Spec Sheet
Product Specs
- Amperage Rating:
- 80A
- Circuit Breaker Frame Type:
- Complete breaker
- Circuit Breaker Type:
- EHD
- Frame Size:
- F-frame
- Frequency Rating:
- 50/60 Hz
- Interrupt Rating:
- 18 kAIC at 240 Vac, 14 kAIC at 480 Vac
- Number Of Poles:
- Two-pole
- Series:
- Series C
- Terminals:
- Load side
- Trip Type:
- Fixed thermal, fixed magnetic
- Department:
- Electrical
- Product Length:
- 3.38 IN
- Product Height:
- 6 IN
- Product Weight:
- 3 LB
- Product Width:
- 2.75 IN
- Frame:
- F
- Certifications:
- UL Listed
B-LINE EHD2080 – Frequently Asked Questions
1) What is the interrupting rating of the Eaton EHD2080 circuit breaker at 240V and 480V?
The EHD2080 is rated 18 kAIC at 240 Vac and 14 kAIC at 480 Vac. That is the number to check against the available fault current calculated at your panel location; if the engineer's short circuit study shows more than 14 kA at a 480V board, this F-frame EHD will not meet the requirement and you need a higher interrupting frame.
2) Does the EHD2080 have an adjustable trip setting?
No. The EHD2080 uses a fixed thermal, fixed magnetic trip unit, so both the overload and the instantaneous pickup are set at the factory and there is nothing to dial in during commissioning. If your coordination study calls for an adjustable instantaneous, you need a different trip type.
3) What is the correct part number to order this 80A two-pole Eaton breaker?
Order it as EHD2080. That is the manufacturer part number for the 80A two-pole EHD complete breaker in the Eaton Series C molded case line, and it is the designation a distributor or facility electrician should quote to avoid getting a frame-only or trip-unit-only item.
4) Will the EHD2080 breaker fit in the space I have in the panel?
The EHD2080 measures 6 in high, 3.38 in long and 2.75 in wide, and weighs 3 lb. Those are F-frame proportions, so confirm your enclosure or panelboard interior is prepped for an F-frame two-pole mounting before ordering.
5) What terminals come on the EHD2080 and do I need to order lugs separately?
Load side terminals are what the EHD2080 is specified with. Verify the wire range against your 80A feeder conductors, and if your installation requires line side terminations or a different lug type, plan on the appropriate terminal kit for the F-frame.
6) Can I use this Eaton EHD breaker on a 50 Hz system?
Yes. The EHD2080 carries a 50/60 Hz frequency rating, so it works on both North American 60 Hz and 50 Hz distribution.
How fast can I get the B-LINE EHD2080 delivered?
Most orders ship the same day from our distribution partners, with quick delivery throughout the
continental
U.S.
Need it urgently? Contact Us for expedited shipping options.
Can I return it if it doesn’t work for me?
Yes—ZenSupply offers a hassle-free return policy. If the product isn’t the right fit,
reach out to our support team for a return authorization or setup a return by following our return instructions.
Does the B-LINE EHD2080 come with a warranty?
Absolutely. The B-LINE EHD2080 is backed by a manufacturer’s warranty.
For full warranty terms, check the product documentation or Contact Us.
