Eaton CH Mechanical Interlock 225A Three-Phase 10kAIC NEMA 1 Enclosure

Eaton CH Mechanical Interlock 225A Three-Phase 10kAIC NEMA 1 Enclosure

(No reviews yet) Write a Review

Model: CHPMIKCSR

In Stock (leaves warehouse same day if ordered before 3pm ET)

$241.50
$224.39
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton CH Mechanical Interlock 225A Three-Phase 10kAIC NEMA 1 Enclosure

Professional Electrical Safety & Control Solution

The Eaton CH Mechanical Interlock delivers reliable three-phase electrical control with 225A capacity and 10kAIC interrupt rating in a NEMA 1 enclosure. This professional-grade interlock system features aluminum bus construction for dependable performance in commercial and industrial applications requiring mechanical safety interlocking.

Professional Features & Benefits

  • 225A Amperage Rating: Handles substantial electrical loads for commercial and industrial three-phase applications with reliable capacity.
  • Three-Phase Configuration: Designed specifically for three-phase electrical systems providing balanced power distribution and control.
  • 10kAIC Interrupt Rating: Provides robust short-circuit protection capability for enhanced electrical safety and system reliability.
  • NEMA 1 Enclosure: Indoor-rated enclosure protects internal components from dust and accidental contact in general purpose applications.
  • Aluminum Bus Material: Lightweight yet durable bus construction ensures reliable electrical conductivity and long-term performance.
  • Mechanical Interlock Design: Prevents simultaneous operation of connected devices, providing essential safety control for transfer applications.

Technical Specifications

  • Amperage Rating: 225 A
  • Bus Material: Aluminum
  • Certifications: Contact Manufacturer
  • Enclosure: NEMA 1
  • Interrupt Rating: 10 kAIC
  • Phase: Three-phase
  • Product Details: Interlock
  • Product Height: 1.1 in
  • Product Length Depth: 34.1 in
  • Product Weight: 8.6 lb
  • Product Width: 14.3 in

Professional Applications

  • Commercial Facilities requiring three-phase power control and safety interlocking
  • Industrial Manufacturing with mechanical interlock safety requirements
  • Multi-Unit Properties needing reliable electrical transfer control systems
  • Professional Offices with three-phase electrical distribution systems
  • Retail Establishments requiring robust electrical safety and control solutions
  • Light Industrial applications demanding mechanical interlock protection

Why Choose Eaton Quality?

Eaton delivers professional-grade electrical control solutions with proven reliability and durability. The NEMA 1 enclosure rating and aluminum bus construction ensure dependable performance, while the mechanical interlock design provides essential safety control for critical electrical applications.

Manufacturer Resources

Product Specs

Amperage Rating:
225 A
Bus Material:
Aluminum
Certifications:
Contact Manufacturer
Configuration:
NEMA 1
Interrupt Rating:
10 kAIC
Phase:
Three-phase
Product Details:
Interlock
Product Height:
1.1 in
Product Length Depth:
34.1 in
Product Weight:
8.6 lb
Product Width:
14.3 in
Department:
Electrical
Product Group:
Boxes & Enclosures
Product Type:
Enclosure

Eaton CHPMIKCSR – Frequently Asked Questions

1) What does the Eaton CHPMIKCSR mechanical interlock actually do in a panel?
The Eaton CH mechanical interlock, model CHPMIKCSR, is a mechanical kit that prevents two connected devices from being closed at the same time. That's the classic utility-versus-generator arrangement: one breaker can be on, never both. It is a three-phase, 225 A rated assembly with a 10 kAIC interrupt rating in a NEMA 1 enclosure. It is not a transfer switch and it does not switch anything automatically, an operator moves the handle.
2) Can I mount the Eaton CHPMIKCSR interlock outdoors or in a wet location?
No. The enclosure rating is NEMA 1, which is a general purpose indoor rating. It guards against dust and incidental contact with live parts, nothing more. For an exterior wall, a parking structure, a wash-down area, or anywhere rain or hose spray reaches, you need a rainproof or watertight enclosure instead. Keep this one in a clean, dry electrical room or interior utility space.
3) Will a 10 kAIC interrupt rating be enough for my service?
Only if the available fault current at the point of installation is at or below 10 kAIC, which is the rating carried here. On a small commercial service well downstream of the transformer that is usually fine. Close to a large pad-mount transformer, or on a big multi-family or industrial service, available fault current often runs well above 10 kA and this assembly would be under-rated. Have the fault current calculated at the panel location before you commit.
4) Is the Eaton CHPMIKCSR suitable for single-phase residential service?
No. This one is built for three-phase systems and rated 225 A. For a single-phase house panel you want the single-phase version of the CH interlock, not this assembly. The three-phase configuration is what makes it appropriate for commercial, light industrial, and multi-unit three-phase distribution.
5) Can I use the Eaton CHPMIKCSR as a generator transfer setup for a commercial building?
It works as manual transfer control. The mechanical interlock physically blocks both sources being closed together, so utility and generator can never be paralleled. It is manual, though, so someone has to be on site to throw the handles during an outage. If the building needs unattended changeover, such as life safety or refrigerated load, specify an automatic transfer switch instead. Also confirm your generator and main breaker sizing fits the 225 A three-phase rating.
6) Which Eaton loadcenter line does this interlock belong to?
It is part of Eaton's CH line, ordered as model CHPMIKCSR. CH and BR are separate breaker and loadcenter families at Eaton and their accessories are not cross-compatible, so if your panel is BR this interlock is the wrong part. Match the panel family before ordering.
7) What are the dimensions and weight of the Eaton CH 225A interlock enclosure?
The stated dimensions are 34.1 in length/depth, 14.3 in width, and 1.1 in height, at 8.6 lb. It's a light, flat assembly, so one person can hold it while fastening, but plan wall or panel space for the 34.1 in dimension before you lay out the electrical room.
8) Is the bus aluminum or copper on the Eaton CH 225A interlock?
Aluminum bus. That matters on termination: aluminum needs correctly rated connectors and lugs, proper torque to the marked value, and a re-torque check after the first heat cycles. If your specification calls for copper bus throughout, this assembly will not meet it.
