Eaton 200A Single-Position Meter Socket, Ringless, Three-Phase

Eaton 200A Single-Position Meter Socket, Ringless, Three-Phase

(No reviews yet) Write a Review

Model: H7210UCH

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,001.88
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton 200A Single-Position Meter Socket, Ringless, Three-Phase

The Eaton 200A Single-Position Meter Socket is a commercial-service metering enclosure engineered for three-phase, four-wire installations up to 600V. Featuring a ringless, seven-jaw design with a top/bottom feed configuration and a 5 x 5 inch hub cover plate, this meter socket is built for single-position commercial service applications where secure, code-compliant metering is required. UL Listed for dependable performance, it is a solid choice for commercial and multi-family electrical service entrances.

Key Features

  • Amperage Rating: 200A rating supports commercial service entrance loads.
  • Voltage Rating: 600V rating for three-phase commercial applications.
  • Ringless Design: Ringless security construction for a tamper-resistant metering installation.
  • Seven-Jaw Configuration: Seven-jaw design provides secure, reliable meter contact.
  • Top/Bottom Feed: Top/bottom (over/under) feed type allows flexible conduit entry.
  • Four-Wire: Four-wire configuration suited to three-phase service.
  • 5 x 5 Hub Cover Plate: Includes a 5 x 5 inch hub cover plate for conduit hub connections.
  • Single-Position Commercial Service: Single-position design for one meter per enclosure in commercial service.

Certifications & Compliance

  • UL Listed

Technical Specifications

  • Voltage Rating: 600V
  • Number of sockets: 1
  • Department: Electrical

Typical Applications

  • Commercial Electric Service Metering
  • Multi-Family and Commercial Buildings
  • Utility Meter Installations
  • New Construction and Service Upgrades
  • Three-Phase Electrical Service Entrances

Why Eaton?

Eaton builds its 200A meter sockets with a ringless, seven-jaw design and UL Listed construction to deliver secure, code-compliant metering for demanding commercial service applications. The three-phase, four-wire configuration and top/bottom feed flexibility make this meter socket a reliable choice for licensed electricians handling commercial and multi-family service installations. Choose Eaton for dependable metering equipment backed by proven electrical manufacturing standards.

Manufacturer Resources

Product Specs

Product Width:
13 in
Load:
3/8 in stud
Hub type:
5 x 5 hub cover plate
Voltage Rating:
600V
Amperage Rating:
200A
Product Length/Depth:
4.93 in
Number of sockets:
1
Product Height:
24.68 in
Product Type:
Meter Socket
Phase:
Three-phase
Number of jaws:
Seven-jaw
Security:
Ringless
Feed type:
Top/bottom
Line:
3/8 in stud
Number of wires:
Four-wire
Certifications:
UL Listed
Department:
Electrical
Configuration:
Single-Position
Listing:
UL Listed
Product Group:
Power Distribution
Product Subgroup:
Metering & Meter Sockets

Eaton H7210UCH – Frequently Asked Questions

1) Will a seven-jaw meter socket work for my three-phase 120/208V service?
Seven jaws is the standard configuration for three-phase, four-wire metering, and that is exactly what the Eaton H7210UCH is built for: three-phase, four-wire, rated 600V and 200A. If your utility meter is a self-contained three-phase four-wire form (the usual 120/208V or 277/480V wye service), this is the socket type they expect. A single-phase service uses a four-jaw socket instead, so do not order this one for a residential 120/240V drop.
2) My utility requires a ringless meter socket. Is the Eaton H7210UCH ringless or ring-type?
Ringless. The H7210UCH uses ringless security construction, meaning the cover is retained by the sealing mechanism rather than a sealing ring around the meter. Utilities are specific about this and will reject the wrong style at inspection, so match it to what your serving utility's meter spec calls out before the service entrance goes in.
3) Can I bring conduit in from the top or does it have to come up from below?
Either. The H7210UCH is a top/bottom (over/under) feed socket, so you can land the service conduit overhead or underground and run the load out the opposite end. It ships with a 5 x 5 inch hub cover plate for the hub opening, so you pick and install the hub that matches your conduit size.
4) What are the line and load terminations on the Eaton H7210UCH meter socket?
Both line and load sides terminate on 3/8 inch studs. That means you are landing lugs or compression terminals drilled for a 3/8 inch bolt rather than pushing conductors into set-screw lugs, so order your terminal lugs sized for the 200A conductors and drilled to match.
5) Can I meter two tenants from this Eaton socket?
No. It is a single-position socket with one meter socket per enclosure. For a multi-tenant building where each unit needs its own meter, you need a multi-position metering stack or gang, not this enclosure.
6) Can an ABB MeterMod III 800A ringless socket be used in place of the Eaton H7210UCH?
No, they serve different services. The Eaton H7210UCH is a 200A single-position, seven-jaw, four-wire three-phase socket rated 600V, so it is matched to a three-phase, four-wire commercial service entrance. The ABB MeterMod III is an 800A single-phase ringless meter socket, which is a single-phase service at a much higher amperage. Both use ringless security construction, so a utility that requires ringless covers accepts either style, but the jaw count, phase, and amperage have to match the service and the utility's metering requirement before either one goes on the wall.
7) What size wall space do I need for this 200A commercial meter socket?
Plan on an enclosure footprint of 24.68 inches by 13 inches, with a depth of 4.93 inches off the mounting surface. On a service upgrade that depth matters most: check clearance to any adjacent gas meter, downspout, or corner before you set the backboard.
8) Is this meter socket UL Listed for a commercial service entrance?
Yes, the Eaton H7210UCH carries a UL Listing. For an inspector on a commercial or multi-family service, that plus the 600V and 200A ratings is what gets checked against the drawing.
9) Does picking a ringless socket from a different manufacturer change the conduit entry or hub work?
The security style and the conduit provisions are separate decisions. The Eaton H7210UCH is a top/bottom feed enclosure supplied with a 5 x 5 inch hub cover plate, with 3/8 inch studs on both line and load, and it measures 24.68 inches high by 13 inches wide by 4.93 inches deep. The ABB MeterMod III is also a ringless socket but is an 800A single-phase unit, so its enclosure and terminal arrangement are sized for that service. Confirm feed direction, hub opening, and enclosure footprint against the meter location before committing to either, since ringless alone does not make two sockets interchangeable.
