Eaton E30 Series Square Multifunction Pushbutton Legend Plate, Red Actuator, Watertight/Oiltight

The Eaton E30 series square multifunction pushbutton legend plate is a 30.5 mm watertight/oiltight component designed for use with Eaton's square multifunction pushbutton operators. Featuring a red actuator and an "OFF" legend in 3/16 inch high letter size, this button insert is built for panel builders and maintenance electricians who need clearly marked, durable control station components. The watertight/oiltight construction makes it suitable for demanding industrial environments where moisture and oil exposure are a concern.

Key Features

  • Trade Size: 30.5 mm square multifunction format for use with Eaton E30 pushbutton operators.
  • Watertight/Oiltight Design: Rated watertight and oiltight for reliable performance in washdown and industrial oil-exposure environments.
  • Legend: Marked "OFF" in 3/16 inch high letter size for clear operator identification at the control station.
  • Actuator Color: Red actuator for high-visibility identification on the panel face.
  • Compatible Use: Designed for use with pushbutton, square multifunction control station operators in the Eaton E30 series.
  • Product Height: .3 in, a low-profile fit within the pushbutton assembly.
  • Warranty: Backed by a 1 year manufacturer warranty.

Technical Specifications

  • Legend: OFF
  • Actuator color: Red
  • Warranty: 1 year
  • Series: E30

Typical Applications

  • Industrial Control Panels and Operator Stations
  • Machine Control and OFF/Stop Function Marking
  • Washdown and Wet-Location Industrial Environments
  • Oil-Exposed Manufacturing and Processing Equipment
  • Panel Builder and Maintenance Retrofit Projects

Why Eaton?

Eaton's E30 series pushbutton components are engineered for watertight and oiltight performance, giving panel builders and maintenance teams a dependable, clearly legended control element for demanding industrial applications. With a 1 year manufacturer warranty and a design built for compatibility with Eaton's square multifunction pushbutton platform, this legend plate delivers the reliable, code-compliant performance professionals expect from Eaton electrical control products.

Manufacturer Resources

Product Specs

Used With:
Pushbutton, square multifunction
Legend:
OFF
Special Features:
Used with Pushbutton, square multifunction
Product Height:
.3 in
Product Type:
Legend Plate
Actuator Color:
Red
Warranty:
1 year
Product Category:
Button
Series:
E30
Department:
Electrical
Product Color:
Red
Configuration:
Square Multifunction Watertight/Oiltight
Product Group:
Motor Control & Automation
Product Subgroup:
Push Buttons & Pilot Devices

Eaton E30KB218 – Frequently Asked Questions

1) Is the Eaton E30 red OFF button a complete pushbutton, or just the legend plate and button insert?
It is the button/legend plate component only, not a complete operator. The E30 red OFF button insert is made to go into an Eaton E30 series square multifunction pushbutton operator, so you still need the operator body and the contact blocks to build a working control station.
2) What does the Type A, B, C or E actuator style mean when ordering the E30 OFF button?
Those are the four actuator styles offered, all in the extended button profile: Type A Extended (E30KA218), Type B Extended (E30KB218), Type C Extended (E30KC218) and Type E Extended (E30KE218). The legend, OFF, and the red color are the same across all four, so the actuator style is the only thing you are choosing. Match it to the operator style already in the panel or on the drawing.
3) I am replacing a faded OFF button on an existing Eaton E30 station. Do I have to change the whole operator?
Not if the operator is sound. Since this is the button and legend element for the square multifunction E30 platform, you can swap just the insert and leave the operator and contact blocks in place. Note the actuator style already installed, Type A, B, C or E, and order the matching extended version.
4) Can I use this red OFF button on a washdown machine or where there is oil spray?
That is what it is built for. The configuration is watertight/oiltight, so it suits washdown areas and oil-exposed processing equipment, provided the E30 operator it mounts into and the enclosure are also the watertight/oiltight type.
5) Is a red OFF button the same thing as an emergency stop?
No. This is a standard red OFF pushbutton insert for normal machine stop or off marking on an E30 control station. An E-stop is a separate device, typically a maintained mushroom or palm operator with a twist or pull release, and that function is not what this button provides.
6) Is the OFF legend printed on the button itself, and how big is the lettering?
The marking reads OFF in 3/16 inch high letters on the red button face, so an operator can identify the stop function at the control station without a separate nameplate below it.
