B-Line Eaton series wireway sy...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$439.34
B-Line Eaton series wireway system adapter, Includes sealing plate kits, Adapter for Hammond® Mfg, 12, Steel, ANSI 61 gray painted finish

B-Line Eaton series wireway system adapter, Includes sealing plate kits, Adapter for Hammond® Mfg, 12, Steel, ANSI 61 gray painted finish

(No reviews yet) Write a Review

Model: 22-12LAHM
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$439.34
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Eaton B-Line series wireway system adapter, Includes (2) sealing plate kits, Adapter for Hammond® Mfg, NEMA 12, Steel, ANSI 61 gray painted finish

Manufacturer Resources

Product Specs

Certifications:
UL Listed
Finish Color:
ANSI 61 gray painted
Product Height:
2.5 in
Product Length Depth:
11.94 in
Product Weight:
4.583 lb
Product Width:
2.5 in
Special Features:
Includes (2) sealing plate kits, NEMA12
Department:
Electrical
Product Group:
Connectors & Adapters
Product Subgroup:
Adapters
Product Type:
Adapter for Hammond® Mfg
Product Details:
Adapter for Hammond® Mfg
Product Material:
Steel

B-LINE 22-12LAHM – Frequently Asked Questions

1) What does the Eaton B-Line 22-12LAHM wireway adapter actually do?
It joins an Eaton B-Line wireway run to Hammond Mfg wireway, so you can tie two different manufacturers' trough systems together without fabricating a transition. It is a NEMA 12 rated adapter in steel with an ANSI 61 gray painted finish, and two sealing plate kits come in the box.
2) Do I need to buy gaskets or sealing plates separately to keep a NEMA 12 wireway sealed at the transition?
No. Two sealing plate kits ship with the 22-12LAHM adapter, which is what keeps the joint to the NEMA 12 rating for dust and dripping liquid. Screws and any additional wireway connectors for the rest of the run are not part of it.
3) Is this B-Line to Hammond wireway adapter UL Listed for an inspected industrial job?
Yes, the 22-12LAHM is UL Listed. That plus the NEMA 12 construction is normally what an inspector wants to see on a dust-tight wireway transition in a plant or shop environment.
4) Can I use this adapter in a washdown or outdoor location?
Not for those. NEMA 12 covers falling dirt, circulating dust, and dripping non-corrosive liquid, not hosedown or weather exposure. For washdown or outdoor wireway you want a NEMA 4 or 4X rated trough and matching transition instead of this adapter.
5) Will the gray finish match the wireway already installed in my plant?
The adapter is painted ANSI 61 gray, the standard light gray used across industrial enclosures and wireway, so it blends with existing B-Line and Hammond trough finished the same way. Substrate is steel, so touch-up paint behaves the same as the rest of the run.
