Eaton Freedom Size 2 NEMA Reversing Motor Starter, Open Type

Eaton Freedom Size 2 NEMA Reversing Motor Starter, Open Type

(No reviews yet) Write a Review

Model: AN59GN0A5E045

In Stock (leaves warehouse same day if ordered before 3pm ET)

$4,590.49
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton Freedom Size 2 NEMA Reversing Motor Starter, Open Type

The Eaton Freedom Size 2 NEMA Reversing Motor Starter is a Freedom Series combination starter built for industrial and commercial motor control applications requiring bidirectional (forward/reverse) motor operation. Rated at 45A with an Open type construction, this Size 2 NEMA starter integrates a C440 electronic overload relay (EOLR) with standard feature set, SEL reset, and SEL class settings (10a, 10, 20, 30) for precise, adjustable motor protection. Backed by UL Listing and RoHS Compliance, it delivers dependable, code-compliant performance for horizontally mounted panel and enclosure installations.

Key Features

  • NEMA Size: Size 2 rating suited for medium horsepower motor control applications.
  • Amperage Rating: 45A rated for reliable, continuous motor circuit switching.
  • Reversing Configuration: NEMA reversing Freedom Series starter design enables forward and reverse motor control from a single assembly.
  • C440 Overload Protection: Equipped with C440 EOLR standard feature set, SEL reset, and SEL class (10a, 10, 20, 30) for adjustable, precise motor overload protection.
  • Open Type Construction: Open type enclosure design for panel-mounted and OEM control applications.
  • Mounting: Horizontal mounting configuration for standard panel installation.
  • Compact Footprint: Measures 6.7 in wide by 4.98 in deep by 7.1 in high, sized for efficient panel space utilization.
  • RoHS Compliant: Manufactured to RoHS compliance standards for restricted hazardous substances.

Certifications & Compliance

  • UL Listed
  • RoHS Compliant

Technical Specifications

  • Warranty: 1 year
  • Amperage Rating: 45A
  • Size: 2
  • Product Type: Motor Starter
  • Certifications: UL
  • Type: Open
  • Mounting: Horizontal
  • Product Width: 6.7 in
  • Product Length/Depth: 4.98 in
  • Product Height: 7.1 in

Typical Applications

  • Industrial Motor Control Panels
  • Reversing Motor Circuits for Pumps, Fans, and Conveyors
  • OEM Control Panel Building
  • Commercial and Industrial Electrical Installations
  • Motor Overload Protection and Fault Monitoring

Why Eaton?

Eaton's Freedom Series combination starters pair rugged Open type construction with the precision of the C440 electronic overload relay, giving electrical professionals adjustable, reliable motor protection in a compact, UL Listed package. RoHS compliance and consistent NEMA-rated performance make this Size 2 reversing starter a dependable choice for demanding industrial and commercial motor control installations.

Manufacturer Resources

Product Specs

Product Width:
6.7 in
Warranty:
1 year
Amperage Rating:
45A
Mounting Method:
Horizontal
Product Size:
2
Product Length/Depth:
4.98 in
Compliances:
RoHS Compliant
Product Height:
7.1 in
Product Type:
Motor Starter
Certifications:
UL
Department:
Electrical
Listing:
UL Listed
Standards:
RoHS Compliant
Series:
Freedom Series
Configuration:
Reversing
Product Group:
Motor Control & Automation
Product Subgroup:
Motor Starters & Contactors
Product Length:
4.98 in
Product Weight:
8.2 lb

Eaton AN59GN0A5E045 – Frequently Asked Questions

1) Will an Eaton Freedom Size 2 reversing starter fit in my panel, and what are its dimensions?
The Freedom Size 2 reversing starter, model AN59GN0A5E045, measures 6.7 in wide, 4.98 in deep and 7.1 in high. It is built for horizontal mounting, so lay out your backpan with that orientation in mind. Because it is an Open type unit with no enclosure, it has to go inside a panel or enclosure you provide.
2) Do I need a separate enclosure for the Eaton AN59GN0A5E045 motor starter?
Yes. This is an Open type starter, meaning the contactors and overload relay are mounted on an open frame with no cover or box. It is intended to be installed inside a control panel or enclosure, which is how OEM panel builders normally buy it. If you need a standalone starter for a wall in a wet or dusty area, you want an enclosed NEMA-rated version instead, not this one.
3) What size motor will a NEMA Size 2 reversing starter handle?
NEMA Size 2 is the medium-horsepower step in the NEMA frame progression, and this Freedom unit is rated 45A continuous. Horsepower depends on your supply voltage and phase, so size the motor by its full load amps against the 45A rating and set the C440 overload to the motor FLA. If your motor nameplate amps run above 45A, you need the next NEMA size up.
4) What overload protection comes with the Eaton Freedom Size 2 reversing starter, and is it adjustable?
It ships with Eaton's C440 electronic overload relay (EOLR) in the standard feature set, with SEL reset and selectable trip classes of 10a, 10, 20 and 30. That means you set the trip class to match the load, class 10 for a general pump or fan, class 20 or 30 for high-inertia loads like large conveyors or fans that take longer to come up to speed. No separate heater packs to order.
5) Should I use a reversing starter or two separate contactors for a forward/reverse motor circuit?
A reversing starter does the job in one assembly. The AN59GN0A5E045 is a NEMA reversing configuration, so the forward and reverse contactors come pre-assembled with a shared overload relay, which saves panel space and the wiring work of interlocking two separate starters yourself. If the motor only ever runs one direction, buy a non-reversing Size 2 starter instead and don't pay for the second contactor.
6) Is the Eaton AN59GN0A5E045 starter UL listed for a commercial inspection?
Yes, the Freedom Size 2 reversing starter is UL Listed, and it is also RoHS compliant. That covers the usual electrical inspection and procurement requirements on commercial and industrial panel work.
7) Is an open reversing starter like this a good fit for a conveyor or pump control panel?
That's exactly what it's built for. Reversing pump, fan and conveyor circuits are the typical use, along with OEM control panel building. The open construction and the 6.7 x 4.98 x 7.1 inch footprint let it sit on a backpan alongside the disconnect and control transformer, and the C440's selectable trip classes let you tune the overload to a conveyor's longer acceleration.
