Eaton NEMA Size 0 Reversing Motor Starter

Eaton NEMA Size 0 Reversing Motor Starter

(No reviews yet) Write a Review

Model: MST02

In Stock (leaves warehouse same day if ordered before 3pm ET)

$170.29
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton NEMA Size 0 Reversing Motor Starter, 208V Coil

The Eaton NEMA Size 0 Reversing Motor Starter (MST0 Series) delivers dependable motor control for industrial and commercial applications requiring forward/reverse operation. Built with a 208V coil and rated for a 0.35-1.65 A overload range, this Space SVG reversing starter includes 1NO auxiliary contacts for interlocking and control-circuit signaling. Designed to NEMA Size 0 dimensions, it supports motor loads up to 1 hp at 120/240 Vac/dc and 0.25 hp at 32 Vdc, making it a compact, code-ready choice for motor control panels.

Key Features

  • NEMA Size 0 Frame: Compact Space SVG construction with a product width of 1.77 in, length/depth of 5.5 in, and height of 6.3 in for space-constrained panel layouts.
  • Reversing Configuration: Enables forward and reverse motor control from a single integrated starter assembly.
  • Auxiliary Contact: Equipped with 1NO auxiliary contact for control-circuit interlocking and status signaling.
  • 208V Coil: Matched to 208V control circuits for reliable, consistent contactor operation.
  • Overload Range: 0.35-1.65 A adjustable overload setting for precise motor protection.
  • Voltage Rating: Rated 120/240 Vac/dc at 1 hp and 32 Vdc at 0.25 hp for versatile motor applications.
  • Horsepower Range: Supports 0.25 hp and 1 hp motor loads within a single NEMA Size 0 platform.

Technical Specifications

  • Product Type: Motor Starter
  • Size: NEMA Size 0
  • Voltage Rating: 120/240 Vac/dc at 1 hp, 32 Vdc at 0.25 hp
  • Horsepower: 0.25 hp, 1 hp
  • Product Width: 1.77 in
  • Product Length/Depth: 5.5 in
  • Product Height: 6.3 in
  • Warranty: 1 year
  • Catalog Notes: Does not include heater.

Typical Applications

  • Industrial Motor Control Panels
  • Forward/Reverse Motor Control Circuits
  • Commercial HVAC and Pump Motor Control
  • OEM Machine Control Systems
  • Renovation and New Construction Electrical Panels

Why Eaton?

Eaton's NEMA Size 0 reversing starters combine a compact Space SVG footprint with dependable 208V coil operation and a precise 0.35-1.65 A overload range, giving electrical professionals a reliable, code-ready building block for motor control panels. Backed by a 1-year warranty, this MST0 Series starter is engineered for consistent performance in forward/reverse motor control applications. Note that the heater is not included and must be ordered separately to complete overload protection.

Manufacturer Resources

Product Specs

Product Width:
1.77 in
Voltage Rating:
208V
Product Size:
NEMA size 0
Product Length/Depth:
5.5 in
Product Height:
6.3 in
Warranty:
1 year
Catalog Notes:
Does not include heater.
Horsepower:
0.25 hp, 1 hp
Product Type:
Motor Starter
Department:
Electrical
Amperage Rating:
0.35-1.65A
Series:
MST0
Configuration:
Reversing
Product Group:
Starters & Contactors

Eaton MST02 – Frequently Asked Questions

1) Does the Eaton MST0 reversing starter come with overload heaters?
No. The MST0 Series NEMA Size 0 reversing starter ships without heaters, and they have to be ordered separately to complete the overload protection. The overload block itself covers a 0.35 to 1.65 A range, so size the heater to your motor's full load amps inside that window before the panel goes together.
2) What coil voltages can I get on the Eaton MST0 reversing starter?
Two coil choices: 120V (MST01SN1P) and 208V (MST02). Pick the one that matches your control circuit voltage, not the motor supply voltage, since the coil is what the pilot devices and interlocks switch.
3) Will an Eaton NEMA Size 0 reversing starter fit my motor's amp draw?
It works for small motors only. The overload range is 0.35 to 1.65 A, and the starter is rated 1 hp at 120/240 Vac/dc and 0.25 hp at 32 Vdc. If your motor's full load current sits above 1.65 A, this Size 0 unit is the wrong frame and you need a larger NEMA size.
4) How much panel space does the Eaton MST0 Size 0 reversing starter take up?
Plan on 1.77 in wide, 5.5 in deep and 6.3 in high. The narrow width is what makes it workable when you are fitting a forward/reverse assembly into an existing control panel with limited backplate real estate, but check the 6.3 in height against your wireway clearance.
5) Do I need two contactors to run a motor forward and reverse, or does this one unit do it?
One unit does it. The MST0 is a reversing starter, meaning both directions are handled by a single integrated assembly rather than two separate contactors you wire and interlock yourself. If your application only ever runs one direction, a non-reversing Size 0 starter is the simpler and smaller choice.
6) Does the Eaton MST0 reversing starter have an auxiliary contact for control wiring?
It carries one normally open auxiliary contact. That is what you use for electrical interlocking between directions or to feed a run light or PLC input. If your sequence needs a normally closed contact or more than one aux, plan on an add-on auxiliary block.
7) Is the Eaton MST0 starter suitable for HVAC and pump motor control?
Yes, within its size. Typical uses are commercial HVAC and pump motor control, OEM machine control, and forward/reverse circuits in industrial panels. The limit is motor size: 1 hp at 120/240 Vac/dc. Small damper, pump, and conveyor drives fit; anything larger needs a bigger NEMA frame.
