Eaton XT IEC B Frame Line Side Adapter

The Eaton XT IEC Line Side Adapter is a snap-on accessory engineered for use with the Eaton XTPR manual motor protector to create a UL 508 Type E/F manual combination starter. Sized for the B frame, this compact adapter measures 45 mm wide, 42 mm high, and 33 mm deep, and is CE Marked to EN 60947-4-1 for reliable performance in IEC-based motor control assemblies. It replaces the earlier XTPAXLSA adapter with an updated snap-on design for faster, tool-free installation on panel and control-cabinet builds where space and assembly time matter.

Key Features

  • Compact Dimensions: 45 mm width x 42 mm height x 33 mm depth for space-saving mounting alongside XTPR devices in tight enclosures.
  • B Frame Size: Purpose-built to match B frame XTPR manual motor protectors for a precise, secure fit.
  • Snap-On Design: Snap-on mounting version simplifies assembly, reduces installation time, and replaces the previous XTPAXLSA adapter.
  • Combination Starter Configuration: Used with XTPR to create a UL 508 Type E/F manual combination starter for motor circuit protection.
  • Accessory Type Construction: Classified as an Accessory Type component within the Eaton XT IEC motor control line, designed to integrate seamlessly with existing XT assemblies.
  • Compliance-Ready: CE Marked and tested to EN 60947-4-1 for IEC motor control applications, supporting international project specifications.
  • Supplied Quantity: Available in quantities of 5 per package for straightforward panel-shop stocking.

Certifications & Compliance

  • CE Marked
  • EN 60947-4-1
  • Used with XTPR to Form a UL 508 Type E/F Manual Combination Starter

Technical Specifications

  • Quantity: 5
  • Product Type: Adapter
  • Product Width: 45 mm
  • Product Height: 42 mm
  • Product Length/Depth: 33 mm
  • Size: B frame
  • Catalog Notes: Snap on version, use instead of XTPAXLSA

Typical Applications

  • Manual Motor Protection and Combination Starter Assemblies
  • IEC-Based Motor Control Panels
  • Commercial and Industrial Electrical Installations
  • OEM Machine Control Building
  • Panelboard and Control Enclosure Wiring
  • Retrofit Upgrades Replacing XTPAXLSA Adapters

Why Eaton?

Eaton engineers the XT IEC motor control line for dependable, code-compliant performance in demanding industrial environments. This Line Side Adapter carries CE Marking and EN 60947-4-1 compliance, giving electrical professionals confidence when building UL 508 Type E/F manual combination starters with XTPR devices. The snap-on construction and B frame sizing reflect Eaton's focus on practical, field-friendly design. Choose Eaton for consistent quality across its motor control and protection portfolio.

Manufacturer Resources

Product Specs

Product Width:
45 mm
Catalog Notes:
Snap on version, use instead of XTPAXLSA
Item Quantity:
5
Product Size:
B frame
Product Length/Depth:
33 mm
Compliances:
CE Marked
Product Height:
42 mm
Product Type:
Contactor & Relay Accessory
Certifications:
EN 60947-4-1
Department:
Electrical
Series:
B Frame
Standards:
EN 60947-4-1
Listing:
CE Marked
Product Group:
Motor Control & Automation
Product Subgroup:
Contactors & Relays

Eaton XTPAXLSA2 – Frequently Asked Questions

1) What does the Eaton XTPAXLSA2 line side adapter actually do in a motor control panel?
It is a snap-on line side terminal adapter for the Eaton XTPR manual motor protector. Fitted to an XTPR, it forms a UL 508 Type E/F manual combination starter, which is what lets the device be used as the disconnect and short circuit protection ahead of the motor. On its own it does no switching or protection, it terminates and shrouds the line side of the XTPR.
2) Will the XTPAXLSA2 fit any XTPR manual motor protector, or only certain frame sizes?
B frame only. The XTPAXLSA2 is sized for B frame XTPR devices, so if your protector is a different frame size the adapter will not seat on it. Check the frame designation on the XTPR before you order.
3) Can I use the XTPAXLSA2 in place of the older Eaton XTPAXLSA adapter?
Yes, that is exactly its purpose. Eaton's catalog note reads "Snap on version, use instead of XTPAXLSA." It is the snap-on replacement for the earlier screw-mount style adapter, so on a retrofit or a repeat panel build you order the XTPAXLSA2 going forward.
4) How much room do I need in the enclosure for the Eaton B frame line side adapter?
Plan for 45 mm width, 42 mm height and 33 mm depth. It sits on the line side of the XTPR, so allow that depth clear above the protector in the DIN rail layout before you finalize the panel drawing.
5) Does the Eaton XT line side adapter meet IEC standards for an export machine build?
It is CE Marked and built to EN 60947-4-1, the IEC standard covering electromechanical contactors and motor starters. That is what supports it on machines specified to IEC rather than purely North American requirements.
6) Do I get one adapter or a pack when I order XTPAXLSA2?
They come 5 to a package. Panel shops running multiple motor starters per build usually want that, but if you only need a single Type E/F conversion you will still be buying the five pack.
7) Is the XTPAXLSA2 a tool-free install or does it need screws to mount?
Snap-on. The XTPAXLSA2 clips onto the B frame XTPR without separate mounting hardware, which is the main change from the older XTPAXLSA it supersedes. Line conductors still land on the adapter terminals in the normal way.
8) Is a Leviton 4-in-1 adapter plate an alternative to the Eaton XT line side adapter?
No, and they are not interchangeable in any sense. The Leviton 3254-BLU is a 4-in-1 adapter plate for wiring device and outlet box work. The Eaton XTPAXLSA2 is a line side terminal adapter that snaps onto a B frame XTPR manual motor protector to build a Type E/F combination starter. If you are wiring a motor branch circuit, only the Eaton part applies.
