Eaton FG3060S17 Series C compl...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$1,998.30
$1,948.30
Eaton FG3060S17 Series C complete molded case circuit breaker, F-frame, FG, Fixed thermal and magnetic trips, Three-pole, 60A, 600 Vac, 18 kAIC at 240 Vac, 14 kAIC at 480 Vac, Line/load, 12-24 Vac/dc same side w/ right pigtail, Reverse, 60 Hz

Eaton FG3060S17 Series C complete molded case circuit breaker, F-frame, FG, Fixed thermal and magnetic trips, Three-pole, 60A, 600 Vac, 18 kAIC at 240 Vac, 14 kAIC at 480 Vac, Line/load, 12-24 Vac/dc same side w/ right pigtail, Reverse, 60 Hz

(No reviews yet) Write a Review

Model: FG3060S17
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,998.30
$1,948.30
Adding to cart… The item has been added
Free Shipping on orders over $99
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like
Eaton FDB3060LA05 Series C complete molded case circuit breaker, F-frame, FDB, Fixed thermal, fixed magnetic trip, Three-pole, 60A, 600 Vac, 250 Vdc, 18 kAIC at 240 Vac, 14 kAIC at 480 Vac, Line and load, 1A-1B same side w/ right pigtail, 50/60 Hz

Eaton FDB3060LA05 Series C complete molded case circuit breaker, F-frame, FDB, Fixed thermal, fixed magnetic trip, Three-pole, 60A, 600 Vac, 250 Vdc, 18 kAIC at 240 Vac, 14 kAIC at 480 Vac, Line and load, 1A-1B same side w/ right pigtail, 50/60 Hz

Model: EAT-FDB3060LA05

Eaton Series C complete molded case circuit breaker, F-frame, FDB, Fixed thermal, fixed magnetic trip, Three-pole, 60A, 600 Vac, 250 Vdc, 18 kAIC at 240 Vac, 14 kAIC at 480 Vac, Line and load, 1A-1B...

Eaton

$1,837.74
$1,787.74
Eaton Series C complete molded case circuit breaker, F-frame, FG, Fixed thermal and magnetic trips, Three-pole, 60A, 600 Vac, 18 kAIC at 240 Vac, 14 kAIC at 480 Vac, Line/load, 12-24 Vac/dc same side w/ right pigtail, Reverse, 60 Hz

Manufacturer Resources

Product Specs

Amperage Rating:
60 A
Certifications:
UL 489
Circuit Breaker Frame Type:
Complete breaker
Circuit Breaker Type:
FG
Class:
Engine generator
Frame:
F
Frequency Rating:
60 Hz
Functions:
Reverse
Generator Rating:
22 kVA/17 kW at 240 Vac, 43 kVA/35 kW at 480 Vac, 54 kVA/43 kW at 600 Vac
Interrupt Rating:
14 kAIC at 480 Vac
Number Of Poles:
Three-pole
Pickup:
Fixed
Product Height:
6 in
Product Length Depth:
7 in
Product Weight:
4 lb
Product Width:
5 in
Shunt Trip:
12-24 Vac/dc right pigtail same side
Terminals:
Line and load
Trip Type:
Fixed thermal, fixed magnetic
Voltage Rating:
600 Vac
Product Group:
Electrical
!
