Eaton Freedom A200 Non-Reversing Motor Starter, Three-Pole, 200-208V/60Hz Coil

Eaton Freedom A200 Non-Reversing Motor Starter, Three-Pole, 200-208V/60Hz Coil

(No reviews yet) Write a Review

Model: A200MACB

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,262.23
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton Freedom A200 Non-Reversing Motor Starter, Three-Pole, 200-208V/60Hz Coil

The Eaton Freedom A200 Non-Reversing Motor Starter is a three-pole, three-phase magnetic starter built for reliable motor control in commercial and industrial systems. Rated 9A with a 200-208 Vac, 60 Hz coil, this Size 0 starter is UL Listed and engineered to deliver dependable motor switching and overload protection in demanding electrical applications.

Key Features

  • Three-Pole Configuration: Three-phase magnetic design supports balanced motor control across all three phases.
  • Non-Reversing Starter: Delivers straightforward motor starting control for applications that do not require direction reversal.
  • Amperage Rating: Rated 9A for reliable, code-compliant motor switching performance.
  • Coil Voltage: 200-208 Vac, 60 Hz coil for compatibility with standard control circuits.
  • A200 Series, Size 0: Part of Eaton's proven A200 series motor control line, sized for smaller motor loads.
  • HP Rating: Rated 1/3 hp at 115V, 1-1/2 hp at 208,240V, and 2 hp at 480,600V, giving flexibility across common motor voltages.
  • Compact Footprint: Measures 4.38 in wide, 4.61 in deep, and 3.31 in high for straightforward panel integration.
  • UL Listed: Independently certified for safety and code-compliant installation.

Certifications & Compliance

  • UL Listed

Technical Specifications

  • Number Of Poles: Three-pole
  • Amperage Rating: 9A
  • Coil Voltage: 200-208 Vac, 60 Hz
  • Series: A200
  • Size: 0
  • Product Width: 4.38 in
  • Product Length/Depth: 4.61 in
  • Product Height: 3.31 in
  • Phase: Three-phase magnetic
  • HP Rating - Max: 1/3 hp at 115V, 1-1/2 hp at 208,240V, 2 hp at 480,600V
  • Certifications: UL Listed

Typical Applications

  • Commercial and Industrial Motor Control Panels
  • Motor Control Centers and Starter Enclosures
  • Pump, Fan, and Conveyor Motor Circuits
  • Panelboard and Load Center Wiring
  • New Construction and Motor Control Retrofits

Why Eaton?

Eaton's A200 series motor starters are built for dependable, code-compliant performance in professional electrical work, backed by UL Listing and Eaton's established motor control engineering. The Freedom A200 Non-Reversing Starter's three-pole, three-phase magnetic design and defined HP ratings make it a trusted choice for controlling motor loads in industrial and commercial installations.

Manufacturer Resources

Product Specs

Number Of Poles:
Three-pole
Product Width:
4.38 in
Amperage Rating:
9A
Coil voltage:
200-208 Vac, 60 Hz
Series:
A200
Product Size:
0
Product Length/Depth:
4.61 in
Product Height:
3.31 in
Phase:
Three-phase magnetic
HP rating - max:
1/3 hp at 115V, 1-1/2 hp at 208,240V, 2 hp at 480,600V
Certifications:
UL Listed
Product Type:
Motor Starter
Department:
Electrical
Voltage Rating:
200-208V
Listing:
UL Listed
Product Group:
Starters & Contactors
