Eaton 30.5 mm Heavy-Duty Key Selector Switch

Eaton 30.5 mm Heavy-Duty Key Selector Switch

The Eaton 30.5 mm Heavy-Duty Key Selector Switch (Series 10250T) is a rugged 3-position selector designed for industrial control panels, machine controls, and equipment requiring secure, key-operated switching. Built on Eaton's Heavy-Duty 30.5 mm platform, this non-illuminated selector switch features a 60° throw and is rated NEMA 3, NEMA 3R, NEMA 4, NEMA 4X, NEMA 12, and NEMA 13 for use across a wide range of indoor and outdoor environments, including washdown and dusty locations. Its key-operated actuator with center-only key removal helps ensure that only authorized personnel can change the switch position, making it well suited for machine safety and access-control applications.

Key Features

• Compact Footprint: Measures 1.8 in wide x 2.2 in deep x 2 in tall, fitting standard 30.5 mm panel cutouts without crowding adjacent devices.
• Heavy-Duty Construction: 30.5 mm Heavy-Duty type from the Eaton 10250T Series, built for demanding industrial control panel applications.
• Key-Operated Actuator: Key actuator with center-only key removal position restricts switching to authorized personnel.
• 3-Position Switching: Three-position selector with a 60° throw for clear, positive selection between operating states.
• Configurable Cam: Uses Eaton's cam-based contact configuration system to set switching sequence for the application.
• Non-Illuminated Design: Non-illuminated body simplifies wiring for applications that do not require indicator lighting.
• Broad Environmental Ratings: Rated NEMA 3, NEMA 3R, NEMA 4, NEMA 4X, NEMA 12, and NEMA 13 for indoor, outdoor, washdown, and dust-tight enclosure use.

Certifications & Compliance

• UL Listed
• CE Marked
• NEMA 3, NEMA 3R, NEMA 4, NEMA 4X, NEMA 12, NEMA 13 Rated

Technical Specifications

• Warranty: 1 year
• Department: Electrical

Typical Applications

• Industrial Control Panels and Machine Control Stations
• Manufacturing and Process Automation Equipment
• HVAC and Building Control Systems
• Outdoor and Washdown-Rated Equipment Enclosures
• Security-Sensitive Operator Interfaces Requiring Key Control
• Panel Retrofits and New Machine Builds Using the Eaton 10250T Platform

Why Eaton?

Eaton's 10250T Heavy-Duty pushbutton and selector switch platform is engineered for reliable, code-compliant performance in demanding electrical control applications. With UL Listing, CE Marking, and multiple NEMA environmental ratings spanning NEMA 3 through NEMA 13, this key-operated selector switch delivers the durability, secure operation, and consistent switching performance that professional panel builders, OEMs, and maintenance teams depend on for critical control applications.
