Eaton One-Element Surface Moun...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$67.16
Eaton One-Element Surface Mounting Enclosure, 22.5 mm, Non-Illuminated

Eaton One-Element Surface Mounting Enclosure, 22.5 mm, Non-Illuminated

(No reviews yet) Write a Review

Model: M22-I1-PG

In Stock (leaves warehouse same day if ordered before 3pm ET)

$67.16
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton M22 Two-Element Surface Mount Enclosure, Non-Illuminated

The Eaton M22 Two-Element Surface Mounting Enclosure is a non-illuminated enclosure designed to house Eaton's 22.5 mm M22 modular pushbuttons and pilot devices using base-mounted contact blocks. Built with a white enclosure body and black base, this two-element unit measures 3 in wide x 4.5 in deep x 2.5 in high, giving panel builders a compact, field-proven housing for operator interface stations. Rated IP67, IP69K, NEMA 4X, and NEMA 13, it is engineered for reliable performance in washdown, outdoor, and other harsh-duty industrial environments.

Key Features

  • Mounting Size: Sized for 22.5 mm Eaton M22 modular pushbuttons and pilot devices.
  • Two-Element Configuration: Surface-mount enclosure accommodates two M22 device positions in a single housing.
  • Compact Dimensions: 3 in product width x 4.5 in product length/depth x 2.5 in product height.
  • Durable Construction: White enclosure color with a black base for clear operator visibility and long-term durability.
  • Non-Illuminated Design: Suited for applications that do not require internal pilot lighting.
  • Environmental Rating: IP67, IP69K, NEMA 4X, and NEMA 13 rated for wet, washdown, and outdoor-capable installations.
  • Base-Mounted Contact Block Ready: Requires use of base mounted contact blocks (sold separately) per Eaton catalog notes.

Certifications & Compliance

  • CSA Certified
  • Bureau Veritas Compliance
  • IP67 Rated
  • IP69K Rated
  • NEMA 4X Rated
  • NEMA 13 Rated

Technical Specifications

  • Product Type: Pushbutton
  • Series: M22
  • Department: Electrical

Typical Applications

  • Industrial Control Panels and Operator Stations
  • Washdown and Food/Beverage Processing Environments
  • Outdoor and Wet-Location Equipment Enclosures
  • Machine Building and Process Control Stations
  • OEM Panel Assembly Using M22 Modular Pushbuttons

Why Eaton?

Eaton's M22 enclosure line is built to back demanding industrial applications with CSA-certified construction and Bureau Veritas compliance. With IP67, IP69K, NEMA 4X, and NEMA 13 environmental ratings, this two-element surface mounting enclosure is engineered to protect M22 modular pushbuttons in washdown, outdoor, and harsh-duty control environments where dependable, code-compliant performance is essential.

Manufacturer Resources

Product Specs

Enclosure Color:
White
Base:
Black
Environmental Rating:
IP67, IP69K, NEMA 4X, NEMA 13
Catalog Notes:
Requires use of base mounted contact blocks
Department:
Electrical
Series:
M22
Product Color:
White
Illumination:
Non-illuminated
Product Width:
3 in
Product Size:
22.5 mm
Product Group:
Boxes & Enclosures
Product Type:
Pushbutton Enclosure
Product Subgroup:
Enclosures

Eaton M22-I1-PG – Frequently Asked Questions

1) Will the Eaton M22 surface mount enclosure hold my 22.5 mm pushbuttons?
Yes. The M22 enclosure is sized for 22.5 mm M22 modular pushbuttons and pilot devices, which is the standard operator device cutout for this line. Pick the 1-element version (M22-I1-PG) for a single device or the 2-element version (M22-I2-PG) for two.
2) Do I need to buy anything else to make an Eaton M22 enclosure station work?
Yes. The enclosure ships as the housing only. You supply the M22 operator (pushbutton or pilot device) and, per Eaton's catalog note, base mounted contact blocks are required. Front-mounted contact block assemblies will not work in this housing.
3) Can this M22 enclosure go outdoors or in a washdown area?
It is rated IP67, IP69K, NEMA 4X and NEMA 13, so it handles high pressure washdown, wet locations, oil and coolant, and outdoor-capable mounting. IP69K is the rating food and beverage plants look for when the line gets hosed down at high pressure and temperature.
4) What is the difference between the M22-I1-PG and M22-I2-PG enclosures?
Only the number of device positions. M22-I1-PG is a one-element box for a single 22.5 mm operator; M22-I2-PG takes two. Everything else matches: white enclosure body, black base, non-illuminated, same environmental ratings.
5) Is the Eaton M22 enclosure illuminated, and does that limit which pushbuttons I can install?
The enclosure itself is non-illuminated, meaning there is no lighting built into the housing. It is intended for applications that do not need internal pilot lighting. If your station calls for an illuminated indicator, that function comes from the M22 device you install, not the box.
6) How much panel or machine space does the M22 enclosure take up?
The M22 surface mount enclosure is 3 in wide, and the two-element housing is described at 3 in wide x 4.5 in deep x 2.5 in high. It surface mounts, so you do not need to cut a 22.5 mm hole in the machine skin, which is why panel builders use it for add-on stop and start stations on existing equipment.
7) Does the Eaton M22 enclosure carry any third-party certification for plant use?
It is CSA Certified and carries Bureau Veritas compliance, alongside the IP67, IP69K, NEMA 4X and NEMA 13 ratings. That combination is what most facility and OEM specs want for a washdown-duty operator station.
8) Will a white enclosure with a black base match the rest of my M22 stations?
The housing is white with a black base, which is the standard M22 surface station color scheme across the line. For a facility standardizing on M22, one and two element boxes share that same white body and black base so a fleet of stations looks consistent.
