Eaton Three-Pole Reversing Dru...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$1,428.59
Eaton Three-Pole Reversing Drum Switch, Lever Operator, Oiltight

Eaton Three-Pole Reversing Drum Switch, Lever Operator, Oiltight

(No reviews yet) Write a Review

Model: 9441H276

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,428.59
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton Three-Pole Reversing Drum Switch, Lever Operator, Oiltight

The Eaton Three-Pole Reversing Drum Switch is a maintained-and-momentary motor control device built without an overload relay, designed for direct-reversing control of three-phase motors. Operated by a lever, this oiltight switch supports flush or cavity mounting for clean integration into control panels and machine enclosures. Measuring 5.3 in in length/depth and 5.6 in in height, it delivers dependable, code-compliant switching for demanding industrial motor control applications.

Key Features

  • Three-Pole Configuration: Three-pole switching supports direct reversing control of three-phase motor circuits.
  • Lever Operator: A lever operator provides positive, easy-to-actuate control for maintained and momentary switching modes.
  • Maintained and Momentary Operation: Dual operating modes give installers flexibility for continuous-run or momentary jog control applications.
  • Oiltight Design: Oiltight construction helps protect internal contacts from oil, dust, and coolant exposure in machine-shop and industrial environments.
  • Flush or Cavity Mounting: Supports flush or cavity mounting for a clean, low-profile installation in control panels and enclosures.
  • Compact Footprint: Product dimensions of 5.3 in (length/depth) by 5.6 in (height) suit space-constrained panel layouts.
  • No Integral Overload Relay: Supplied without an overload relay, allowing pairing with separately specified motor protection where required.

Certifications & Compliance

  • NLRV Compliant

Technical Specifications

  • Number of Poles: Three-pole
  • Product Length/Depth: 5.3 in
  • Product Height: 5.6 in
  • Operator: Lever
  • Mounting: Flush, cavity, oiltight
  • Warranty: 1 year
  • Compliances: NLRV

Typical Applications

  • Three-Phase Motor Reversing Control
  • Industrial Machine Control Panels
  • Commercial and Industrial Electrical Installations
  • Machine Shop and Manufacturing Equipment
  • Panel and Enclosure Retrofit or New Construction

Why Eaton?

Eaton engineers motor control components like this reversing drum switch for the demands of professional industrial environments, combining a durable oiltight housing with flexible lever-operated, maintained-and-momentary switching. Backed by a 1-year warranty and built to comply with NLRV requirements, this drum switch offers electricians and panel builders a reliable, code-compliant solution for three-phase motor reversing control.

Manufacturer Resources

Product Specs

Number Of Poles:
Three-pole
Product Length/Depth:
5.3 in
Product Height:
5.6 in
Warranty:
1 year
Mounting Method:
Flush, cavity, oiltight
Operator:
Lever
Compliances:
NLRV
Product Type:
Specialty Switch
Department:
Electrical
Configuration:
3-Pole
Standards:
NLRV
Product Group:
Wiring Devices
Product Subgroup:
Switches
Product Length:
5.3 in

Eaton 9441H276 – Frequently Asked Questions

1) Can an Eaton 9441H drum switch reverse a three-phase motor directly, without a contactor?
That is what it is built for. The 9441H is a three-pole reversing drum switch for direct-reversing control of three-phase motors, operated by a lever. It handles both maintained and momentary switching, so you can use it for continuous-run duty or for jog control off the same device. Note that it comes with no integral overload relay, so motor overload protection has to be specified separately in the circuit.
2) Does this Eaton drum switch include motor overload protection?
No. The 9441H reversing drum switch is supplied without an overload relay. It switches and reverses the motor only. You need a separate overload device, such as a starter or overload relay sized to the motor full-load amps, to protect the motor.
3) Will an Eaton 9441H drum switch hold up in a machine shop with coolant and oil spray?
Its housing is an oiltight design, which is specifically intended to keep oil, dust, and coolant off the internal contacts. That is the usual reason it gets specified on lathes, mills, and other shop equipment rather than an open drum switch.
4) How much panel space do I need for the Eaton 9441H drum switch?
Plan on a device measuring 5.3 in length/depth and 5.6 in height. Mounting is flush or cavity, oiltight, so the body sits behind the panel face with the lever out front. Lay out your enclosure depth against the 5.3 in figure before you cut the opening.
5) What is the difference between the DB 1 and DB 2 versions of the Eaton 9441H drum switch?
They are the two size selections on the 9441H reversing drum switch: DB 1 is Eaton part number 9441H276 and DB 2 is 9441H347. Order by that part number so you get the frame size your panel drawing calls for.
6) Is a drum switch the right choice, or should I use a reversing starter instead?
A drum switch like the Eaton 9441H is a manual device: the operator throws a lever and the contacts carry the motor current directly, with no coil, no pilot circuit, and no overload relay in the unit. That suits a machine where someone is standing at the control and reversing by hand. If you need remote pushbutton control, interlocking, low-voltage control wiring, or built-in overload protection, a magnetic reversing starter is the correct device instead.
7) Can I use the Eaton 9441H for jogging a machine as well as running it?
Yes, it is a maintained-and-momentary device. Held in a momentary position it jogs, and set to a maintained position it stays put for continuous run. That means one lever covers both setup jogging and normal operation on the same machine.
8) What compliance does the Eaton 9441H reversing drum switch carry?
It is listed as NLRV compliant. That is the only standard stated for the 9441H, so if your specification calls for another listing, verify it against Eaton's published data for the specific part number you are ordering.
How fast can I get the Eaton 9441H276 delivered?
Most orders ship the same day from our distribution partners, with quick delivery throughout the continental U.S. Need it urgently? Contact Us for expedited shipping options.
Can I return it if it doesn’t work for me?
Yes—ZenSupply offers a hassle-free return policy. If the product isn’t the right fit, reach out to our support team for a return authorization or setup a return by following our return instructions.
Does the Eaton 9441H276 come with a warranty?
Absolutely. The Eaton 9441H276 is backed by a manufacturer’s warranty. For full warranty terms, check the product documentation or Contact Us.
How do I get technical support or installation help for the Eaton 9441H276?
You can call, text, or email our expert support team for fast answers. We’re here to help with product selection, installation tips, and troubleshooting. Contact Us
