Eaton XBT XB Series IEC Termin...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$6.00
Eaton XB IEC terminal block Wide Feed Through Terminal Block

Eaton XBT XB Series IEC Terminal Block, 800V Wide Feed Through

(No reviews yet) Write a Review

Model: XBUT4RD
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$6.00
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton XBT XB Series IEC Terminal Block, 800V Wide Feed Through

The Eaton XBT XB Series IEC Terminal Block delivers a wide feed through design engineered for secure, reliable wire termination in industrial and commercial wiring applications. Rated for IEC 800V, with EN 700V and UL 600V ratings, this professional-grade terminal block provides the electrical capacity and insulation margin demanded by industrial control panels and power distribution systems. The XB Series construction offers standardized mounting and connection methods that simplify installation, while multi-standard voltage compliance across IEC, EN, and UL keeps it versatile for different electrical code applications.

Key Features

  • Voltage Rating: IEC 800V, EN 700V, UL 600V delivers robust electrical capacity with reliable insulation and safety margins for high-voltage industrial use.
  • Wide Feed Through Design: Enables efficient wire routing and connection flexibility for complex wiring configurations and space optimization.
  • XB Series Construction: Delivers consistent terminal block performance with standardized mounting and connection methods for streamlined installation.
  • Multi-Standard Compliance: Meets IEC, EN, and UL voltage requirements, providing versatility across different electrical code applications.
  • Industrial-Grade Materials: Ensures long-term durability and reliable electrical connections in demanding industrial environments.

Certifications & Compliance

  • IEC 800V Rated
  • EN 700V Rated
  • UL 600V Rated

Technical Specifications

  • Product Type: Electrical Component
  • Series: XB Series
  • Voltage Rating: IEC 800V, EN 700V, UL 600V

Typical Applications

  • Industrial Control Panels
  • Manufacturing Equipment
  • Process Control Systems
  • Electrical Distribution Panels
  • Automation Systems
  • Commercial Electrical Installations

Why Eaton?

Eaton XB Series terminal blocks provide dependable electrical connections backed by multi-standard voltage compliance across IEC, EN, and UL, along with industrial-grade construction built for demanding environments. The wide feed through design supports versatile installation options while the XB Series' standardized mounting and connection methods help ensure consistent, code-compliant performance for professional electrical work.

Manufacturer Resources

Product Specs

Product Type:
Terminal Block
Series:
XB Series
Voltage Rating:
800V
Configuration:
Wide Feed Through
Department:
Electrical
Product Group:
Wiring Devices

Eaton XBUT4RD – Frequently Asked Questions

1) Can I use an Eaton XB Series 800V terminal block in a UL 508A control panel rated 600V?
Yes. The XB Series feed through block carries three separate ratings: IEC 800V, EN 700V, and UL 600V. For a panel built to a UL listing you work to the UL 600V number, not the 800V IEC figure. The 800V IEC rating is what applies on export machinery built to IEC rules. Same physical part either way, you just cite the rating that matches the code the panel is being inspected against.
2) Is a feed through terminal block the right choice, or do I need a different type for my control panel?
A feed through block like the XB Series is the plain pass-through: one conductor in, one out, no switching, no fuse, no disconnect function. That is what you want for the bulk of a panel, landing field wiring and carrying it to the internal side. If instead you need to feed a motor starter directly, that is a different animal, the Square D TeSys GV2 top feed terminal block is a 3-pole 63A/690V block made to sit on top of a TeSys D or TeSys U starter rather than run in a general terminal strip. Use the XB for the terminal strip, a starter-specific block where you are feeding the starter.
3) Is the Square D GV1G09 terminal block a drop-in substitute for the Eaton XBUT4 feed through terminal block?
No. The Eaton XBT XB Series is a wide feed through terminal block, a general purpose block used to pass a conductor through and land field wiring in industrial control panels and distribution panels. The Square D GV1G09 is a TeSys GV2 top feed terminal block, a 3-pole 63A/690V block made to feed TeSys D and TeSys U devices. One is a general wire termination block you install as many of as the panel needs; the other is a three-phase feed block matched to a specific starter family. If the drawing calls for feed through blocks landing individual conductors, the GV1G09 does not do that job.
4) I am building machinery for export to Europe, does the Eaton XB Series terminal block meet EN requirements?
The XB Series feed through block holds an EN 700V rating alongside its IEC 800V and UL 600V figures, so one part number covers a machine that has to satisfy both a European and a North American inspection. That is the main reason to specify it on export builds, you are not stocking two different blocks for the same terminal strip depending on where the panel ships.
5) Which terminal block carries the higher voltage rating, the Eaton XBUT4 or the Square D GV1G09?
The Eaton XBT XB Series carries an 800V rating, published as IEC 800V with EN 700V and UL 600V. The Square D GV1G09 TeSys GV2 top feed block is rated 63A/690V. If the panel specification is written to an 800V IEC insulation level, the Eaton XB Series meets it; if the requirement is a 690V three-phase feed at 63A for a TeSys starter, the GV1G09 is rated to that. The two are written to different points on the same spec sheet, so match the rating that the control panel drawing actually calls out.
