Crouse-Hinds Conduit Bushed Ni...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$6.32
Eaton Crouse-Hinds Conduit Bushed (Chase) Nipple - Rigid/IMC, Non-Insulated

Crouse-Hinds Conduit Bushed Nipple - Rigid/IMC, Malleable Iron, Non-Insulated

(No reviews yet) Write a Review

Model: 55

In Stock (leaves warehouse same day if ordered before 3pm ET)

$6.32
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Crouse-Hinds Conduit Bushed Nipple - Rigid/IMC, Malleable Iron, Non-Insulated

Professional conduit connection solution for reliable electrical installations

The Crouse-Hinds Conduit Bushed Nipple delivers dependable performance for Rigid/IMC conduit systems in ordinary locations. Constructed from durable malleable iron with non-insulated design, this chase nipple provides secure conduit connections while meeting NEC/CEC standards for professional electrical installations.

Professional Features & Benefits

  • Rigid/IMC Compatibility: Designed specifically for rigid and intermediate metallic conduit systems, ensuring proper fit and secure connections in professional installations.
  • Malleable Iron Construction: Robust malleable iron material provides exceptional durability and corrosion resistance for long-term reliability in electrical systems.
  • Non-Insulated Design: Standard non-insulated configuration allows for proper grounding continuity and electrical bonding in conduit runs.
  • NEC/CEC Compliance: Meets National Electrical Code and Canadian Electrical Code standards for safe and code-compliant installations.
  • Ordinary Location Rating: Suitable for standard non-hazardous environments, providing versatile application in commercial and industrial settings.
  • Bushed Configuration: Chase nipple design facilitates smooth wire pulling and protects conductor insulation during installation.

Technical Specifications

  • Area Classification: Ordinary/Non-Hazardous Locations
  • Conduit Type: Rigid/IMC
  • Insulator: Non-insulated
  • Product Material: Malleable iron
  • Standards Type: NEC/CEC

Professional Applications

  • Commercial Building Electrical Systems
  • Industrial Facility Conduit Runs
  • Institutional Electrical Installations
  • Multi-Unit Residential Properties
  • Professional Office Buildings
  • Retail and Service Establishments
  • Educational Facility Electrical Systems

Why Choose Crouse-Hinds Quality?

Crouse-Hinds delivers proven reliability through malleable iron construction and NEC/CEC compliance, ensuring professional-grade performance in ordinary location electrical installations. The non-insulated design provides proper grounding continuity while the bushed configuration protects conductors during installation and service.

Manufacturer Resources

Product Specs

Area Classification:
Ordinary/Non-Hazardous Locations
Conduit Type:
Rigid/IMC
Insulator:
Non-insulated
Product Material:
Malleable iron
Standards Type:
NEC/CEC
Department:
Electrical
Product Type:
Conduit Nipple
Product Subgroup:
Conduit Fittings
Product Group:
Conduit & Raceway

Crouse-Hinds 55 – Frequently Asked Questions

1) Can I use a Crouse-Hinds chase nipple in a Class I Division 2 area or a paint booth?
No. This chase nipple is rated for ordinary, non-hazardous locations only. Anything in a classified area needs fittings listed for that class and division, typically an explosionproof union or sealing fitting, not an ordinary-location bushed nipple.
2) Chase nipple or a nipple with a locknut and bushing, which do I use to join two boxes back to back?
For two enclosures mounted tight against each other, the chase nipple is the right piece: it threads through the two aligned knockouts and pulls them together with a single locknut, with the bushed end facing the wire so conductors do not drag on a raw thread. If the boxes are apart, or you need a length of raw conduit between them, use a threaded close nipple or a chase nipple plus locknuts and a separate insulated bushing on each side. Where the conductors are 4 AWG or larger, code wants an insulated throat, and this one is non-insulated, so an insulated bushing or an insulated-throat fitting is what that job calls for.
3) Which way does the bushed end of the chase nipple face when I install it?
The bushed, tapered end goes toward the conductors, inside the enclosure the wire is pulled into, so the smooth shoulder takes the strain instead of a cut thread. The threaded shank passes through the knockout and the locknut lands on the far side. Installed backwards, the wire rides on the thread and the insulation is the thing that pays for it.
4) Does a chase nipple come with the locknut, or do I order that separately?
Order the locknut separately. A chase nipple is the threaded body with the bushed shoulder; the retaining locknut on the far side of the knockout is a separate item, sized to the same trade size as the nipple. Budget one locknut per nipple, and add an insulated bushing if the conductors call for an insulated throat, since this nipple is non-insulated.
5) Is a malleable iron bushed nipple OK for a damp outdoor location or a wash-down area?
Malleable iron holds up well in commercial and industrial conduit runs, and it is what gives this nipple its strength across the threads. It is an ordinary-location fitting, though, not a hazardous-location one, and nothing in the record makes it a raintight or wet-location connection on its own. For a wet or corrosive environment, spec the fitting family listed for it.
6) Do Crouse-Hinds catalog numbers 50, 52, 54, 55 and 56 all refer to the same bushed nipple?
Same fitting, one number per trade size. 50 is the 1/2 inch, 52 the 1 inch, 54 the 1-1/2 inch, 55 the 2 inch and 56 the 2-1/2 inch. All five are the Rigid/IMC, malleable iron, non-insulated chase nipple, so when you standardize a facility you are ordering one part family and only changing the size digit.
