Bussmann KTS-R-3 Eaton series ...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$213.10
$126.53
Bussmann KTS-R-3 Eaton series KTS-R fuse, LIMITRON Fast-acting fuse, 70/30 brass end cap, Panelboards, 3 A, 1, Class RK1, Non-indicating, Ferrule end x ferrule end, 200 kAIC at 600 Vac, Melamine glass tube, Standard, 600 V

Bussmann KTS-R-3 Eaton series KTS-R fuse, LIMITRON Fast-acting fuse, 70/30 brass end cap, Panelboards, 3 A, 1, Class RK1, Non-indicating, Ferrule end x ferrule end, 200 kAIC at 600 Vac, Melamine glass tube, Standard, 600 V

(No reviews yet) Write a Review

Model: KTS-R-3
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$213.10
$126.53
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Bussmann KTS-R-3 Eaton series KTS-R fuse, LIMITRON Fast-acting fuse, 70/30 brass end cap, Panelboards, 3 A, 1, Class RK1, Non-indicating, Ferrule end x ferrule end, 200 kAIC at 600 Vac, Melamine glass tube, Standard, 600 V.

  • Amp rating: 3 A
  • Voltage rating: 600 V
  • Class: Class RK1
  • Interrupt rating: 200 kAIC at 600 Vac
  • Product type: Fuse
  • Dimensions (L x W x H): 0.8 x 0.8 x 5 in

Genuine Bussmann part number KTS-R-3.

Manufacturer Resources

Product Specs

Amperage Rating:
3A
Class:
Class RK1
Compliances:
CE Marked
Connection:
Ferrule end x ferrule end
Fuse Indicator:
Non-indicating
Interrupt Rating:
200 kAIC at 600 Vac
Number Of Elements:
1
Packaging Type:
Standard
Product Height:
5 in
Product Length Depth:
.8 in
Product Weight:
.13 lb
Product Width:
.8 in
Special Features:
70/30 brass end cap
Voltage Rating:
600V
Department:
Electrical
Product Material:
Melamine glass tube
Product Type:
Fast-Acting Fuse
Product Group:
Circuit Protection
Product Subgroup:
Fuses
Product Length:
0.8 in

Bussmann KTS-R-3 – Frequently Asked Questions

1) Can I use a 600 V KTS-R-3 fuse on a 240 V or 480 V circuit?
Yes. The KTS-R-3 carries a 600 V rating, and a fuse may be applied at or below its voltage rating, so it works on 208, 240 and 480 V systems as well. What you cannot do is go the other way and put a 250 V fuse into a 600 V circuit. Its interrupting rating is 200 kAIC at 600 Vac.
2) Is the KTS-R-3 fast-acting or time-delay, and can I use it ahead of a motor?
Fast-acting. The LIMITRON KTS-R is a single-element fast-acting design, so it has no intentional time delay and will open on motor inrush if sized at nameplate. Use it for non-inductive loads, panelboards, feeders and circuits where you want the quickest clearing. For a motor branch circuit you want a dual-element time-delay Class RK fuse such as the Bussmann FRS-R instead.
3) Can a KTS-R-3 replace an existing KTS-R or RK1 fuse of the same rating in my panelboard?
Yes, as a direct swap for any 3 A, 600 V Class RK1 ferrule fuse. Match three things when replacing: 3 A amperage, 600 V, and the RK1 class. If the old fuse was a dual-element time-delay RK5, the KTS-R-3 will physically fit the same clips but clears faster, so do not substitute it on a motor or transformer circuit.
4) Is 200,000 AIC enough for my service with a high available fault current?
The KTS-R-3 interrupts 200 kA at 600 Vac, which covers essentially any commercial or industrial service point you will encounter, and as a current-limiting Class RK1 fuse it also reduces let-through energy so downstream gear can be series rated. Confirm the available fault current from your utility study is at or below 200 kA.
5) Does the KTS-R-3 have a blown fuse indicator?
No. It is non-indicating, so there is no window or pop-out pin to tell you it has opened. You will need a meter or continuity check to identify the blown leg, which is worth knowing if you are standardizing a panel where techs rely on visual indication.
6) How is the Bussmann KTS-R-3 packaged and what part number do I order?
Order genuine Bussmann part number KTS-R-3. It ships in standard packaging as individual fuses, not a sealed carton assortment, so you can buy the exact count a panel needs rather than a full box.
