B-Line Eaton series wireway te...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$2,218.71
Image coming soon

B-Line Eaton series wireway telescoping fitting, Feed through, Wireway telescoping fitting, 4X rated, Stainless steel, Brushed finish, 4" X 4"

(No reviews yet) Write a Review

Model: 44-4XSFT

In Stock (leaves warehouse same day if ordered before 3pm ET)

$2,218.71
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Eaton B-Line series wireway telescoping fitting, Feed through, Wireway telescoping fitting, NEMA 4X rated, Stainless steel, Brushed finish, 4" X 4"

Manufacturer Resources

Product Specs

Certifications:
UL Listed
Finish Color:
Brushed finish
Product Height:
4 in
Product Length Depth:
15.5 in
Product Weight:
6.661 lb
Product Width:
4 in
Special Features:
NEMA 4X
Wiring Method:
Feed through
Department:
Electrical
Product Type:
Wireway telescoping fitting
Product Details:
Wireway telescoping fitting
Product Material:
Stainless steel

B-LINE 44-4XSFT – Frequently Asked Questions

1) Will the B-Line 44-4XSFT telescoping fitting work with 4 x 4 inch wireway?
Yes. The Eaton B-Line 44-4XSFT is sized for 4 inch by 4 inch wireway, with a stated product height of 4 inches and width of 4 inches. It will not mate to 6x6 or 8x8 trough; those need a fitting built for that cross section.
2) Can this B-Line telescoping fitting be used outdoors or in a washdown area?
It is built to NEMA 4X, which covers outdoor and corrosive or washdown environments, and it is UL Listed. The body is stainless steel with a brushed finish, so it holds up where painted steel wireway would corrode. Every component in the run, including covers and gaskets, has to carry the same 4X rating for the enclosure to perform.
3) How much length can the 44-4XSFT telescoping fitting cover?
The fitting measures 15.5 inches in overall length depth, so it spans a gap within that range as it telescopes. Take your field measurement between the two wireway ends before ordering, since a gap longer than the fitting's reach needs a cut section of wireway plus couplings instead.
4) What is a wireway telescoping fitting used for?
It closes a gap between two runs of wireway that cannot be brought together, or lets you make up a run when the field measurement does not land on a standard length. The 44-4XSFT slides to take up the difference and is a feed through fitting, so conductors pass straight through with no pull point or change of direction.
5) Is the B-Line 44-4XSFT stainless or painted steel?
Stainless steel with a brushed finish, not painted. That matters in food processing, marine, and chemical areas where a painted carbon steel fitting would rust at the seams. Match it to stainless wireway so you are not pairing dissimilar metals in the run.
6) What part number do I order for the Eaton B-Line 4x4 NEMA 4X stainless telescoping fitting?
Order Eaton B-Line catalog number 44-4XSFT. That is the 4 inch by 4 inch, NEMA 4X, stainless steel feed through telescoping fitting. There is one configuration, so no finish or size suffix to specify.
7) How heavy is the 4x4 stainless telescoping wireway fitting, and can one person set it?
It weighs 6.661 lb, so a single installer can hold it in place while making up the screws on an overhead run.
