Spec Sheet
Product Specs
- Amperage Rating:
- 50A
- Circuit Breaker Frame Type:
- Complete breaker
- Circuit Breaker Type:
- FDB
- Frame Size:
- F-frame
- Frequency Rating:
- 50/60 Hz
- Interrupt Rating:
- 18 kAIC at 240 Vac, 14 kAIC at 480 Vac
- Number Of Poles:
- Two-pole
- Series:
- Series C
- Terminals:
- Load side
- Trip Type:
- Fixed thermal, fixed magnetic
- Voltage Rating:
- 600 Vac, 250 Vdc
- Department:
- Electrical
- Product Length:
- 3.38 IN
- Product Height:
- 6 IN
- Product Weight:
- 3 LB
- Product Width:
- 2.75 IN
B-LINE FDB2050 – Frequently Asked Questions
1) Will the Eaton FDB2050 breaker work on a 480V three-phase panel?
The FDB2050 is rated 600 Vac and 250 Vdc, so 480V is within its voltage rating. Watch the interrupting capacity though: it's 18 kAIC at 240 Vac but only 14 kAIC at 480 Vac. If your available fault current at the panel exceeds 14 kA, this two-pole F-frame breaker is not the right choice and you need a higher-AIC frame.
2) Is the FDB2050 a complete breaker or just the frame, and do I need to order a trip unit separately?
It ships as a complete molded case breaker with a fixed thermal, fixed magnetic trip already built in. Nothing to add: no interchangeable trip unit, no rating plug. The trade-off is that the 50A rating and the trip settings can't be adjusted later, so if you need field-adjustable magnetic pickup you want a different Series C breaker.
3) What terminals come on the Eaton FDB2050 and can I land line conductors on it?
Load side terminals are what's provided on this FDB breaker. In a panel or switchboard the line side is meant to connect through the bus or plug-on connection, so if your application needs lugs on both ends you'll have to add the line-side terminal kit for the F-frame rather than assume it's in the box.
4) How much space does the FDB2050 need in an enclosure?
The breaker measures 6 in height, 3.38 in length and 2.75 in width, and weighs 3 lb. Use those figures when you're checking gutter space and door clearance in a small NEMA enclosure, and add for the handle operator or through-door mechanism if you're fitting one.
5) Can I use this Eaton F-frame breaker on a 50 Hz system overseas?
Yes. The FDB2050 carries a 50/60 Hz frequency rating, so it's good on either standard, and it also holds a 250 Vdc rating for DC applications.
6) Is there a spec sheet for the FDB2050?
Yes, Eaton publishes a spec sheet for the FDB2050 and it's linked directly from the product description. That's the document to hand your inspector along with the 50A, 600 Vac ratings if the panel schedule is being reviewed.
