Advance Electronic Fluorescent Ballast 3-Lamp T8 32W 120-277V Instant Start

Advance Electronic Fluorescent Ballast 3-Lamp T8 32W 120-277V Instant Start

Professional lighting control for commercial and industrial applications

The Advance Electronic Fluorescent Ballast delivers reliable performance for 3-lamp T8 fluorescent lighting systems. This instant start ballast operates on 120-277V with a high 0.98 power factor and 0.77 ballast factor, providing efficient lighting control for commercial facilities. Featuring Class P thermal protection and compact dimensions of 9.5" x 2.0" x 1.1", this UL and CSA certified ballast ensures dependable operation in professional lighting applications.

Professional Features & Benefits

• 3-Lamp T8 Capacity: Controls three 32W T8 fluorescent lamps for comprehensive area lighting coverage
• 120-277V Universal Voltage: Compatible with standard commercial voltage systems for versatile installation flexibility
• 0.98 Power Factor: High power factor reduces energy waste and improves electrical system efficiency
• Instant Start Technology: Provides immediate lamp ignition without warm-up delay for instant illumination
• Class P Thermal Protection: Built-in thermal protection prevents overheating and extends ballast service life
• Compact Design: 9.5" x 2.0" x 1.1" dimensions allow installation in space-constrained fixtures
• Multiple Certifications: UL, CSA, CEC, and RoHS compliant for code compliance and environmental responsibility

Technical Specifications

• Ballast Factor: 0.77
• Country Of Origin: USA
• Dimmable: No
• Frequency Rating: 50to60 Hz
• Lamp Type: T8
• Number Of Lamps: 3
• Power Factor: 0.98
• Power Rating: 32 WTT
• Product Height: 1.1000 IN
• Product Length: 9.5000 IN
• Product Type: Electronic Fluorescent
• Product Wattage: 32 W
• Product Weight: 0.822 Lbs
• Product Width: 2.0000 IN
• Standard: CSA certificate;UL certificate;CEC Listing;CEE Rated;NEMA Premium;RoHS Compliant
• Start Type: INSTANT START
• Thermal Protection: CLASS P
• Voltage Rating: 120-277 V

Installation & Operation

1. Mount the ballast in a suitable location with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire lamp connections according to the provided 3-lamp T8 configuration and 120-277V specifications.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test instant start functionality and verify proper lamp operation before placing into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to fluorescent ballast systems.

Professional Applications

• Commercial Office Buildings
• Retail Establishments
• Educational Facilities
• Healthcare Facilities
• Industrial Workspaces
• Warehouse and Storage Areas
• Government Buildings

Why Choose Advance Quality?

Advance ballasts deliver proven reliability with comprehensive certifications including UL, CSA, CEC, and RoHS compliance. The Class P thermal protection and high 0.98 power factor ensure long-term performance and energy efficiency. Made in USA with NEMA Premium rating, this ballast provides the professional-grade quality demanded by commercial lighting applications.
