Eaton Freedom Series Overload Relay Heater Pack, Fast Trip Class 10

Eaton Freedom Series Overload Relay Heater Pack, Fast Trip Class 10

(No reviews yet) Write a Review

Model: H2101B-3

In Stock (leaves warehouse same day if ordered before 3pm ET)

$94.33
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton Freedom Series Overload Relay Heater Pack, Fast Trip Class 10

Eaton's Freedom Series Overload Relay Heater Pack delivers Fast Trip, Class 10 protection for motor control applications, engineered to NEMA and IEC design standards. This heater pack pairs with overload relays rated 32 or 75A and provides multiple dial-position current settings, giving electrical professionals precise thermal protection tuning matched to the connected motor load. Compatible with a broad range of starter frame sizes, it is a direct fit for maintenance, retrofit, and OEM panel-building projects that require dependable overload protection. Designed for professional electricians, panel builders, and maintenance teams, this heater pack simplifies overload relay calibration by providing multiple dial-position current settings on a single part, reducing the need to stock separate heater elements for each motor full-load amperage.

Key Features

  • Trip Type: Fast Trip, Class 10 design for quick-response overload protection of connected motor loads.
  • Design Standard: Built to NEMA and IEC design specifications for compatibility across both North American and international starter platforms.
  • Adjustable Tuning: Multiple dial-position current settings corresponding to dial positions A, B, and C, for adjustable thermal protection matched to the connected motor load.
  • Overload Relay Rating: Rated for use with 32A or 75A overload relays.
  • Starter Compatibility: Used with starter sizes 00-0 (Series C) and Sizes 1-2 (Series B) NEMA frames, plus IEC Sizes A-F (Series C) and IEC Sizes G-K (Series B).
  • Packaging: Heater packs are shipped 3 to a carton; catalog numbers and pricing are for the 3-pack quantity.

Technical Specifications

  • Warranty: Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
  • Product Type: Coil
  • Department: Electrical

Typical Applications

  • Motor Control Centers and Starter Panels
  • Industrial and Commercial Motor Protection
  • OEM Panel Building and Retrofit Projects
  • Overload Relay Maintenance and Replacement
  • NEMA and IEC Starter Applications

Why Eaton?

Eaton's Freedom Series heater packs are engineered for reliable, code-compliant thermal overload protection backed by Eaton's manufacturer warranty. Built to Fast Trip, Class 10 performance with NEMA and IEC design compatibility, they give electrical professionals a dependable, precisely calibrated solution for motor starter protection across NEMA and IEC platforms.

Variant Specifications

Motor FLASKUMPN
H2101B3/H2109B3/H2110B3 FLA rangeH2101B-3H2101B3
H2104B3/H2114B3/H2106B3 FLA rangeH2104B-3H2104B3

Manufacturer Resources

Product Specs

Department:
Electrical
Trip Type:
Fast Trip, Class 10
Overload relay:
32 or 75A
Product Design:
NEMA, IEC
Standards:
NEMA/IEC
Product Group:
Relays
Product Type:
Overload Relay

Eaton H2101B-3 – Frequently Asked Questions

1) Will an Eaton Freedom heater pack work with my 32A overload relay?
Yes. The Freedom Series heater packs are rated for use with overload relays rated 32A or 75A, so a 32A relay is a direct match. Anything outside those two relay ratings is not what these packs are built for.
2) What NEMA and IEC starter sizes do Eaton Freedom Series heater packs fit?
They cover NEMA starter sizes 00-0 (Series C) and Sizes 1-2 (Series B), plus IEC Sizes A-F (Series C) and IEC Sizes G-K (Series B). If your starter is outside that range, or a different series letter than the one listed for your size, this is not the heater pack for it.
3) How many heaters come in an Eaton Freedom H2101B-3 heater pack?
Three. Freedom Series heater packs ship 3 to a carton, and the catalog number and quantity are for the 3-pack. That is one pack per phase on a three-phase starter, so a single order covers one overload relay.
4) Is a Class 10 fast trip heater right for my motor, or do I need a slower trip class?
Class 10 means the overload trips within 10 seconds at locked-rotor current, which is the fast end of the scale. The Eaton Freedom heater packs are Fast Trip, Class 10 only. That suits motors that come up to speed quickly and loads you want off line fast. High-inertia loads with long accelerating times, big fans, centrifuges, some compressors, will nuisance trip on Class 10 and want a Class 20 or 30 arrangement instead.
5) Do I have to order a different heater for every motor full-load amp rating?
No, and that is the point of the pack. Each Freedom heater pack carries multiple dial-position current settings, at dial positions A, B, and C, so one part covers a band of motor FLA rather than a single value. You set the dial to the position matching the connected motor load. For a maintenance shop that means far fewer part numbers on the shelf.
6) What is the difference between the Eaton H2101B-3 and H2104B-3 heater packs?
Motor full-load amp coverage, nothing else. H2101B-3 covers the H2101B3/H2109B3/H2110B3 FLA range and H2104B-3 covers the H2104B3/H2114B3/H2106B3 FLA range. Both are Fast Trip Class 10 and both suit 32A or 75A overload relays. Pick by the nameplate FLA of the motor you are protecting.
7) Can I use the same Eaton heater pack on an IEC starter and a NEMA starter?
Yes. Freedom Series heater packs are built to both NEMA and IEC design standards, so a panel shop running mixed North American and international starter platforms can stock one part family instead of two. Match the size and series letter of the starter, not the standard.
8) Does an overload heater pack protect against short circuits too?
No. A heater pack is the thermal element of an overload relay, sized to the motor running current, and it protects against sustained overload and single-phasing. Short-circuit and ground-fault protection is a separate device ahead of the starter, a breaker or fuses. You need both in the panel.
