Product Specs
- Amperage Rating:
- 30A
- Circuit Breaker Frame Type:
- Complete breaker
- Circuit Breaker Type:
- FD
- Frame Size:
- F-frame
- Frequency Rating:
- 50/60 Hz
- Interrupt Rating:
- 65 kAIC at 240 Vac, 35 kAIC at 480 Vac
- Number Of Poles:
- Two-pole
- Series:
- Series C
- Terminals:
- Load side
- Trip Type:
- Fixed thermal, fixed magnetic
- Voltage Rating:
- 600 Vac, 250 Vdc
- Department:
- Electrical
- Product Length:
- 3.38 IN
- Product Height:
- 6 IN
- Product Weight:
- 3 LB
- Product Width:
- 2.75 IN
B-LINE FD2030 – Frequently Asked Questions
1) What is the interrupting rating of the Eaton FD2030 breaker at 240V and 480V?
The FD2030 F-frame breaker is rated 65 kAIC at 240 Vac and 35 kAIC at 480 Vac. If your available fault current at the panel exceeds those numbers, this breaker is not the right device for that location. Its full voltage rating is 600 Vac and 250 Vdc, so it can also be applied on DC circuits within that limit.
2) Is the FD2030 a two-pole 30 amp breaker?
Yes, the Eaton Series C FD2030 is a two-pole breaker with a 30A continuous rating, so it serves a single 240V two-wire circuit or two phases of a three-phase system. For a three-phase load you need the three-pole FD-frame version instead.
3) Can the trip setting on the Eaton FD2030 be adjusted?
No. The FD2030 uses a fixed thermal, fixed magnetic trip unit, so both the overload and the instantaneous trip points are factory set and cannot be dialed in the field. If your coordination study calls for an adjustable instantaneous setting, you need an FD-frame breaker with an adjustable magnetic trip, not this one.
4) Does the FD2030 come as a complete breaker or do I have to order a trip unit separately?
It ships as a complete molded case breaker of the FD type, meaning the frame and the fixed 30A trip are supplied as one assembly. There is no separate rating plug or trip unit to specify.
5) How much room do I need in the enclosure for an FD2030 breaker?
Plan for a device measuring 6 x 3.38 x 2.75 inches (height, length, width) and weighing 3 lb. That is the standard Eaton F-frame two-pole footprint, so it drops into panelboards and enclosures prepped for F-frame devices.
6) What terminals does the FD2030 have, and can I feed it from either end?
The FD2030 is supplied with load side terminals. Line connection is made at the breaker's line end, typically by panel bus or a separately ordered line side terminal kit, so confirm your connection method for the line side before you order lugs.
7) What part number do I order to replace an existing Eaton FD-frame 30 amp two-pole breaker?
The catalog number is FD2030, an Eaton Series C F-frame complete breaker. Match it against the number printed on the face of the breaker you are pulling out; the FD prefix identifies the frame and interrupting class, and the last digits give the 30A two-pole rating.
8) Will an Eaton FD2030 work on a 50 Hz system for an export or imported machine?
Yes. The breaker carries a 50/60 Hz frequency rating, so it can be applied on 50 Hz equipment as well as standard North American 60 Hz distribution, within its 600 Vac limit.
