Eaton Prism 18mm Tubular Photoelectric Sensor, Right Angle
The Eaton Prism 18mm Tubular Photoelectric Sensor is a right-angle, polarized retroreflective sensor built with a structural polyurethane foam enclosure for durability in demanding industrial environments. Featuring an isolated solid-state relay output, a 10-30 Vdc input voltage, and a 6.6 ft (2 m) cable connection, this sensor delivers reliable object detection for automation and machine-control applications. It carries multiple NEMA environmental ratings (NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 12, NEMA 13) and is cUL Recognized, making it suitable for washdown and harsh-duty settings. Note: a compatible retroreflector is required for a complete system and is sold separately.
Key Features
- Compact 18mm Tubular Housing: Right-angle body style measuring .71 in wide, .47 in deep, and 2.75 in tall for space-constrained mounting.
- Durable Construction: Structural polyurethane foam enclosure body for long-term reliability in industrial settings.
- Polarized Retroreflective Sensing: Photoelectric switch type operating in polarized retroreflective mode for accurate object detection; retroreflector sold separately.
- Isolated Solid-State Relay Output: Contact configuration provides an isolated solid-state relay rated at 80 mA at 132 Vac / 110 mA at 132 Vdc.
- Wide Input Voltage Range: Operates on 10-30 Vdc input with a maximum DC current of 110 mA and maximum AC current of 80 mA.
- Red LED Output Indicator: Visual output-status LED simplifies field diagnostics and troubleshooting.
- Rugged Environmental Ratings: Rated NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 12, and NEMA 13 for use in wet, dusty, and washdown locations.
- Wide Operating Temperature Range: Performs from -13 °F to 131 °F for indoor and outdoor industrial use.
- PVC Cable Connection: Terminates with a 6.6 ft (2 m) polyvinyl chloride cable for straightforward wiring.
Certifications & Compliance
- cUL Recognized
- CE Marked
- NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 12, NEMA 13 Rated Enclosure
Technical Specifications
- Warranty: 3 year
- Department: Electrical
Typical Applications
- Industrial Automation and Machine Control
- Conveyor and Material Handling Systems
- Packaging and Assembly Line Object Detection
- Washdown and Wet-Location Sensing Environments
- Control Panel and Cabinet Integration
Why Eaton?
Eaton engineers the Prism sensor line with rugged structural polyurethane foam enclosures, isolated solid-state relay outputs, and broad NEMA environmental ratings to deliver dependable performance in tough industrial environments. Backed by a 3-year warranty and cUL Recognition, this photoelectric sensor is built for code-compliant, professional-grade automation and control applications.
Manufacturer Resources
Product Specs
- Product Height:
- 2.75 in
- Cord length:
- 79.2 ft
- Operating temperature - min:
- -13 °F
- Warranty:
- 3 year
- Department:
- Electrical
- Maximum DC current:
- 110 mA
- Switch Classification:
- Photoelectric
- Connection:
- 6.6 ft (2 m) cable
- Contact configuration:
- Isolated solid state relay
- Product Width:
- .71 in
- Product Type:
- Photoelectric Sensor
- Cable type:
- Polyvinyl Chloride (PVC)
- Compliances:
- CE Marked
- Protection:
- Current limited for loads less than 32 Vac/dc
- Amperage Rating:
- 110 mA
- Product Length/Depth:
- .47 in
- Operating temperature - max:
- 131 °F
- Maximum AC current:
- 80 mA
- LED indicator:
- Output status: red
- Product Material:
- Polyurethane Foam
- Configuration:
- Right Angle
- Voltage Rating:
- 10-30 Vdc
- Listing:
- cUL Recognized
- Product Group:
- Wiring Devices
