Eaton Heavy-Duty Watertight PresTest LED Indicating Light

Eaton Heavy-Duty Watertight PresTest LED Indicating Light

(No reviews yet) Write a Review

Model: 10250T297L

In Stock (leaves warehouse same day if ordered before 3pm ET)

$262.14
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton Heavy-Duty Watertight PresTest LED Indicating Light

The Eaton Heavy-Duty Watertight PresTest LED Indicating Light is a rugged, watertight and oiltight pilot light built for demanding industrial control panels. Featuring a 30.5 mm mounting size, a full voltage LED light unit rated for 120V, and a NEMA 3 enclosure rating, this Eaton indicating light delivers reliable visual status signaling in harsh environments. The PresTest actuator allows the LED lamp to be tested for function without removing the red plastic lens, simplifying maintenance and reducing downtime.

Key Features

  • Mounting Size: 30.5 mm size fits standard 10250T series panel cutouts for easy retrofit and installation.
  • Durable Construction: Heavy-duty watertight and oiltight design with a plastic lens for long-lasting performance in industrial settings.
  • PresTest Actuator: Allows the LED lamp to be tested in place without removing the lens, streamlining maintenance checks.
  • Electrical Rating: 120V light unit voltage with a full voltage LED light unit type for consistent, energy-efficient illumination.
  • Environmental Rating: NEMA 3 rated for indoor and outdoor use where protection from falling rain, sleet, and snow is required.
  • Lens Color and Finish: Red plastic lens for clear, high-visibility status indication on the panel.
  • Compact Dimensions: Product Width 2.2 in, Length/Depth 2.6 in, and Height 4.7 in for space-conscious panel layouts.

Certifications & Compliance

  • CSA Certified
  • CE Marked
  • NEMA 3 Rated for Indoor/Outdoor Use

Technical Specifications

  • Light unit voltage: 120V
  • Product Width: 2.2 in
  • Rating: NEMA 3
  • Lens color: Red
  • Size: 30.5 mm
  • Product Length/Depth: 2.6 in
  • Product Height: 4.7 in
  • Light unit type: Full voltage LED
  • Lens material: Plastic
  • Series: 10250T
  • Compliances: CE Marked
  • Actuator: PresTest
  • Certifications: CSA Certified
  • Department: Electrical
  • Product Type: Pushbutton

Typical Applications

  • Industrial and Commercial Control Panels
  • Machine and Equipment Status Indication
  • Outdoor and Wet-Location Control Stations
  • Panelboard and Control Station Wiring
  • Renovation and New Construction Control Panels

Why Eaton?

Eaton engineers its 10250T series indicating lights for dependable performance in tough industrial and wet-location environments. With a watertight and oiltight plastic lens housing, NEMA 3 environmental rating, CSA Certification, and CE Marking, this Eaton PresTest LED Indicating Light delivers code-compliant, reliable status signaling that professional electricians and panel builders can trust.

Manufacturer Resources

Product Specs

Series:
10250T
Department:
Electrical
Actuator:
PresTest
Compliances:
CE Marked
Product Type:
Indicating Light
Product Material:
Plastic
Product Color:
Red
Voltage Rating:
120V
Standards:
NEMA 3
Listing:
CSA Certified
Product Group:
Motor Control & Automation
Product Subgroup:
Push Buttons & Pilot Devices

Eaton 10250T297L – Frequently Asked Questions

1) Will the Eaton 10250T PresTest indicating light fit a standard 30.5 mm panel cutout?
Yes. The 10250T series indicating light uses the 30.5 mm mounting size, so it drops into standard 10250T panel cutouts on existing control panels and control stations without redrilling. That is the same hole size used across the heavy-duty 30.5 mm pushbutton family, which makes it a straight swap when you are replacing an older pilot light in an existing station.
2) Can I use this Eaton pilot light outdoors or in a washdown area?
It is rated NEMA 3, which covers indoor and outdoor use where the enclosure has to shed falling rain, sleet and snow. The construction is watertight and oiltight, so it holds up in wet control stations and oily machine environments. NEMA 3 is not a hosedown or submersion rating, so for direct high-pressure washdown you want a device rated for that duty instead.
3) What voltage does the Eaton 10250T LED indicating light run on, and does it need a transformer?
The light unit is a full voltage LED rated 120V, so it wires directly to a 120V control circuit with no separate transformer or resistor block. If your panel runs 24V control power, this is the wrong unit.
4) Can this replace an incandescent pilot light in an existing 10250T control station?
Yes, provided the station is a 30.5 mm 10250T cutout and the circuit is 120V. This is a full voltage LED unit, so it draws less than an incandescent lamp on the same 120V feed and mounts in the same hole. Match the lens color if the rest of the panel is color-coded, since this one is red.
5) What does the PresTest actuator on this Eaton indicating light actually do?
PresTest lets you press the lens to test the LED in place. You confirm the lamp is working without pulling the lens off or de-energizing the station, which is what panel maintenance crews use it for during routine checks. On a plain indicating light you would have to remove the lens to check the lamp.
6) Is the Eaton 10250T indicating light certified for use in a commercial or institutional control panel?
It is CSA Certified and CE Marked, alongside the NEMA 3 enclosure rating. That is the documentation a panel builder or facility electrician typically needs on file for a control station going into industrial, commercial or outdoor service.
7) How much room do I need behind the panel for this Eaton pilot light?
Plan for a device measuring 2.2 in wide, 2.6 in in length/depth and 4.7 in in height. The depth figure is the one that matters when the panel door is crowded with wireway or when the enclosure is shallow.
8) What are the differences between the Eaton 10250T part numbers offered?
Four catalog numbers are sold under the heavy-duty 10250T PresTest indicating light: 10250T297L and 10250T297LRP2A, the watertight 10250T221LWP06, and 10250T74NA. Order by the exact catalog number your panel drawing or existing device calls out, since the actuator and packaging differ between them.
9) What color and lens material does the Eaton PresTest LED light use?
Red lens, molded plastic rather than glass. Red is the usual choice for a stop, fault or power-on indication on a machine panel, and plastic takes impact better than glass in a production environment.
