Eaton XT IEC FVNR Manual Motor Controller, 45 mm Frame

Eaton XT IEC FVNR Manual Motor Controller, 45 mm Frame

(No reviews yet) Write a Review

Model: XTSC1P6BBA

In Stock (leaves warehouse same day if ordered before 3pm ET)

$522.86
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Eaton XT IEC FVNR Manual Motor Controller

The Eaton XT IEC FVNR Manual Motor Controller delivers full-voltage, non-reversing (FVNR) manual motor control for commercial and industrial equipment. Built on Eaton's XT IEC motor control platform, this manual motor controller family is available across multiple frame sizes and amperage ratings to match a wide range of motor loads. These controllers are CE Marked and CSA certified, making them well suited for motor starting, protection, and disconnect duties in panels, machinery, and OEM control assemblies where reliable, code-compliant control is required.

Key Features

  • IEC Frame Sizing: Available in compact, space-saving IEC frame sizes that fit efficiently within motor control panels and enclosures.
  • Full-Voltage, Non-Reversing Operation: FVNR design provides dependable motor starting, running, and overload protection duty for single-direction motor loads.
  • Control Coil Options: Offered with control coil voltages that deliver consistent, repeatable switching performance in matched control circuits.
  • Compact Footprint: Space-conscious dimensions simplify enclosure sizing and panel layout planning.
  • Manual Motor Controller Design: FVNR configuration provides direct manual start/stop and disconnect control for single-direction motor loads.
  • IEC XT Platform: Part of Eaton's XT IEC motor control line, engineered for coordinated motor protection and control assemblies alongside compatible XT accessories.
  • Family Options: The broader XT IEC FVNR manual motor controller series spans multiple frame sizes and amperage ratings, supporting a range of motor control system designs.

Certifications & Compliance

  • CE Marked
  • CSA File No. 229767, Class 3211-05

Technical Specifications

  • Product Type: Electrical Component
  • Department: Electrical

Typical Applications

  • Commercial and Industrial Motor Control Panels
  • Machinery Start/Stop and Disconnect Switching
  • Motor Protection and Overload Circuits
  • OEM Equipment and Control Cabinet Assemblies
  • Renovation and New Construction Electrical Projects
  • Coordinated Motor Control Center (MCC) Installations

Why Eaton?

Eaton's XT IEC manual motor controllers are engineered for dependable, code-compliant performance in demanding industrial and commercial environments. With CE marking and CSA certification (File No. 229767, Class 3211-05) backing their construction, these Eaton manual motor controllers give electrical professionals a trusted, compact solution for motor control and protection applications across panels, machinery, and OEM equipment.

Variant Specifications

AmperageModelSKU
1-2.5AStandardXTSC1P6BBA
6.3AXTSC6P3BBTDXTSC6P3BBTD

Manufacturer Resources

Product Specs

Department:
Electrical
Compliances:
CE Marked
Product Type:
Manual Motor Controller
Frame size:
45 mm
Product Width:
1.77 in
Standards:
CE Marked
Product Length/Depth:
3.77 in
Product Group:
Motor Control & Automation
Product Subgroup:
Motor Starters & Contactors

Eaton XTSC1P6BBA – Frequently Asked Questions

1) What amperage ratings does the Eaton XT 45 mm manual motor controller come in?
Two ratings are offered on the 45 mm frame: a 1 to 2.5 amp version, model XTSC1P6BBA, and a 6.3 amp version, model XTSC6P3BBTD. Pick the one whose adjustment range brackets your motor's full load amps so the overload trips before the motor does.
2) Can I use a manual motor controller as the motor's disconnect and start/stop device?
That is what the XT IEC FVNR manual motor controller is built for: direct manual start, stop, and disconnect duty plus overload protection for a single-direction motor load. Because it is manual, there is no coil to energize from a remote pushbutton or PLC output, so if you need remote or automatic starting you want a contactor-based starter instead.
3) What else could I use instead of the Eaton XTSC if my motor draws more than 6.3 amps?
The 45 mm Eaton XTSC controllers top out at 6.3 A, so a larger motor needs a higher-rated device. One option ZenSupply carries is the Leviton MS303-DSW, an industrial grade 3-pole manual motor controller rated 30 A at 600 V AC for three-phase motors. It is a different form factor from the IEC DIN-rail XT platform, so panel layout changes if you switch.
4) What is the difference between the Eaton XT IEC FVNR manual motor controller and the Leviton MS303-DSW manual motor controller?
They solve the same duty from two different design families. The Eaton XTSC is an IEC-style manual motor controller on Eaton's XT platform, built on a 45 mm frame with a compact 3.77 in depth by 1.77 in width body sized for DIN-rail panel layouts, and offered in amperage ranges such as 1-2.5A and 6.3A for small motor loads. The Leviton MS303-DSW is an industrial grade 3-pole manual motor controller rated 30A at 600V AC for 3-phase service. If the motor draws only a few amps and the assembly is an IEC control panel with matching XT accessories, the Eaton XTSC fits that build; if the load is a 3-phase motor up to 30A at 600V, the Leviton 30A controller is the one sized for it.
5) Will an Eaton XTSC manual motor controller reverse a motor?
No. FVNR means full-voltage, non-reversing, so it starts and protects a motor in one direction only. For reversing duty you need a reversing starter arrangement, not this controller.
6) Which manual motor controller takes up less panel space, the Eaton XTSC or the Leviton MS303-DSW?
The Eaton XT IEC FVNR controller is the compact one for panel layout purposes: it is a 45 mm frame device measuring 1.77 in wide by 3.77 in deep, sized to sit efficiently inside IEC motor control panels and enclosures. The Leviton MS303-DSW is described as a 3-pole 600V AC 30A industrial grade 3-phase manual motor controller, a heavier-current device for larger motor loads. If enclosure width is the constraint on a small motor circuit, the Eaton XTSC is the narrower body.
7) My spec calls for CE marked components on an export machine. Does the Leviton MS303-DSW work, or should I use the Eaton XTSC?
The Eaton XT IEC FVNR manual motor controller is the one carrying CE marking, along with CSA certification under File No. 229767, Class 3211-05, which is what an export control assembly with a CE requirement is usually written around. The Leviton MS303-DSW is specified as an industrial grade 3-pole 600V AC 30A 3-phase manual motor controller. For a CE marked bill of materials on an OEM machine build, the Eaton XTSC is the controller that meets that line of the spec.
8) Does the Eaton XTSC work with other XT series accessories in a motor control assembly?
Yes, it is part of Eaton's XT IEC motor control line and is intended for coordinated motor protection and control assemblies alongside compatible XT accessories. That matters if you are standardizing a panel or an MCC build on one platform.
