Spec Sheet
Product Specs
- Amperage Rating:
- 175A
- Circuit Breaker Frame Type:
- Complete breaker
- Circuit Breaker Type:
- ED
- Frame Size:
- F-frame
- Frequency Rating:
- 50-60 Hz
- Interrupt Rating:
- 65 kAIC at 240 Vac
- Number Of Poles:
- Three-pole
- Series:
- Series C
- Terminals:
- Line and load
- Trip Type:
- Fixed thermal, fixed magnetic
- Voltage Rating:
- 240 Vac, 125 Vdc
- Department:
- Electrical
- Product Length:
- 3.38 IN
- Product Height:
- 4.13 IN
- Product Weight:
- 4.5 LB
- Product Width:
- 4.13 IN
B-LINE ED3175 – Frequently Asked Questions
1) What is the interrupting rating of the Eaton ED3175 molded case breaker?
65 kAIC at 240 Vac. That covers most commercial service entrance and distribution locations where available fault current is high, and it is the number your engineer needs for a series or fully rated short circuit study.
2) Is the ED3175 a three-pole 175 amp breaker?
Yes, three-pole, 175 A. It is an F-frame ED type breaker in Eaton's Series C line, supplied as a complete breaker rather than a trip unit or frame only, with both line and load terminals.
3) Is the trip on the ED3175 adjustable?
No. The ED3175 uses a fixed thermal, fixed magnetic trip, so there is no adjustable instantaneous dial and no interchangeable trip unit. The 175 A rating is what you get. If the job calls for field-adjustable settings you need an adjustable magnetic or electronic trip breaker instead.
4) Do I need to order a separate trip unit or terminals with the ED3175?
No. It ships as a complete breaker with line and load terminals already on it, so there is no separate trip unit or terminal kit to add. Mounting hardware, lugs sized to your conductor, and any accessories such as shunt trips or auxiliary switches are ordered separately.
5) What are the dimensions and weight of the ED3175 so I can check my enclosure space?
The breaker measures 4.13 in height, 3.38 in length and 4.13 in width, and weighs 4.5 lb. Use those figures to confirm gutter space and interior clearance before you cut in, particularly in a retrofit enclosure sized for a smaller frame.
6) Will an ED-frame breaker replace another F-frame Eaton breaker in my panel?
The ED3175 is an F-frame, ED type Series C breaker, so it shares the F-frame footprint used across that family. Matching frame class is only part of it though, you also have to match the panel or switchboard mounting method and confirm the enclosure is listed for an ED breaker. Voltage is the hard limit: at 240 Vac max it will not substitute for a 480 V rated F-frame breaker.
7) Can the ED3175 be used on DC as well as AC?
Yes, it carries a 125 Vdc rating alongside the 240 Vac rating, so it can be applied on 125 V DC circuits such as battery or control power systems. The published 65 kAIC interrupting rating is the 240 Vac figure.
8) What part number should I put on the purchase order for this 175A three-pole breaker?
Order it as ED3175, Eaton Series C. There is a single configuration, so there are no suffixes or options to specify beyond that number.
