the support.
6) What material and gauge is the 66-12DH wireway hanger?
Steel, formed from .067 inch stock, and it weighs .697 lb per hanger. That is a light, thin-formed steel part, so support spacing should follow the wireway manufacturer's published hanger interval rather than being stretched out.
