Eaton Crouse-Hinds Conduit Bushed (Chase) Nipple - Rigid/IMC, Non-Insulated, Zinc Die Cast

Crouse-Hinds Conduit Bushed Chase Nipple - Rigid/IMC, Non-Insulated, Zinc Die Cast

(No reviews yet) Write a Review

Model: 59D

In Stock (leaves warehouse same day if ordered before 3pm ET)

$34.47
$27.88
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Crouse-Hinds Conduit Bushed Chase Nipple - Rigid/IMC, Non-Insulated, Zinc Die Cast

Professional conduit connection solution for reliable electrical installations

The Crouse-Hinds Conduit Bushed Chase Nipple delivers dependable conduit connections for Rigid/IMC applications. Constructed from durable zinc die cast material with non-insulated design, this professional-grade nipple ensures secure conduit transitions while meeting NEC/CEC standards for ordinary and non-hazardous locations.

Professional Features & Benefits

  • Rigid/IMC Compatibility: Designed specifically for rigid and intermediate metallic conduit systems, ensuring proper fit and secure connections in professional installations.
  • Zinc Die Cast Construction: Robust material provides excellent corrosion resistance and mechanical strength for long-lasting performance in demanding environments.
  • Non-Insulated Design: Allows for direct electrical continuity and grounding through the fitting, maintaining system integrity and safety requirements.
  • NEC/CEC Compliance: Meets National Electrical Code and Canadian Electrical Code standards, ensuring code-compliant installations and inspector approval.
  • Ordinary Location Rating: Suitable for standard non-hazardous environments, providing versatile application across residential, commercial, and industrial projects.
  • Bushed Configuration: Smooth internal surfaces protect conductor insulation during wire pulling, reducing installation time and preventing damage.

Technical Specifications

  • Area Classification: Ordinary/Non-Hazardous Locations
  • Conduit Type: Rigid/IMC
  • Insulator: Non-insulated
  • Product Material: Zinc die cast
  • Standards Type: NEC/CEC

Professional Applications

  • Commercial Building Electrical Systems
  • Industrial Facility Conduit Runs
  • Residential Service Installations
  • Institutional Electrical Projects
  • Retail and Office Buildings
  • Educational Facility Wiring
  • Healthcare Facility Electrical Systems

Why Choose Crouse-Hinds Quality?

Crouse-Hinds delivers proven reliability through NEC/CEC compliant design and durable zinc die cast construction. The non-insulated configuration ensures proper electrical continuity while the bushed design protects conductors during installation, providing professional contractors with dependable performance for ordinary location applications.

Manufacturer Resources

Product Specs

Area Classification:
Ordinary/Non-Hazardous Locations
Conduit Type:
Rigid/IMC
Insulator:
Non-insulated
Product Material:
Zinc die cast
Standards Type:
NEC/CEC
Department:
Electrical
Product Type:
Conduit Fittings
Product Subgroup:
Electrical

Crouse-Hinds 59D – Frequently Asked Questions

1) What is a bushed chase nipple used for in a conduit run?
A chase nipple joins two enclosures or connects a conduit system through a wall of a box, threading into a knockout or hub with a locknut on the far side. The Crouse-Hinds bushed version adds a smooth bushed throat inside the nipple so conductors are not dragged across a sharp thread edge during the pull. It is built for Rigid and IMC systems and is a non-insulated fitting, so metal-to-metal contact is maintained through the fitting for continuity and grounding.
2) What trade sizes does the Crouse-Hinds bushed chase nipple come in?
Ten trade sizes, 1/2 inch through 4 inch: 1/2 (50D), 3/4 (51D), 1 (52D), 1-1/4 (53D), 1-1/2 (54D), 2 (55D), 2-1/2 (56D), 3 (57D), 3-1/2 (58D) and 4 inch (59D). Order by the trade size of the conduit or knockout you are landing in, not by the outside diameter of the fitting.
3) Can I use a zinc die cast chase nipple in a hazardous or classified location?
No. The Crouse-Hinds zinc die cast bushed chase nipple is rated for ordinary, non-hazardous locations only. Class I, II or III areas call for fittings specifically listed for that classification, so for a classified area you need explosionproof-rated conduit fittings instead of this one.
4) Will a chase nipple work with EMT?
No. This bushed chase nipple is threaded for Rigid and IMC, which share the same NPT thread series. EMT is unthreaded and needs a set screw or compression connector instead. If you are transitioning EMT into a box or another raceway, use an EMT connector, not a chase nipple.
5) Should I use a bushed chase nipple or an insulated throat bushing?
They do different jobs. A bushing threads onto the end of a conduit inside a box to protect conductors; a chase nipple connects two enclosures or lands in a knockout, and the bushed style already has the smooth throat built in, so you do not stack a separate bushing on it. This Crouse-Hinds nipple is the non-insulated type, meaning no plastic insert, which keeps a metal path through the fitting for bonding. Where the NEC calls for an insulated throat on larger conductors, an insulated-throat fitting is the one to specify.
6) Does a chase nipple maintain ground continuity between two boxes?
Yes. The non-insulated zinc die cast body carries metal-to-metal contact from the fitting through the enclosure wall, so the fitting itself is part of the bonding path when it is made up tight with a locknut. The fitting is built to NEC and CEC standards. On a run where the fitting alone is not permitted to serve as the equipment ground, you still pull a bonding jumper as the code requires.
7) Do I need to buy locknuts separately for a Crouse-Hinds chase nipple?
Plan on it. A chase nipple is the threaded nipple only. Landing it in a box knockout takes a locknut on the opposite side of the enclosure wall, sized to the same trade size as the nipple. Two-enclosure make-ups between hubs may not need one, but a knockout installation does.
8) Is zinc die cast good enough for an outdoor or damp electrical installation?
Zinc die cast gives corrosion resistance and mechanical strength for ordinary locations, which covers most commercial, industrial and residential work. It is not a wet-location or raintight seal on its own: a chase nipple is a dry connection between enclosures, so if the joint has to keep water out you need a gasketed or raintight fitting and a sealing washer at the knockout.
9) Can I standardize one part number across a whole facility's conduit terminations?
For Rigid and IMC ordinary-location work, yes. The same Crouse-Hinds bushed chase nipple runs 1/2 inch through 4 inch under one series (50D through 59D), so a maintenance stock only has to carry the sizes on hand, not a different brand or style per size. It does not cover EMT, flex, or classified areas, which need their own fittings.
